Omron CK3E-1310 — Multi-Axis Controller, 16 Axes
SKU: CK3E-1310USD 2100.00
Omron CK3E-1310 Programmable Multi-Axis Controller, 16 EtherCAT axes, 250 us period, 1 GB RAM, Power PMAC IDE.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CK3E-1310 is a 16-axis Programmable Multi-Axis Controller for CNC and high-end motion systems, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
The unit runs Power PMAC firmware on 1 GB RAM and 2 GB flash. It serves as an EtherCAT master, issuing motion commands at a 250 us period. Programming runs in Power PMAC IDE; the free EC Engineer tool handles EtherCAT network setup.
The slim 28.6 mm-wide body has one RJ45 EtherCAT, one RJ45 Ethernet, one USB 3.0 host, and a 24 VDC power input. The 125 x 170.9 x 28.6 mm DIN-rail unit weighs 700 g and runs from 0 to 45 degC. The CK3W-CAX003A axis interface unit pairs with this controller for additional I/O. Related 8-axis and 16-axis controllers on the CK3M platform are the CK3M-CPU101 and CK3M-CPU111.
Key Features
- CK3E Programmable Multi-Axis Controller with Power PMAC firmware, 16 EtherCAT axes
- 1 GB main memory, 2 GB flash, 250 us motion control period
- 1 x RJ45 EtherCAT (100 Mbps), 1 x RJ45 Ethernet, 1 x USB 3.0 host
- 24 VDC 660 mA supply, 28.6 mm wide DIN-rail body, Power PMAC IDE software
- SKU: CK3E-1310
- Series: Omron SYSMAC CK3E Programmable Multi-Axis Controller
- Voltage: 24 VDC
Best-Fit Applications
- Five-axis CNC machining centre where the 16 axes run coordinated tool paths and the 250 us period keeps interpolation smooth on complex contours
- High-speed semiconductor wafer-handling robot where the slim 28.6 mm body fits a cleanroom cabinet and the EtherCAT master drives 12 servo axes
- Spare drop-in on a CK3E retrofit where the existing Power PMAC IDE project loads over Ethernet and the EtherCAT node map carries over
Buying Checklist
- Pick the CK3E-1310 for a 16-axis EtherCAT multi-axis controller with Power PMAC and a 28.6 mm slim body.
- Pick the CK3M-CPU101 instead when the application needs 8 axes on a related multi-axis platform with a different CPU block.
- Pick the CK3M-CPU111 instead when the cell needs a 16-axis controller on the related CK3M platform.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron SYSMAC CK3E Programmable Multi-Axis Controller |
| Model / SKU | CK3E-1310 |
| Maximum Controlled Axes | 16 axes via EtherCAT |
| Motion Control Period | 250 us or more |
| Memory | 1 GB main memory; 2 GB flash (firmware 2.8+) |
| Communication Ports | 1 x RJ45 EtherCAT master (100 Mbps), 1 x RJ45 Ethernet (1 Gbps / 100 Mbps), 1 x USB 3.0 host Type A |
| EtherCAT Slaves | Up to 32 slaves; node address 1 to 32 |
| Supply Voltage | 24 VDC (20.4 to 26.4 VDC), 660 mA max |
| Operating Temperature | 0 to 45 degC; storage -25 to +70 degC |
| Standards | IEC 60068-2-6 vibration, IEC 60068-2-27 shock (147 m/s2), EN 61326, UL, KC, RCM |
| Dimensions / Weight | 125 (H) x 28.6 (D) x 170.9 (W) mm; 700 g |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for CK3E-1310
What software programs the CK3E-1310?
Power PMAC IDE for motion programs, EC Engineer (free) for the EtherCAT network, and Power PMAC NC16 SDK / Runtime for the HMI screen. Use Power PMAC IDE version 4.1 or later for CK3E firmware 2.4 and above.
Does the CK3E-1310 support EtherCAT slaves from other vendors?
Yes. The CK3E-1310 acts as a standard EtherCAT master and accepts any CiA 402-compliant servo drive or I/O block. Omron 1S-series, G5-series and 3G3MX2 drives are verified to work via the standard ESI files.
How is the CK3E-1310 different from an NJ501-1500?
The NJ501-1500 is a machine automation controller with a built-in PLC scan and up to 64 axes via EtherCAT, programmed in Sysmac Studio. The CK3E-1310 is a pure motion controller programmed in Power PMAC, ideal for CNC, complex kinematics and high-speed contouring where the NJ scan time is too slow.
Can the CK3E-1310 pair with a CJ2 PLC?
Yes. The CK3E-1310 can be the EtherCAT master for 16 axes while a CJ2 PLC handles the rest of the machine logic. The two exchange data over Ethernet or via an NX-ECC201 EtherCAT coupler with a CJ1W-NC413 position-control module.
