Omron C200HW-PA204S — 30 W AC PSU, 4.6 A 5 VDC, 24 V Service
SKU: C200HW-PA204SUSD 100.00
C200HW-series 30 W AC power supply with 4.6 A at 5 VDC main output and 0.625 A 26 VDC service supply, for the C200HX/HG/HE rack.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron C200HW-PA204S is the 30 W class AC power supply for the C200HX/HG/HE and C200HS PLC backplanes. It takes a free-voltage 100-120 VAC or 200-240 VAC input at 120 VA max and converts it to a 5 VDC backplane rail at 4.6 A (including the CPU module draw) and a separate 26 VDC service supply at 0.625 A. The service rail powers a relay row, a sensor rail, or an indicator stack directly from the rack supply so a panel builder can wire the machine without a separate 24 VDC PSU. The S suffix is the distinguishing feature -- the bare C200HW-PA204 has the same 5 VDC output but no service rail.
The 26 VDC service rail
The 26 VDC output is sized to feed the C200H-CT021 and C200H-CT002 high-speed counter units (which need 0.625 A at 26 VDC) plus a typical 8-to-16-point relay row. The supply is rated 0.3 A continuous and 0.8 A with the +17% / -11% line-voltage compensation -- the 0.8 A figure is the practical budget on a 200-240 VAC line, the 0.3 A figure is the worst-case 100-120 VAC line. Pick the C200HW-PA209R instead when a 5 VDC 9 A / 26 VDC 1.3 A (45 W) PSU is needed for a deeper rack with several high-speed counters.
The PA204 family split
Pick C200HW-PA204C for the 100-240 VAC free-voltage AC input. Pick C200HW-PA204 for the bare 30 W PSU without the service rail. Pick C200HW-PA204R when an external indicator needs the SPST-NO RUN contact (250 VAC 2 A resistive / 24 VDC 2 A resistive). Pick C200HW-PD024 (24 VDC input, 5 VDC 4.6 A) or C200HW-PD025 (24 VDC input, 5 VDC 6 A) when the cabinet has a 24 VDC rail instead of mains. The PA204S slides into the leftmost slot of a C200HW-BC031 (3-slot) / BC051 (5-slot) / BC081 (8-slot) / BC101 (10-slot) CPU backplane.
Before ordering
Confirm the input supply is 100-120 VAC or 200-240 VAC (the bare C200HW-PA204 is 100-120 / 200-240 only -- pick the PA204C for a 100-240 VAC free-voltage cabinet). Confirm the 26 VDC service current budget (0.3 A at 100-120 VAC vs 0.8 A at 200-240 VAC with the +17%/-11% line-voltage compensation). Confirm the existing backplane is a C200HW-BCxx1 (not a C200H-BC031 legacy 3-slot) -- the 10-slot high-output PA209R needs the C200HW-BC101-V1 backplane.
Key Features
- C200HW-series 30 W class AC power supply for the C200HX/HG/HE and C200HS CPU backplanes
- Free-voltage 100-120 VAC or 200-240 VAC input at 120 VA max
- 4.6 A at 5 VDC main output (includes CPU module draw)
- 0.625 A at 26 VDC service supply (0.3 A continuous / 0.8 A with +17%/-11% line compensation)
- Inrush current 15 A max on 100-120 VAC / 30 A max on 200-240 VAC
- Compatible with C200HW-BC031 / BC051 / BC081 / BC101 backplanes
- 0 to 55 C operating / -20 to 75 C storage, 10-90% RH no condensation
- UL 508 / CSA / cUL / CE approved, no corrosive gases allowed
- Dielectric 2,300 VAC 50/60 Hz for 1 min between AC external and GR
- Distinguishing feature vs the bare C200HW-PA204: the 26 VDC service rail
- SKU: C200HW-PA204S
- Series: C200HW (basic power supply, CPU rack)
- Voltage: 100-120 VAC
- I/O: 100 I/O
Best-Fit Applications
- C200HX/HG/HE CPU rack with a C200H-CT021 high-speed counter on the 26 VDC service rail
- Small C200HS or C200H-Alpha machine panel with a relay row on the 26 VDC service rail
- Existing C200H-PS221 cabinet where the bare PA204 needs an upgrade to the 24 V service-rail version
- OEM skid with 8-10 C200H-series I/O slots that needs a 5 VDC + 24 VDC service from one PSU
- Legacy packaging machine where the original PSU is EOL and the PA204S is the documented replacement
Buying Checklist
- Pick C200HW-PA204S for a 30 W AC PSU with the 26 VDC service rail for relay / sensor / counter power.
- Pick C200HW-PA204 instead when the application does not need the 26 VDC service rail and a smaller wire count is fine.
- Pick C200HW-PA204R instead when an external indicator needs the SPST-NO RUN contact (250 VAC 2 A resistive).
- Pick C200HW-PA204C for the 100-240 VAC free-voltage AC input cabinet (single global SKU).
- Pick C200HW-PA209R for a 45 W PSU with 9 A at 5 VDC and 1.3 A at 26 VDC for a deeper rack with several counters.
- Pick C200HW-PD024 or PD025 when the cabinet is fed with 24 VDC instead of mains (4.6 A or 6 A at 5 VDC).
Technical Specifications
| Series | C200HW (basic power supply, CPU rack) |
|---|---|
| Input Voltage | 100-120 VAC or 200-240 VAC, 50/60 Hz free-voltage |
| Voltage Range | 85-132 VAC or 170-264 VAC |
| Power Consumption | 120 VA max |
| Inrush Current | 15 A max (100-120 VAC) / 30 A max (200-240 VAC) |
| Output 5 VDC | 4.6 A (including CPU power) |
| Service Supply 26 VDC | 0.625 A (0.3 A continuous, 0.8 A with +17%/-11% line comp.) |
| RUN Output | Not provided (no contact on the PA204S) |
| Mount | Leftmost slot of C200HW-BC031 / 051 / 081 / 101 backplane |
| Operating Temperature | 0 to 55 C, 10-90% RH no condensation |
| Storage Temperature | -20 to 75 C |
| Approvals | UL 508 / CSA / cUL / CE |
Resources & Downloads
FAQ for C200HW-PA204S
What is the difference between C200HW-PA204, PA204S, and PA204R?
All three are 30 W, 4.6 A at 5 VDC, 100-120 / 200-240 VAC PSUs. The bare C200HW-PA204 has no service rail. The PA204S adds a 0.625 A at 26 VDC service supply for relay / sensor / counter power. The PA204R is the PA204S plus a SPST-NO RUN contact (250 VAC 2 A resistive) for an external RUN indicator. Pick the PA204S for the 26 VDC service rail without the RUN contact; pick the PA204R for the RUN contact without a separate relay module.
What is the 26 VDC service supply on the PA204S used for?
The 26 VDC output feeds the C200H-CT021 and C200H-CT002 high-speed counter units (which need 0.625 A at 26 VDC) and a typical 8-to-16-point relay row. The actual available current is 0.3 A continuous or 0.8 A with the +17%/-11% line-voltage compensation on a 200-240 VAC line. It is the same supply as the older C200H-PS221 and the modern C200HW-PA204S / PA209R -- the only difference is the maximum draw. Pick the PA209R instead for 1.3 A at 26 VDC.
Can I use the PA204S on a 100-240 VAC free-voltage cabinet?
No. The C200HW-PA204S is the split-voltage 100-120 / 200-240 VAC SKU. For a 100-240 VAC free-voltage AC cabinet, pick the C200HW-PA204C (100 VA max, 4.6 A at 5 VDC, 0.625 A at 26 VDC). The PA204C is the right pick for global single-SKU inventory; the PA204S is the regional split-voltage pick for North America / Japan / Europe cabinets fed from a known 100-120 or 200-240 VAC supply.
Does the PA204S work in a C200H or CS1 rack?
Yes, with the right backplane. The PA204S slides into the leftmost slot of any C200HW-BC031 / BC051 / BC081 / BC101 CPU backplane. It also works in a C200H-BC031 / BC051 / BC081 legacy 3/5/8-slot backplane. For a CS1 / CS1D CPU rack, pick the CS1W-PA205R (25 W) or CS1D-PA207R (35 W) instead -- the C200HW PSU does not fit a CS1 / CS1D backplane. For a CJ / CJ2 rack, pick the CJ1W-PA202 / PA205R or CJ1W-PD022 / PD025 instead.
