Omron CK3W-EXS02 — CK3M Expansion Slave Unit
SKU: CK3W-EXS02USD 268.00
Omron CK3W-EXS02 CK3M-series expansion slave unit, 31.6 mm wide, bus-powered over CK3W-CAX003A from EXM01. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CK3W-EXS02 is the expansion slave unit for the CK3M-series programmable multi-axis controller, manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
The unit mounts on the second rack, to the right of the first axis-interface or I/O module. It receives backplane power and expansion signals from the CK3W-EXM01 master on the first rack over the CK3W-CAX003A 0.3 m cable. The end cover is included.
Power consumption is 5 V 0.2 W max, drawn from the EXM01 over the cable; no separate supply is needed. Body is 90 (H) x 80 (D) x 31.6 (W) mm, 130 g with the end cover. Ambient 0 to +55 degC, 10 to 95 percent RH. Approvals: cULus, EU EN 61326, RCM, KC. Use one CK3W-EXM01 + one CK3W-EXS02 per second rack.
Key Features
- Expansion slave unit for the CK3M second rack
- Receives power and bus signals from the CK3W-EXM01 over the CK3W-CAX003A cable
- 5 V 0.2 W bus-powered, no separate supply
- 90 x 80 x 31.6 mm DIN-rail block, 130 g with end cover, 0 to +55 degC
- SKU: CK3W-EXS02
- Series: Omron CK3M-series programmable multi-axis controller (CK3W expansion)
Best-Fit Applications
- Second-rack slave on a 12-axis machine where the EXS02 sits at the start of rack 2 and the extra axes hang off it
- Modular cabinet retrofit where the original 8-axis machine grows and the EXS02 takes the new axis-interface modules without replacing the existing CPU
- Spare replacement on a CK3M retrofit where the original EXS02 failed and the new unit drops onto the same DIN rail and CK3W-CAX003A cable
Buying Checklist
- Pick the CK3W-EXS02 for the expansion slave unit on the CK3M second rack when an EXM01 is already on rack 1.
- Pick the CK3W-EXM01 instead when no second rack exists and the master on rack 1 is what is needed.
- Pick the CK3M-CPU111 instead when the application needs 8 axes on a single rack without expansion.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron CK3M-series programmable multi-axis controller (CK3W expansion) |
| Model / SKU | CK3W-EXS02 |
| Function | Expansion slave unit for the second rack |
| Compatible Master | CK3W-EXM01 on the first rack |
| Connection Cable | CK3W-CAX003A 0.3 m (sold separately) |
| Power Consumption | 5 V 0.2 W max (bus-powered) |
| Mounting | DIN rail, 35 mm track, far left of rack 2 |
| Vibration / Shock | IEC 60068-2-6 9.8 m/s2 / IEC 60068-2-27 147 m/s2 |
| Approvals | cULus, EU EN 61326, RCM, KC |
| End Cover | Included with the unit |
| Dimensions / Weight | 90 (H) x 80 (D) x 31.6 (W) mm; 130 g with end cover |
FAQ for CK3W-EXS02
Does the CK3W-EXS02 need its own power supply?
No. The unit is bus-powered from the CK3W-EXM01 on rack 1 through the CK3W-CAX003A expansion cable. 5 V 0.2 W max is the only power it draws.
Can two CK3W-EXS02 slaves sit on the same rack?
No. The CK3W-EXM01 master drives exactly one CK3W-EXS02 slave. For more than two racks, use the NX-series PLC + NX-EIC202 coupler topology.
Is the end cover included with the CK3W-EXS02?
Yes. The CK3W-EXS02 ships with the end cover (CK3W-TER11 or equivalent) already mounted on the right side. The CK3W-EXM01 ships without an end cover; one must be ordered separately.
Can the CK3W-EXS02 be used with a CK5M CPU?
No. The CK3W-EXS02 pairs only with the CK3W-EXM01 master on a CK3M-series CPU. For the CK5M platform, use the CK5W-EXS01 expansion slave.
