CJ2H-CPU64EIP

Omron CJ2H-CPU64EIP CJ2 High-Performance CPU Unit with EtherNet/IP

SKU: CJ2H-CPU64EIP

USD 580.00

Omron CJ2H-CPU64EIP is a CJ2H high-performance PLC CPU with 40K steps and built-in EtherNet/IP for networked automation.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CJ2H-CPU64EIP is a high-performance CPU unit from the CJ2 series modular PLC platform, designed for demanding industrial automation applications requiring fast processing, extensive memory, and integrated Ethernet connectivity. This processor delivers 40K steps of program capacity with instruction execution times as fast as 0.04μs for basic instructions, enabling complex control algorithms and high-speed sequence operations. The built-in Ethernet/IP port provides seamless connectivity to HMIs, SCADA systems, enterprise networks, and other PLCs without requiring additional communication modules, reducing system cost and complexity. The CJ2H-CPU64EIP supports up to 2560 I/O points across multiple racks, making it suitable for large-scale manufacturing systems, process control applications, and distributed control architectures. The CPU features extensive data memory capacity with 128K words for data logging, recipe management, and complex data manipulation tasks. The integrated USB port facilitates fast program uploads/downloads and online monitoring, significantly reducing commissioning and troubleshooting time compared to serial communication. The CJ2 series maintains backward compatibility with CJ1 series I/O modules, protecting existing investments while providing enhanced performance and functionality. Advanced features include task programming for deterministic execution timing, structured programming with function blocks, and comprehensive data handling capabilities. The processor supports multiple communication protocols including Ethernet/IP, Modbus TCP, and FINS messaging, enabling flexible integration with diverse automation architectures. Applications include automotive manufacturing, food and beverage processing, pharmaceutical production, material handling systems, and any application requiring high-speed, reliable control with extensive networking capabilities.

  • SKU: CJ2H-CPU64EIP
  • Series: CJ2H
  • I/O: 2560 I/O

Best-Fit Applications

  • Automotive manufacturing lines
  • Food and beverage processing
  • Pharmaceutical production systems
  • Material handling and warehousing
  • Packaging machinery
  • Process control systems
  • Water and wastewater treatment
  • Energy management systems

Buying Checklist

  • High-speed processing for demanding applications
  • Integrated Ethernet eliminates extra modules
  • Large memory capacity for complex programs
  • USB port simplifies programming and maintenance
  • Backward compatible with CJ1 investments
  • Proven Omron PLC reliability
  • Comprehensive programming tools
  • Global technical support network

Technical Specifications

Model CJ2H-CPU64EIP
Series CJ2H
Type High-Performance PLC CPU
Program Capacity 40K steps
Data Memory 64K words
Max I/O Points 2560 points
LD Instruction Time 0.04μs
Built-in Ports EtherNet/IP, USB
High-Speed Counter 100kHz 4-axis
Pulse Output 100kHz 4-axis
Expandable Units Up to 40 units
Battery Life 5 years at 25°C
Operating Temperature 0 to +55°C
Software CX-Programmer

FAQ for CJ2H-CPU64EIP

What's the advantage of built-in EtherNet/IP?
No need for separate Ethernet unit. Direct connection to EtherNet/IP network: HMIs, drives, remote I/O, other PLCs. Saves slot and cost.
Can this CPU act as EtherNet/IP scanner?
Yes, CJ2H-CPU64EIP can be EtherNet/IP adapter (slave) or scanner (master). As scanner, can control remote I/O, drives, and other EtherNet/IP devices.
What's the difference between CPU64 and CPU64EIP?
CPU64EIP has built-in EtherNet/IP port. CPU64 requires CJ1W-EIP21 unit for EtherNet/IP. Same program capacity and performance.
Can I use FINS over EtherNet/IP?
Yes, FINS/TCP and FINS/UDP supported over EtherNet/IP port. Enables communication with Omron HMIs, other Omron PLCs using FINS protocol.
