Omron R88M-1M20030T-BS2 AC Servo Motor 200W 3000rpm 1S Series with Brake — front view

Omron R88M-1M20030T-BS2 1S Servo Motor, 200 W, 100 VAC, 3000 rpm, with Brake

SKU: R88M-1M20030T-BS2

USD 225.00

Omron R88M-1M20030T-BS2 1S-series AC servo motor, 200 W, 100 VAC, 3000 rpm, smooth shaft, with 24 VDC electromagnetic brake, for vertical-axis 1S servo applications.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron R88M-1M20030T-BS2 is a 200 W, 100 VAC, 3000 rpm member of the 1S-series servo motor family, with a 24 VDC electromagnetic brake. The "1M" prefix in the R88M ordering code denotes the 100 V class; "20030" is 200 W at 3000 rpm; "T" is the standard (non-oil-seal) shaft; "-BS2" denotes smooth shaft with electromagnetic brake.

The 1S family is Omron's compact, low-cost servo motor line, designed to pair with the 1S-series R88D-1SN and R88D-1M drives. It uses a 17-bit incremental serial encoder (4,096 counts / rev with ×4 quadrature in the drive), and the motor body carries a keyway and a 24 VDC brake that engages when the brake power is removed.

The brake version (-BS2) is intended for vertical-axis and Z-axis applications where the load must be held in place when the servo is de-energised. The brake is spring-applied, electrically released — fail-safe on power loss. Brake power is 24 VDC, drawn from a dedicated brake-release supply on the drive (do not power the brake from the logic supply).

The 100 V class is common in Japan and parts of Asia, and on small 100 V control transformers in industrial panels. In Europe and the Americas, the 200 V class is the standard.

Key Features

  • 200 W continuous output at 3000 rpm rated speed
  • 100 VAC class (100–115 VAC)
  • 17-bit incremental serial encoder
  • 24 VDC spring-applied electromagnetic brake (engages on power-off)
  • Smooth shaft (no keyway) for flexible coupling
  • 50 mm frame (square flange)
  • IP65 body, IP67 shaft seal
  • Insulation class B
  • SKU: R88M-1M20030T-BS2
  • Series: 1S (R88M-1M)
  • Voltage: 100 VAC
  • I/O: 200 I/O

Best-Fit Applications

  • Vertical-axis and Z-axis applications where load holding is required
  • Compact 200 W pick-and-place axes
  • Small indexing tables and rotary fixtures
  • Labelling and dispensing heads on packaging lines
  • Bench-top laboratory automation

Buying Checklist

  • Match the motor voltage class (100 V) to the drive voltage class (R88D-1M family) — never mix 100 V and 200 V
  • Confirm the brake voltage (24 VDC) matches your brake-release supply
  • For keyed shaft, choose the -BS2K variant; for oil seal, add the O-seal suffix
  • Use a flexible coupling rated for the 8 mm shaft and your side-load
  • Plan a brake-release delay in the drive's safety logic — sudden brake release under load can cause a position error

Technical Specifications

Series 1S (R88M-1M)
Model R88M-1M20030T-BS2
Motor type AC servo motor, low-inertia
Rated output 200 W
Rated speed 3,000 rpm
Rated voltage 100 VAC class (100–115 VAC, single-phase)
Rated torque 0.64 N·m
Peak torque 1.91 N·m (3× rated)
Rated current ≈ 2.0 A (per-phase)
Encoder 17-bit incremental serial
Shaft Smooth (no keyway)
Brake 24 VDC spring-applied electromagnetic brake
Brake holding torque ≥ rated torque
Frame size 50 mm square flange
Shaft diameter 8 mm
Mass ≈ 0.9 kg (with brake)
Protection IP65 (body), IP67 (shaft)
Insulation class Class B
Operating temperature 0 °C to +40 °C

FAQ for R88M-1M20030T-BS2

What drive pairs with this motor?
The R88D-1M20030T-S2 or R88D-1M20030T-BS2 — the matching 100 V 200 W drive in the MECHATROLINK-II or EtherCAT family. Always match the voltage class.
Why does this motor have a brake?
For vertical-axis / Z-axis applications where the load has to be held in place when the servo is de-energised. The brake is spring-applied and electrically released at 24 VDC — so if power is lost, the brake engages and the load is held.
Is the brake powered from the drive or from a separate supply?
The 1S drives provide a dedicated 24 VDC brake output. You do not need a separate brake supply; just route the drive's brake terminals to the motor's brake wires. The drive controls brake release / engage in sync with servo enable.
