Omron CK3M-CPU111 — CK3M Motion CPU, 4 Axes
SKU: CK3M-CPU111USD 1340.00
Omron CK3M-CPU111 CK3M motion controller CPU, 4 EtherCAT axes, 1 GHz dual core, 1 GB RAM. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CK3M-CPU111 is a programmable multi-axis motion controller CPU from the CK3M series, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
The CPU ships with 1 GB of RAM and 1 GB of built-in flash on a dual-core 1 GHz processor. Two Ethernet sockets expose one EtherCAT port for up to 4 servo axes and one EtherNet/IP port for upstream controllers and HMIs. Up to four CK3W-AX axis interface units chain on the right side for analog or pulse encoder feedback.
Servo cycle runs down to 25 microseconds across 5 axes for high-precision machining and nano-scale control. Programming is in Power PMAC IDE using PMAC motion language and standard IEC 61131-3 languages. The CK3M-CPU101 sibling drops EtherCAT for sequence-only use; the CK3M-CPU121 extends to 8 servo axes for larger machines.
Key Features
- CK3M multi-axis motion controller CPU, 1 GB RAM / 1 GB flash, dual-core 1 GHz processor
- 1 EtherCAT port (RJ45) for up to 4 servo axes + 1 EtherNet/IP port (RJ45) for upstream PLC / HMI
- Up to 4 CK3W-AX axis interface units chain on the right for analog / pulse encoder feedback
- 25 us / 5 axes servo cycle, Power PMAC IDE programming, IEC 61131-3 compatible
- SKU: CK3M-CPU111
- Series: Omron CK3M-series programmable multi-axis motion controller
- Voltage: 24 VDC
Best-Fit Applications
- High-precision CNC milling retrofit where 4 EtherCAT servos drive X / Y / Z and spindle axes with 25 us servo cycle for surface finish control
- Multi-axis packaging machine where the CK3M runs synchronized cutting, sealing and film-feed motion alongside a host NJ/NX PLC over EtherNet/IP
- Spare replacement on a wire-bonding or pick-and-place tool where the existing CK3M-CPU101 must be upgraded to add EtherCAT servo axes
Buying Checklist
- Pick the CK3M-CPU111 for a CK3M motion controller with 4 EtherCAT servo axes and built-in EtherCAT + EtherNet/IP on one body.
- Pick the CK3M-CPU101 instead when the cell needs sequence control only and no EtherCAT servo motion.
- Pick the CK3M-CPU121 instead when the machine needs 8 or more servo axes for a larger press or converting line.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron CK3M-series programmable multi-axis motion controller |
| Model / SKU | CK3M-CPU111 |
| Processor | Dual-core 1 GHz |
| Memory | 1 GB RAM, 1 GB built-in flash |
| Motion Control | Up to 4 EtherCAT servo axes, 25 us / 5 axes servo cycle |
| Communication | 1 EtherCAT port (RJ45, DC sync), 1 EtherNet/IP port (RJ45), USB 2.0 for external storage |
| Axis Interface Units | Up to 2 CK3W-AX[] units (CK3W-AX1515N analog, CK3W-AX1515P pulse) |
| Expansion | Up to 8 CK3W-EX units via CK3W-EXM01 master and CK3W-EXS02 slaves, plus CK3W-MD7110 high-speed analog I/O |
| Programming | Power PMAC IDE (PMAC motion language + IEC 61131-3 ladder / structured text / function block) |
| Power Supply | 24 VDC -15% to +20% (20.4 to 28.8 VDC), D-class grounding |
| Environment / Mounting | 0 to 55 C, 10 to 95% RH non-condensing, panel-mount, IP20, end cover CK3W-TER11 required |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for CK3M-CPU111
What is the Omron CK3M-CPU111 used for?
It is a multi-axis motion controller CPU for high-precision machines like CNC, packaging, and converting equipment. Four EtherCAT servo axes run on a 25 us / 5 axes cycle, with Power PMAC IDE for motion programming.
Does the CK3M-CPU111 have EtherNet/IP?
Yes. One EtherNet/IP port sits alongside the EtherCAT port for upstream NJ / NX PLCs, NA HMIs, and SCADA. EtherNet/IP and EtherCAT are two separate RJ45 sockets on the front.
CK3M-CPU111 vs CK3M-CPU101 - what is the difference?
The CK3M-CPU111 adds an EtherCAT port for up to 4 servo axes. The CK3M-CPU101 has no EtherCAT and is for I/O and sequence control only. Memory, processor, and EtherNet/IP port are identical between the two.
How many CK3W-AX axis interface units can the CK3M-CPU111 hold?
Up to 2 CK3W-AX[] units chain on the right side, ending with a CK3W-TER11 cover. The CK3W-AX1515N adds 4 analog inputs, the CK3W-AX1515P adds 4 pulse encoder inputs.
What software programs the CK3M-CPU111?
Power PMAC IDE, Omron's PMAC-based motion development environment. It supports the PMAC motion scripting language plus standard IEC 61131-3 languages (ladder, structured text, function block) for sequence logic.
