Omron CJ1W-EIP21 — CJ EtherNet/IP Unit, 256 Connections
SKU: CJ1W-EIP21USD 270.00
CJ-series CPU-bus EtherNet/IP unit, one 10/100 port, 180k CH tag data links, FINS / socket service, 256 connections, 5 VDC / 250 mA.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CJ1W-EIP21 is the CJ-series CPU-bus EtherNet/IP unit. It sits in one CPU-bus slot on a CJ1 / CJ2 rack, draws 250 mA from the 5 VDC backplane, and exposes a single 10/100 Base-TX Ethernet port on the front face. Pick the EIP21 to add EtherNet/IP tag data links to an existing CJ build that needs to share up to 180,000 CH of real-time data with other EtherNet/IP devices -- Omron NX / NJ, Allen-Bradley ControlLogix, Keyence vision systems, or any ODVA-conformant controller on the same plant network.
Tag data links in plain language
Tag data links are deterministic, cyclic data exchanges between controllers -- the CJ1 / CJ2 PLC receives and sends fixed chunks of data on a set cycle (typically 1 to 100 ms) without any ladder-logic programming. The EIP21 supports up to 256 connections per unit, up to 256 nodes on the network, up to 722 CH per connection, and a total tag data link capacity above 180,000 CH. The producer / consumer model means the CJ1 / CJ2 PLC publishes data once and many devices consume it -- a typical 10-station conveyor with a CJ2 + 10 inverters at 50 words per inverter sits well within the 256 / 256 / 722 envelope.
CIP message + FINS + socket on one port
The same Ethernet port runs CIP explicit messaging for non-cyclic read / write between devices, plus FINS / UDP, FINS / TCP and Socket service for legacy CJ1 / NJ communications and for non-Omron TCP / UDP devices. A typical build uses CIP tag data links for cyclic I/O with a third-party EtherNet/IP scanner, FINS / TCP for programming-port upload from CX-Programmer, and Socket service for a third-party barcode reader.
EIP21 vs EIP21S
The bare CJ1W-EIP21 was discontinued by Omron in March 2025 in favor of the CJ1W-EIP21S that adds secure-communication features (secure-comm, user authentication, port on / off, IP packet filter) and official support for NJ-series CPUs. The EIP21 remains in stock at distributors for like-for-like spare replacement on existing CJ CPU-bus slots. Pick the EIP21S for new builds or for any install that needs network-security controls.
Key Features
- CJ-series CPU-bus EtherNet/IP unit, one slot wide on the CJ backplane
- One 10/100 Base-TX Ethernet port (RJ45, Auto-MDIX), 100 m cable run
- Tag data links: up to 256 connections per unit, up to 256 nodes on the network
- Up to 722 words per connection, total tag data link capacity above 180,000 CH
- Producer / consumer model -- no programming required for shared data
- CIP explicit messaging on the same port for non-cyclic read / write
- FINS / UDP + FINS / TCP + Socket service for legacy and third-party TCP / UDP devices
- Web server for diagnostics and tag-data-link configuration
- IP address: manual or DHCP, subnet mask, default gateway
- 5 VDC 250 mA from the CJ backplane -- no external supply
- UC1 / N / L / CE approvals; MADE IN JAPAN
- Discontinued March 2025 by Omron -- the CJ1W-EIP21S is the secure-comm successor
- Distinguishing feature vs CJ1W-ETN21: EIP21 adds EtherNet/IP tag data links; ETN21 is FINS / socket only
- SKU: CJ1W-EIP21
- Series: CJ-series CPU Bus EtherNet/IP Unit
Best-Fit Applications
- Add EtherNet/IP tag data links to an existing CJ1 / CJ2 rack for cyclic I/O with another ODVA scanner (e.g. Allen-Bradley ControlLogix, Keyence vision system)
- Cyclic tag-data-link exchange between CJ1 / CJ2 CPUs and a CJ2H-CPU6[]-EIP built-in EtherNet/IP scanner at up to 50 ms cycle
- FINS / TCP + Socket service on the same Ethernet port for CX-Programmer upload and a third-party TCP barcode reader
- Spare / replacement part for an existing CJ CPU-bus slot that already runs an EIP21 (the EIP21S is the official successor but the bare EIP21 stocks for like-for-like)
- Pick the CJ1W-EIP21S for new builds, secure-comm installs, or NJ-series CPU support -- the bare EIP21 is restricted to the CJ1 / CJ2 family
Buying Checklist
- Pick CJ1W-EIP21 to add EtherNet/IP tag data links to a CJ1 / CJ2 rack with 256 connections / 180,000 CH capacity.
- Pick CJ1W-EIP21S for new builds or installs that need secure-comm, user auth, or NJ-series CPU support (the EIP21 was discontinued March 2025).
- Pick CJ1W-ETN21 instead if only FINS / socket service is needed -- the ETN21 is cheaper and supports the same Ethernet port quartet minus EtherNet/IP.
- Pick CS1W-EIP21 for CS-series CPU-bus instead (the EIP21 only fits CJ1 / CJ2 / NJ CPU bus slots).
- Plan a free CJ CPU-bus slot on the rack and confirm the CJ1W-PA205R / PD025 PSU can carry the extra 250 mA 5 VDC draw.
- Use Network Configurator (CX-One) to set the tag data link connections on the EIP21 -- each connection consumes CH budget on a 256 / 256 / 722 envelope.
Technical Specifications
| Series | CJ-series CPU Bus EtherNet/IP Unit |
|---|---|
| Model | CJ1W-EIP21 (one Ethernet port, standard tag data links) |
| Ethernet Port | 1 x 10/100 Base-TX RJ45, Auto-MDIX, 100 m cable run |
| Tag Data Link Connections | Up to 256 per unit, up to 256 nodes total |
| Tag Data Link Capacity | Up to 722 CH per connection, 180,000 CH total or more |
| Message Service | CIP explicit messaging, FINS/UDP, FINS/TCP, Socket service (TCP / UDP) |
| Network Settings | IP address (manual or DHCP), subnet mask, default gateway; built-in web server |
| Power | 250 mA from 5 VDC CJ backplane (no external supply) |
| Mounting | One CJ CPU-bus unit slot, DIN-rail |
| Configuration Tool | CX-Programmer / CX-One / Network Configurator for EtherNet/IP |
| Discontinued Status | Discontinued March 2025 -- pick CJ1W-EIP21S for new builds, EIP21 for like-for-like spare replacement |
| Approvals / Origin | UC1 / N / L / CE; MADE IN JAPAN |
Resources & Downloads
FAQ for CJ1W-EIP21
What is the difference between CJ1W-EIP21 and CJ1W-ETN21?
Both are CJ-series CPU-bus Ethernet units with a single 10/100 Base-TX RJ45 port, but the EIP21 adds EtherNet/IP support. The EIP21 runs EtherNet/IP tag data links (cyclic producer / consumer between devices), CIP explicit messaging, FINS / UDP, FINS / TCP and Socket service. The ETN21 runs only FINS / UDP, FINS / TCP and Socket service -- no EtherNet/IP. Pick the EIP21 when the cabinet needs to talk to a third-party EtherNet/IP scanner / actuator or needs shared real-time data between Omron and non-Omron controllers. Pick the ETN21 when the only need is FINS / socket traffic to other Omron PLCs or a TCP / UDP device.
How many tag data link connections can the CJ1W-EIP21 handle?
Up to 256 connections per EIP21 unit, up to 256 nodes on the same EtherNet/IP network, up to 722 CH per connection. Total tag-data-link capacity exceeds 180,000 CH. This is the same envelope as the CJ2H-CPU6[]-EIP CPU built-in EtherNet/IP port, so swapping between a CPU-built-in port and an EIP21 unit does not change the data-link budget. A typical 10-inverter conveyor at 50 words per inverter uses only 50 connections / 50 nodes / 500 CH of the envelope.
Is the CJ1W-EIP21 still available?
Yes for like-for-like spare replacement on an existing CJ CPU-bus slot -- the bare CJ1W-EIP21 was discontinued by Omron in March 2025 in favor of the CJ1W-EIP21S that adds secure-communication features and NJ-series CPU support. Distributor stock of the bare EIP21 remains for retrofit and like-for-like use. For new builds, secure-comm installs, or NJ-series panels, pick the EIP21S instead.
Does the CJ1W-EIP21 work on a CJ2H-CPU6[]-EIP system?
Yes -- the EIP21 fits any CJ-series CPU-bus slot (CJ1H, CJ1M, CJ2H, CJ2M) on a CJ CPU rack. The CJ1W-IC101 I/O control unit is required on the CPU rack, and the CJ1W-II101 I/O interface unit is required on each expansion rack. For CJ1 / CJ2 CPUs without EtherNet/IP built in, the EIP21 is the standard add-on. The CJ1W-CIF11 RS-232C to RS-422A converter pigtail is not used here -- the Ethernet port on the EIP21 is the only network interface on the unit.
