Omron CJ1W-TC002 — front view of the CJ1 unit showing the Omron model label, the four green input channel LEDs, the four red output channel LEDs, the DIP switch for thermocouple type and the removable M3 screw terminal block

Omron CJ1W-TC002 — 4-Loop Thermocouple Input, PNP

SKU: CJ1W-TC002

USD 160.00

CJ1 4-loop temperature control, R/S/K/J/T/L/B thermocouple, PNP pulse output, CX-Programmer. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CJ1W-TC002 is a 4-loop temperature control unit for the CJ1, CJ2 and NJ-series PLCs It is manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

Each loop accepts a type R, S, K, J, T, L or B thermocouple. The unit runs ON/OFF or 2-degree-of-freedom PID with auto-tune, switchable per loop.

For a CP-series 4-input thermocouple sensor module without PID, use the CP1W-TS102. Key specs: I/O System CJ CPU Bus or CJ Expansion Rack (Special I/O); Number of Loops 4; Temperature Sensor Thermocouple: R, S, K, J, T, L, B; Control Outputs 4 PNP voltage pulse, 100 mA at 24 VDC max; Control Method ON/OFF or 2-DOF PID with auto-tune; Indication Accuracy +/- 0.3% of PV or +/- 1 degC, plus 1 digit; RUN / STOP Control From CPU via Special I/O area bits; Internal Current 250 mA max at 5 VDC.

Key Features

  • CJ1 Special I/O 4-loop temperature control unit, thermocouple R/S/K/J/T/L/B inputs
  • 4 PNP voltage-pulse outputs, 100 mA at 24 VDC, ON/OFF or 2-DOF PID with auto-tune
  • Indication accuracy +/- 0.3% of PV or +/- 1 degC plus 1 digit
  • 31 x 90 x 89 mm, 250 mA at 5 VDC, RUN / STOP from CPU
  • SKU: CJ1W-TC002
  • Series: Omron CJ1W-series Special I/O temperature control unit

Best-Fit Applications

  • Four-zone plastic extruder barrel where the PID auto-tune trims each heater band to a stable melt temperature without operator intervention
  • Packaging line heat-seal station where 4 PNP pulse outputs drive solid-state relays and the heater-burnout detection flags a failed SSR
  • Spare replacement on a CJ2M-CPU33 cell where the original 4-loop thermocouple board failed and the CX-Programmer project loads the same Special I/O bits

Buying Checklist

  • Pick the CJ1W-TC002 for 4 thermocouple loops with PNP pulse outputs on a CJ1 Special I/O slot.
  • Pick the CJ1W-TC102 instead when the panel needs 4 thermocouple loops with NPN (sinking) pulse outputs.
  • Pick the CJ1W-TC001 instead when the application needs only 2 loops on the same CJ1 Special I/O footprint.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CJ1W-series Special I/O temperature control unit
Model / SKU CJ1W-TC002
I/O System CJ CPU Bus or CJ Expansion Rack (Special I/O)
Number of Loops 4
Temperature Sensor Thermocouple: R, S, K, J, T, L, B
Control Outputs 4 PNP voltage pulse, 100 mA at 24 VDC max
Control Method ON/OFF or 2-DOF PID with auto-tune
Indication Accuracy +/- 0.3% of PV or +/- 1 degC, plus 1 digit
RUN / STOP Control From CPU via Special I/O area bits
Internal Current 250 mA max at 5 VDC
Dimensions (W x H x D) 31 × 90 × 89 mm; 200 g

Manufacturer documentation

Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.

FAQ for CJ1W-TC002

Does the CJ1W-TC002 support Pt100 RTD inputs?
No. The TC002 is thermocouple only (R, S, K, J, T, L, B). For Pt100 or JPt100 RTD inputs on the same 4-loop body, use the CJ1W-TC003.
What PLC programs the CJ1W-TC002?
CX-Programmer under the CX-One suite. The unit exchanges 20 words of constant data plus 90 words of regular data with the CPU in the Special I/O area (CIO 2000 to CIO 2959). Set points, RUN / STOP, AT and alarm values are written from the CPU; PV, SP, status and heater current are read back.
How is the CJ1W-TC002 different from a CP1W-TS003?
The CP1W-TS003 is a CP-series temperature sensor unit that only converts temperature to a 16-bit binary value, with no PID loop. The CJ1W-TC002 is a Special I/O unit that runs full PID control and auto-tune, and requires a CJ CPU rack.
Can the CJ1W-TC002 do heat-cool control?
Yes. The unit supports forward (heat) or reverse (cool) operation, set per loop with the DIP switch on the front of the unit. Heat-cool uses two of the PNP outputs per loop.
