Omron P2RFZ-08-E Push-in Terminal Socket 8-Pin

SKU: P2RFZ-08-E

USD 1.50

Omron P2RFZ-08-E is an 8-pin relay socket with push-in terminals for tool-less wiring of G2R/H5CZ series relays.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron P2RFZ-08-E is an 8-pin push-in terminal socket designed specifically for H5CZ series timer relays from Omron. This socket provides a convenient and reliable method for connecting timer relays in industrial control panels. The push-in terminal technology enables fast and tool-free wiring, significantly reducing installation time compared to traditional screw-terminal sockets. The P2RFZ-08-E supports both solid and stranded conductors within the 0.5-2.5 mm² range, providing flexibility for various wiring scenarios. The socket features DIN rail mounting capability, allowing for quick installation and easy removal for maintenance or replacement. The compact design and clear terminal markings help save panel space and reduce wiring errors during installation. This socket is ideal for control panel builders and automation integrators working with Omron H5CZ timer relays in applications such as industrial timing, sequencing, and delay functions.

  • SKU: P2RFZ-08-E
  • Series: P2RFZ
  • Voltage: 250VAC

Best-Fit Applications

  • Industrial timer circuits
  • Conveyor delay controls
  • Machine timing functions
  • Sequencing equipment
  • Lighting control timing
  • Motor control delays
  • Process automation timing
  • Panel building

Buying Checklist

  • Fast push-in wiring reduces labor
  • Reliable spring contact connection
  • Easy DIN rail installation
  • Compact size saves panel space
  • Compatible with popular H5CZ timers
  • Clear markings prevent errors
  • Professional appearance

Technical Specifications

Model P2RFZ-08-E
Series P2RFZ
Pin Count 8-pin
Connection Type Push-in spring terminals
Compatible Relays G2R-2, H5CZ series
Terminal Capacity 22-16 AWG (0.5-1.5mm²)
Mounting Panel or DIN rail
Rated Current 10A
Rated Voltage 250VAC
Operating Temperature -25 to +55°C

FAQ for P2RFZ-08-E

What relays fit 8-pin push-in socket?
G2R-2 series relays, H5CZ series counters, and standard 8-pin tube base relays. Check relay base matches socket pin configuration.
Is push-in as reliable as screw terminals?
Yes, push-in spring terminals are UL/CSA certified and meet same standards as screw terminals. Spring force maintains constant contact pressure, resistant to vibration loosening.
Can I DIN rail mount this socket?
Yes, includes DIN rail clip. Also supports panel mounting. DIN rail mounting allows easy socket replacement without rewiring.
What's the wire stripping length?
10mm (3/8 inch) stripping length for push-in terminals. Too short: won't make contact. Too long: exposed conductor outside terminal.
