Omron NS12-TS00-V2 NS Series Touch Screen HMI 12.1 inch STN
SKU: NS12-TS00-V2USD 780.00
Omron NS12-TS00-V2 is a 12.1 inch NS series HMI with STN display, large screen premium operator interface.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron NS12-TS00-V2 is a large-screen programmable terminal from the NS series, featuring a 12.1-inch STN color LCD touch screen designed for industrial automation applications requiring more display area. This HMI provides a comprehensive user interface for operator monitoring and control, with display area for complex process data, multiple alarms, detailed graphics, and trending information. The STN display technology provides good visibility in various lighting conditions while maintaining cost-effectiveness. The NS12-TS00-V2 supports Ethernet connectivity for seamless integration with Omron PLCs and other automation devices, enabling fast data exchange and remote monitoring capabilities. The large touch screen allows intuitive operation with multiple on-screen buttons, indicators, and data display elements that can be configured using Omron NS-Designer software. This HMI supports multiple communication protocols including Ethernet, RS-232C, and RS-422/485, providing flexibility for connecting to various PLC brands and automation equipment. The robust construction with IP65 front panel rating makes it suitable for industrial environments. The NS12-TS00-V2 includes built-in memory for storing complex screens, extensive logic, and data logging, supporting demanding applications. With support for trending, alarms, recipes, and multi-window displays, this HMI provides comprehensive operator interface capabilities for medium to large-scale automation projects.
- SKU: NS12-TS00-V2
- Series: NS12
Best-Fit Applications
- Advanced PLC operator interface
- Complex machine control monitoring
- Detailed process visualization
- Multi-alarm systems
- Data entry terminals
- Medium-scale SCADA
- Large packaging machinery HMI
- Complex assembly line interfaces
Buying Checklist
- Large display area for complex screens
- High resolution graphics
- Easy touch screen programming
- Multiple communication options
- Proven Omron HMI reliability
- Ethernet for networked applications
- Advanced features support
- IP65 rated for industrial use
Technical Specifications
| Model | NS12-TS00-V2 |
|---|---|
| Series | NS12 |
| Screen Size | 12.1 inch |
| Display Type | STN Color LCD |
| Resolution | 800 x 600 (SVGA) |
| Touch Panel | Analog resistive |
| Communication | Ethernet, USB, Serial |
| Supply Voltage | DC24V |
| Memory | 32MB |
| Operating Temperature | 0 to +55°C |
| Protection | IP65 (front panel) |
| Software | CX-Designer |
Resources & Downloads
FAQ for NS12-TS00-V2
What's the advantage of 12.1 inch display?
Large screen shows more information simultaneously. Ideal for SCADA screens, multiple trends, detailed schematics. Better visibility from distance.
What's the screen resolution?
800x600 SVGA resolution. Higher than VGA (640x480). More screen real estate for complex interfaces.
Can this HMI display multiple windows?
Yes, NS series supports popup windows, split screens. Display multiple information sources simultaneously.
Can I connect keyboard and mouse?
Yes, USB ports support keyboard and mouse. Useful for data entry, navigation, complex operations.
