Part of the Omron CJ-Series PLCs series — see the full model table, lifecycle status and replacement parts.

Omron CJ1W-TC001 — Omron cardboard shipping box on a wooden surface showing the white label TYPE CJ1W-TC001 / TEMPERATURE CONTROL UNIT / VER. / LOT No. / barcode / OMRON Corporation / MADE IN JAPAN / blue OMRON band

Omron CJ1W-TC001 — 4-Loop TC PID Control Unit

SKU: CJ1W-TC001

USD 160.00

Omron CJ1W-TC001 4-loop TC PID control unit for CJ PLCs. 4 inputs + 4 NPN outputs, +/-0.3% accuracy. In stock, datasheet, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CJ1W-TC001 is a 4-loop thermocouple PID temperature control unit for the CJ-series Special I/O bus, manufactured by Omron Corporation. Hengyixin Automation stocks this controller unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

The CJ1W-TC001 carries four thermocouple inputs (R, S, K, J, T, B, L) and four NPN open-collector control outputs in one slim 31 x 90 x 65 mm unit, so a single TC001 can run four independent PID loops from one PLC slot. Sampling cycle is 500 ms per channel; indication accuracy is +/- 0.3% of PV or +/- 1 degree C. Control is ON/OFF or 2-DOF PID with auto-tuning.

The TC001 does NOT include heater burnout detection (HBA) — pick the CJ1W-TC003 for that — and does NOT accept Pt100 RTD inputs — pick the CJ1W-TS562 for Pt100. The TC001 takes two consecutive Special I/O unit numbers on the CJ rack. Programming is in CX-Programmer / CX-Process.

Key Features

  • 4-loop thermocouple PID control unit for CJ-series PLCs, 31 x 90 x 65 mm slim
  • 4 TC inputs (R, S, K, J, T, B, L) + 4 NPN open-collector control outputs in one slot
  • ON/OFF or 2-DOF PID control with auto-tuning, 500 ms sampling cycle per channel
  • No heater burnout detection; thermocouple inputs only (not Pt100 RTD)
  • SKU: CJ1W-TC001
  • Series: Omron CJ-series Special I/O temperature control unit

Best-Fit Applications

  • Four-zone heat-seal jaw control on a vertical-form-fill-seal packaging machine, with one K-type TC per zone and four voltage-pulse outputs driving solid-state relays
  • Four-zone reflow oven control on a small SMT line, with a CJ2H-CPU64-EIP scanning all four loops every 2 s and the TC001 handling the PID math locally
  • Plastic-injection barrel zone control on a 4-zone molding machine (barrel, nozzle, mold, hopper), each zone logged to the DM area for shift-end quality reports

Buying Checklist

  • Pick the CJ1W-TC001 for four thermocouple PID loops on one slim CJ Special I/O slot with NPN control outputs.
  • Pick the CJ1W-TC002 instead when the field-side wiring needs PNP sourcing outputs.
  • Pick the CJ1W-TC003 instead when the panel needs heater burnout detection (HBA) on the same 4-loop TC control unit.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CJ-series Special I/O temperature control unit
Model / SKU CJ1W-TC001
Function 4-loop thermocouple PID temperature control (4 TC inputs + 4 control outputs)
Thermocouple Types R, S, K, J, T, B, L
Sampling Cycle 500 ms per channel
Indication Accuracy +/- 0.3% of PV or +/- 1 degree C, +/- 1 digit max
Control Outputs 4 x NPN open-collector voltage pulse, 100 mA per output at 24 VDC, short-circuit protected
Control Method ON/OFF or 2-DOF PID with auto-tuning, forward / reverse operation
Heater Burnout Detection Not included; use CJ1W-TC003 / TC004 for HBA
Unit Numbers Allocated 2 consecutive Special I/O unit numbers per TC001
Power / Body 24 VDC at 250 mA from 5 VDC backplane; 18-position M3 terminal block; 31 x 90 x 65 mm at approx. 150 g; 0 to +55 C; IP20

FAQ for CJ1W-TC001

What is the Omron CJ1W-TC001?
The Omron CJ1W-TC001 is a 4-loop thermocouple PID temperature control unit for the CJ-series Special I/O bus. It carries four thermocouple inputs (R, S, K, J, T, B, L) and four NPN open-collector control outputs in one slim 31 x 90 x 65 mm unit, so a single TC001 can run four independent PID loops from one PLC slot. Programming is in CX-Programmer / CX-Process.
CJ1W-TC001 vs CJ1W-TC002 — what is the difference?
Output polarity. The CJ1W-TC001 has four NPN (sinking) outputs at 100 mA / 24 VDC. The CJ1W-TC002 has four PNP (sourcing) outputs at the same rating. Both share the same 4 TC inputs, the same 31 x 90 x 65 mm body, and the same PID with auto-tuning. Pick the TC001 for NPN field wiring; pick the TC002 for PNP.
Does the CJ1W-TC001 support heater burnout detection?
No. The CJ1W-TC001 does NOT include heater burnout detection (HBA). Pick the CJ1W-TC003 for PID control with HBA. The TC001 is for straight ON/OFF or 2-DOF PID with auto-tuning only, no current-transformer input.
