Omron CJ1W-ID232 — 32-Pt DC Input, MIL Connector
SKU: CJ1W-ID232USD 65.00
CJ-series 32-point 24 VDC digital input unit with MIL 40-pin connector for US-standard flat-ribbon wiring. 4.1 mA per point, 5.6 kOhm impedance, 16 points per common, 8 ms ON/OFF response time, 2 CIO words per unit.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The CJ1W-ID232 is Omron's 32-point 24 VDC digital input unit for the CJ-series PLC platform with a MIL 40-pin connector on the front face — the US-standard counterpart to the CJ1W-ID231 (Fujitsu connector, already done). The MIL connector is the typical 40-pin polarized ribbon-style connector with crimp-on sockets, accepting the standard 40-pin flat-ribbon cable assembly (per MIL-DTL-83503) or the Omron G79-@@@C pre-wired cable assembly — which lets the engineer land 32 inputs in a 31 mm DIN-rail slot using bulkhead wiring methods familiar to North American control-panel builders. For installations where the existing wiring scheme uses MIL connectors (legacy Allen-Bradley 1771 I/O, PLC-5, SLC-500), the CJ1W-ID232 is the right pick for a CJ-series retrofit.
Decoding CJ1W-ID232 within the ID2xx family
The CJ1W-ID@@@ model code follows four positional digits: __2_ = 32-pt density (vs 1_ = 16-pt for ID2_1_, 6_ = 64-pt for ID2_6_); __3_ = MIL connector (vs 1 = removable TB for ID211/ID212, 1 = Fujitsu for ID231/ID261); __1_ = standard (vs 3 = high-speed with 15 us quick-response on inputs 0-7). The ID232 codepoint thus decodes as 32-point standard DC input with MIL connector.
MIL connector vs Fujitsu connector — when to choose ID232
The MIL 40-pin connector on the CJ1W-ID232 follows the MIL-DTL-83503 (formerly MIL-C-83503) flat-ribbon standard — a 40-pin polarized socket with a centerbump polarization key, accepting standard 40-pin flat-ribbon cable assemblies. The Fujitsu FCN-361J040-AU connector on the CJ1W-ID231 (already done) follows the FCN-360 series Japanese standard — similar density but different pin geometry, polarization, and crimp-on sockets. Both connectors are widely available as pre-wired cable assemblies, but the MIL connector is more common in North American installations while the Fujitsu is more common in Asian installations.
Compatibility with input filter and quick-response settings
On a CJ2-series CPU, the CJ1W-ID232 input filter is set in the PLC Setup: 0 / 0.5 / 1 / 2 / 4 / 8 / 16 / 32 ms selectable. The default 8 ms is the right pick for limit-switch, push-button, and E2E-X inductive sensor inputs — those signals have plenty of edge duration. For high-speed inputs (registration-mark detection, encoder Z-pulse, high-speed object counting), the engineer should pick the CJ1W-ID233 (32-pt HIGH-SPEED with MIL connector) instead — it supports 15 us quick-response on inputs 0-7, plus interrupt-input assignment on the CJ2 CPU.
Key Features
- CJ-series 32-point 24 VDC digital input unit
- MIL 40-pin connector on the front face for US-standard flat-ribbon wiring
- Accepts standard 40-pin flat-ribbon cable assemblies
- Compatible with Omron G79-@@@C pre-wired cable assemblies
- Compatible with CJ1M, CJ2M, CJ2H, and NJ-series CPUs
- Bidirectional optocoupler input - NPN sink or PNP source field devices accepted
- 24 VDC rated input
- 5.6 kOhm input impedance, 4.1 mA typical input current at 24 VDC
- SKU: CJ1W-ID232
- Series: CJ1W I/O Basic Units (CJ-series expansion I/O)
- Voltage: 24 VDC
- I/O: 32 I/O
Best-Fit Applications
- 32 limit switches + proximity sensors on a stamping press - each of 8 axes contributes 4 sensors for 32.
- Push-button + selector-switch panel on a CNC machine tool - 32 inputs from 16 push-buttons + 16 selector switches controlling.
- Pneumatic-cylinder position feedback on an assembly line - 32 reed-switch or magnetic-position-sensor inputs, allowing the PLC to verify each cylinder's.
- Encoder-Z and home-position inputs on a multi-axis servo system - 32 inputs from 4 servo axes; for high-speed Z-pulse capture.
Buying Checklist
- Pick CJ1W-ID232 for 32-pt 24 VDC standard input with MIL connector - North American control-panel builders using flat-ribbon cable
- Pick CJ1W-ID231 for 32-pt 24 VDC input with Fujitsu connector - Japanese-style wiring with FCN-361J040-AU
- Pick CJ1W-ID211 for 16-pt 24 VDC input with removable TB - easier field-wiring, lower up-front cost
- Pick CJ1W-ID212 for 16-pt HIGH-SPEED 15 us quick-response input - for registration-mark detection, encoder Z-pulse
- Pick CJ1W-ID233 for 32-pt HIGH-SPEED MIL connector - supports both 15 us quick-response and interrupt-input assignment on CJ2 CPU
- Pick CJ1W-ID262 for 64-pt MIL connector - for very-high-density panels
Technical Specifications
| Model | CJ1W-ID232 |
|---|---|
| Series | CJ1W I/O Basic Units (CJ-series expansion I/O) |
| Type | 32-point 24 VDC digital input unit, MIL connector |
| Input Points | 32 points |
| Common Configuration | 16 points per common (2 commons per unit - word 1 = CH0-15, word 2 = CH16-31) |
| Connector Type | MIL 40-pin socket (per MIL-DTL-83503 / FCN-360M040-AU or compatible); 1 connector per unit |
| Recommended Cable | Standard 40-pin flat-ribbon cable (1.27 mm pitch, per MIL-DTL-83503) or Omron G79-@@@C pre-wired cable assembly |
| Rated Input Voltage | 24 VDC |
| Operating Voltage Range | 20.4 to 26.4 VDC |
| Input Impedance | 5.6 kOhm |
| Input Current (typical at 24 VDC) | 4.1 mA per point |
| ON Voltage / ON Current | 14.4 VDC min / 3 mA min |
| OFF Voltage / OFF Current | 5 VDC max / 1 mA max |
| Interrupt Input Capability | NOT supported (use CJ1W-ID233 for interrupt-input assignment on CJ2 CPU) |
| Internal Current Consumption | 90 mA at 5 VDC (from CJ bus) |
Resources & Downloads
FAQ for CJ1W-ID232
What's the difference between CJ1W-ID232 and CJ1W-ID231?
Both are 32-point 24 VDC standard input units for the CJ-series PLC with the same electrical specifications (4.1 mA per point, 5.6 kOhm impedance, 8 ms ON/OFF filter, 16 pts/common, 2 CIO words, 90 mA bus current). The differences are: (a) Connector type - ID231 uses a Fujitsu FCN-361J040-AU 40-pin connector (Japanese standard), ID232 (this SKU) uses a MIL 40-pin connector per MIL-DTL-83503 (US standard).
Does the CJ1W-ID232 support quick-response inputs on a CJ2 CPU?
No - the CJ1W-ID232 is a standard-speed input unit. Quick-response input (15 us ON / 90 us OFF) and interrupt-input assignment is supported only on the high-speed input units: CJ1W-ID212 (16-pt removable TB, already done), CJ1W-ID233 (32-pt MIL connector), CJ1W-INT01 (legacy 16-pt interrupt-only unit).
What cable assembly do I need for the CJ1W-ID232?
The CJ1W-ID232 accepts a MIL 40-pin connector on the front face (per MIL-DTL-83503, polarized with centerbump). Two cable options: (a) Standard 40-pin flat-ribbon cable - any 1.27 mm pitch 40-conductor flat-ribbon cable with crimp-on sockets (3M 89140 series, Harting, Amphenol). This is the lowest-cost option and works with IDC mass-termination tooling. (b) Omron G79-@@@C pre-wired cable assembly - has the MIL 40-pin connector on one end and free leads on the other for landing on a remote terminal block.
Can I use the CJ1W-ID232 with both NPN and PNP sensors on the same unit?
Yes - the CJ1W-ID232 has 2 separate commons (COM1 for CH0-15, COM2 for CH16-31), each 16-pt group independently polarity-selectable. Wire COM1 to +24 VDC for NPN sensors in the CH0-15 group; wire COM2 to 0 V for PNP sensors in the CH16-31 group. This allows mixed NPN+PNP inputs on the same unit, aligned to 16-pt boundaries. The bidirectional optocoupler inside the ID232 handles the polarity at each COM terminal but does not allow per-point polarity selection within a single group.
