Omron R88D-1M20030T-S2 Servo Motor and Drive Set 200W 1S Series — front view

Omron R88D-1M20030T-S2 Accurax G5 Servo Drive, 200 W, 100 VAC, MECHATROLINK-II

SKU: R88D-1M20030T-S2

USD 175.00

Omron R88D-1M20030T-S2 Accurax G5 servo drive, 200 W output, single-phase 100 VAC input, MECHATROLINK-II communications, for compact 200 W servo axes on CJ/NJ/NX controllers.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron R88D-1M20030T-S2 is a 200 W, 100 VAC-input member of the Accurax G5 servo family. The "1M" prefix in the R88D ordering code denotes the 100 VAC MECHATROLINK-II variant — the smallest-power G5 drive, intended for compact machines that run off single-phase 100 VAC mains (common in Japan and parts of Asia, and on the control transformer of small panels elsewhere).

MECHATROLINK-II is Omron's deterministic motion fieldbus. It carries position, speed and torque commands, plus real-time status and I/O, on a single cable between the controller and the drive. A CJ1W-MCH71 or CJ2 master module on a CP1H/CJ-series PLC, or an NJ/NX-series controller, runs the G5 axes on MECHATROLINK-II with cycle times down to 250 µs.

The 20030 in the code means 200 W at the 3000-rpm motor speed class. This drive is matched to the R88M-1M20030T (no brake) and R88M-1M20030T-B (with brake) motors in the 100 VAC G5 family. Pair the drive and motor carefully — mixing 100 V and 200 V drives and motors is a common commissioning error.

The drive supports profile-position, profile-velocity, profile-torque and interpolated-position modes, plus homing. Gain tuning can be one-button automatic or fully manual. The "-S2" suffix denotes a standard (non-safety) drive.

Key Features

  • 200 W continuous output at 3000 rpm motor class
  • Single-phase 100 VAC input — drops into small 100 V control transformers
  • MECHATROLINK-II motion bus, up to 250 µs cycle time
  • Position / speed / torque control modes plus homing
  • One-button auto-gain tuning, with manual override
  • 17-bit incremental encoder feedback (compatible with R88M-1M series motors)
  • Integrated regenerative braking resistor (no external unit for typical 200 W duty)
  • DIN-rail or panel mounting
  • SKU: R88D-1M20030T-S2
  • Series: Accurax G5 (R88D-1M)
  • Voltage: 115 VAC
  • I/O: 200 I/O

Best-Fit Applications

  • Compact 200 W servo axes on packaging, labelling and small-format assembly machines
  • Indexing tables and small rotary axes in laboratory automation
  • Pick-and-place gantries with MECHATROLINK-II daisy-chaining
  • Retrofit of older 100 VAC servo systems to a current Omron platform
  • Tight integration with CJ1W-MCH71 / CJ2 / NJ / NX controllers over MECHATROLINK-II

Buying Checklist

  • Confirm the input voltage — the 1M (100 VAC) and 1SN (200 VAC) drives look similar but are not interchangeable
  • Match the drive and motor suffixes: 20030T drive ↔ 20030T motor; 20030T-BS2 drive ↔ 20030T-B motor
  • If you need safety (STO/SS1/SLS), order the -Z variant — the -S2 is a standard drive
  • Check MECHATROLINK-II master availability — the controller needs a CJ1W-MCH71 or built-in MECHATROLINK-II port
  • For cable runs over 20 m, use Omron's specified MECHATROLINK-II cable — generic Ethernet cable is not rated for the motion duty

Technical Specifications

Series Accurax G5 (R88D-1M)
Model R88D-1M20030T-S2
Drive type MECHATROLINK-II servo drive
Continuous output 200 W
Applicable motor R88M-1M20030T / R88M-1M20030T-B (100 VAC, 3000 rpm)
Input voltage Single-phase 100–115 VAC, 50/60 Hz
Control method PWM sine-wave drive, IGBT
Encoder feedback 17-bit incremental serial encoder
Communication MECHATROLINK-II
Cycle time 250 µs / 500 µs / 1 ms (selectable)
Control modes Position, speed, torque, homing
Gain tuning Auto (one-button) and manual
Protective functions Overcurrent, overload, overvoltage, undervoltage, overspeed, encoder error, regenerative discharge
Operating temperature 0 °C to +55 °C
Storage temperature -20 °C to +65 °C
Mounting DIN rail or panel mount

FAQ for R88D-1M20030T-S2

What's the difference between the R88D-1M and R88D-1SN?
The R88D-1M is the 100 VAC MECHATROLINK-II family; the R88D-1SN is the 200 VAC MECHATROLINK-II family at the same power ratings. 100 VAC drives are common in Japan; 200 VAC drives are the standard everywhere else. Do not mix the two.
What motor do I pair with this drive?
The R88M-1M20030T (no brake) or R88M-1M20030T-B (with brake) in the 100 VAC 3000 rpm family. Always match the voltage class of drive and motor.
Does this drive support safety (STO)?
No. The -S2 suffix is a standard drive. For STO / SS1 / SLS support, order the -Z suffix variant instead — that is a different drive, not a firmware option.
What controller do I need?
Any Omron controller with a MECHATROLINK-II master: CJ2 with CJ1W-MCH71, CP1H with CJ1W-MCH71, or an NJ / NX series controller. The drive is configured from CX-Drive and commissioned via the Sysmac Studio or CX-Programmer + CX-Motion tools.
