Omron CJ2H-CPU65EIP CJ2 CPU Unit with EtherNet/IP
SKU: CJ2H-CPU65EIPUSD 720.00
Omron CJ2H-CPU65EIP is a CJ2 CPU unit with built-in EtherNet/IP for networked automation applications.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CJ2H-CPU65EIP is a high-performance CPU unit from the CJ2 series, featuring 60K steps of program capacity and built-in Ethernet/IP communication. This processor delivers exceptional speed and functionality for complex automation applications, with instruction execution times as fast as 0.04μs for basic instructions. The integrated Ethernet/IP port enables seamless connectivity to HMIs, SCADA systems, and enterprise networks without requiring additional communication modules. With support for up to 2560 I/O points and extensive memory capacity, the CJ2H-CPU65EIP is ideal for large-scale manufacturing systems, process control applications, and facilities requiring advanced data acquisition and networking capabilities.
- SKU: CJ2H-CPU65EIP
- Series: CJ2H
- I/O: 2560 I/O
Best-Fit Applications
- Large manufacturing systems
- Automated assembly lines
- Process control plants
- Material handling systems
- Quality control systems
- Data acquisition systems
Buying Checklist
- High-speed performance
- Built-in Ethernet eliminates extra modules
- Scalable I/O capacity
- Large memory for complex programs
- USB port for easy programming
- Proven CJ2 platform
Technical Specifications
| Model | CJ2H-CPU65EIP |
|---|---|
| Series | CJ2H |
| Program Capacity | 60K steps |
| Built-in Ports | EtherNet/IP, USB |
| Max I/O Points | 2560 points |
| LD Instruction Time | 0.04μs |
| Expandable Units | Up to 40 units |
| Operating Temperature | 0 to +55°C |
| Software | CX-Programmer |
Resources & Downloads
FAQ for CJ2H-CPU65EIP
Is this the same as CJ2H-CPU65-EIP?
Yes, CPU65EIP and CPU65-EIP refer to the same model. Different listings may use either notation. Both have 60K capacity and built-in EtherNet/IP.
What networks does this CPU support?
Built-in EtherNet/IP. Add CJ1W communication units for DeviceNet, CompoNet, Controller Link, serial networks. Flexible network configuration.
Can I program this CPU over Ethernet?
Yes, CX-Programmer connects via EtherNet/IP using FINS/TCP protocol. Faster than serial connection. Allows remote programming and monitoring.
Is this CPU suitable for large systems?
Yes, 60K program capacity and 2560 I/O points suit large automation systems. For very large systems, consider CJ2H-CPU67/68 with more capacity.
