Omron CP1E-N20DT1-A Compact PLC 20 I/O Transistor Output Sinking

Name: Omron CP1E-N20DT1-A Compact PLC 20 I/O Transistor Output Sinking
Brand: Omron
SKU: CP1E-N20DT1-A
Price: 90 USD
Availability: InStock

SKU: CP1E-N20DT1-A

USD 90.00

Omron CP1E-N20DT1-A is a CP1E-N series compact PLC with 20 total I/O points (12 input, 8 transistor output), sinking NPN output for high-speed switching applications.

1-Year Warranty Full manufacturer warranty

Global Shipping Worldwide delivery available

Genuine Omron 100% authentic product

Ready to Ship Usually ships within 24h

In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The CP1E-N20DT1-A fits industrial control projects that require dependable logic execution, maintainable programming workflows, and architecture growth over the equipment lifecycle. It supports standardized automation design across machine families while preserving serviceability in production environments.

Deterministic Logic and Sequence Control

This controller class supports predictable scan-driven execution for interlocks, sequencing, alarms, and coordinated device handling. Deterministic behavior is essential for consistent machine output and repeatable cycle performance.

Platform Reuse Across Equipment Variants

Standardizing on a proven PLC/controller family enables software reuse, reduced engineering lead time, and easier support across multiple machine models or production lines.

Lifecycle Service and Maintainability

A maintainable control architecture with documented I/O mapping, diagnostics, and modular expansion strategy reduces troubleshooting time and improves long-term ownership value.

Key Features

Total I/O Points: 20 points (12 input, 8 output)
Output Type: Transistor (NPN sinking)
Power Supply: AC100-240V
Program Capacity: 5K steps
High-Speed Counter: 100kHz 1-axis
Pulse Output: 100kHz 1-axis

SKU: CP1E-N20DT1-A
Series: CP1E-N
Voltage: 240V
I/O: 20 I/O

Best-Fit Applications

Executes deterministic control logic
Coordinates multi-device machine behavior
Supports reusable software structures
Improves fault diagnostics and recovery time
Enables modular feature growth over time
Standardizes control strategy across equipment

Buying Checklist

Strong fit for scalable machine control
Maintains deterministic automation behavior
Supports long-term maintainability
Good platform standardization candidate
Reliable industrial controller ecosystem

Technical Specifications

Model	CP1E-N20DT1-A
Series	CP1E-N
Total I/O Points	20 points (12 input, 8 output)
Output Type	Transistor (NPN sinking)
Power Supply	AC100-240V
Program Capacity	5K steps
High-Speed Counter	100kHz 1-axis
Pulse Output	100kHz 1-axis
Max Output Current	0.3A per point
Operating Temperature	0 to +55°C

Resources & Downloads

FAQ for CP1E-N20DT1-A

What's the advantage of transistor output over relay output?

Transistor outputs offer: much faster switching (up to 100kHz for pulse output), longer life (no mechanical contacts), silent operation, and higher switching frequency. Choose transistor for high-speed counting, positioning, or PWM applications.

What's the difference between NPN (sinking) and PNP (sourcing) outputs?

NPN (sinking) switches the negative/0V side - current flows INTO the output. PNP (sourcing) switches the positive side - current flows OUT of the output. Match your output type to your load wiring and regional standards (NPN common in Asia, PNP common in Europe).

Can I use this PLC for stepper motor control?

Yes, the transistor output model supports 100kHz pulse output for stepper motor control. Use pulse/direction signals to control stepper drivers. Suitable for single-axis positioning applications like indexing tables or linear actuators.

What's the maximum load current for transistor outputs?

0.3A per point, 0.8A per common (4 points). For higher current loads, use intermediate relays or contactors. Total current for all outputs should not exceed 1.2A for the CPU unit.
