Omron R88D-KT02H-Z Accurax G5 Servo Drive, 200 W, 200 VAC, Analog/Pulse, with Safety

SKU: R88D-KT02H-Z

USD 360.00

Omron R88D-KT02H-Z Accurax G5 servo drive, 200 W, single-phase 200 VAC, analog ±10 V or pulse-train command input, with STO/SS1/SLS safety (-Z), for pulse-command PLC retrofits.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron R88D-KT02H-Z is a 200 W, single-phase 200 VAC G5 servo drive with the analog/pulse-train command interface and the safety option. The "KT" prefix in the R88D ordering code denotes the analog/pulse-train command family — used in applications where the controller issues a ±10 V analog velocity/torque command or a step/direction pulse train rather than a fieldbus command.

This drive family is the right choice for retrofitting an existing line where the controller is a pulse-output PLC (CP1H-Y, CP1L, or a non-Omron PLC) rather than a Sysmac NJ/NX. Pulse-train position control gives reliable point-to-point motion using the PLC's high-speed pulse output, with no need to add an EtherCAT master.

The "-Z" suffix adds the safety option: STO (Safe Torque Off), SS1 (Safe Stop 1) and SLS (Safely Limited Speed) per IEC 61800-5-2, activated by discrete safety inputs (24 VDC) on the drive's safety connector. Note that on the KT-family (analog/pulse) drives, the safety I/O is hard-wired, not FSoE — that is because the analog/pulse command interface is not EtherCAT.

Matching motor: R88M-K20030H (no brake) or R88M-K20030H-B (with brake) in the 200 V 3000 rpm family. The drive carries a built-in regenerative resistor for typical 200 W duty.

Key Features

  • 200 W continuous output at 3000 rpm motor class
  • Single-phase 200–230 VAC input
  • Analog ±10 V or pulse-train (line-driver / open-collector) command input
  • Integrated safety: STO, SS1, SLS per IEC 61800-5-2 (discrete 24 VDC safety inputs)
  • 20-bit absolute encoder feedback with the matching R88M-K motor
  • One-button auto-gain tuning with manual override
  • Built-in regenerative resistor
  • DIN-rail or panel mount
  • SKU: R88D-KT02H-Z
  • Series: Accurax G5 (R88D-KT)
  • Voltage: 230 VAC
  • I/O: 200 I/O

Best-Fit Applications

  • Retrofit of pulse-output PLC systems to current G5 hardware
  • Stepper-replacement upgrades where 200 W servo performance is needed
  • Stand-alone positioning axes on packaging / cutting machines
  • Safety-rated axes with discrete safety wiring (no safety bus)
  • Replacement for legacy Omron SMX/SMY servo systems

Buying Checklist

  • If you need fieldbus, use the EtherCAT (-ECT) variant — this drive is analog/pulse only
  • For 24 VDC discrete safety wiring, the -Z variant's safety connector is the standard interface
  • For pulse input, decide between line-driver and open-collector — they are different pulse-input pins
  • Match the motor to the 200 V 200 W class
  • For pulse frequencies above 200 kpps, use the line-driver pulse input (not the open-collector)

Technical Specifications

Series Accurax G5 (R88D-KT)
Model R88D-KT02H-Z
Drive type Analog/pulse-train servo drive with safety
Continuous output 200 W
Applicable motor R88M-K20030H / R88M-K20030H-B (200 VAC, 3000 rpm)
Input voltage Single-phase 200–230 VAC, 50/60 Hz
Control method PWM sine-wave, IGBT
Command input Analog ±10 V (velocity/torque) OR pulse train (step + direction / A + B)
Pulse input modes Line-driver (RS-422) or open-collector, up to 500 kpps line-driver
Encoder feedback 20-bit absolute serial encoder
Safety functions STO, SS1, SLS per IEC 61800-5-2 (hard-wired 24 VDC inputs)
Safety rating SIL 3 / PL e (with suitable safety circuit)
Control modes Position (pulse-train), velocity (analog), torque (analog)
Gain tuning Auto (one-button) and manual
Protective functions Overcurrent, overload, overvoltage, undervoltage, overspeed, encoder error, regenerative discharge
Operating temperature 0 °C to +55 °C
Storage temperature -20 °C to +65 °C
Mounting DIN rail or panel mount

FAQ for R88D-KT02H-Z

Can I use this drive with an NJ or NX controller?
Technically yes — you wire the NJ/NX high-speed output to the drive's pulse input. But this loses most of the value of an NJ/NX system. For new NJ/NX designs, use the EtherCAT (-ECT) variant instead.
How are the safety functions wired?
On the KT-family drives, safety is hard-wired: 24 VDC discrete inputs on the drive's safety connector. The EtherCAT FSoE safety protocol is only available on the EtherCAT -Z variants. Both deliver the same STO / SS1 / SLS behaviour; the difference is the wiring.
What's the maximum pulse frequency?
500 kpps on the line-driver input, 200 kpps on the open-collector input. For most pulse-output PLCs the line-driver input is the right choice.
