Omron CK3W-EXM01 — CK3M Expansion Master Unit
SKU: CK3W-EXM01USD 262.00
Omron CK3W-EXM01 CK3M-series expansion master unit, 31.6 mm wide, bus-powered, links to one CK3W-EXS02. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CK3W-EXM01 is the expansion master unit for the CK3M-series programmable multi-axis controller, manufactured by Omron Corporation. Hengyixin Automation stocks this I/O expansion unit in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
The unit sits to the right of the CK3M-CPU101 CPU on the first rack. It connects over a CK3W-CAX003A 0.3 m cable to one CK3W-EXS02 expansion slave unit on the second rack, extending the system to a second row of axis-interface and digital I/O modules.
Power consumption is 5 V 0.4 W max, drawn from the CK bus; no separate supply is needed. Body is 90 (H) x 80 (D) x 31.6 (W) mm, 100 g. Ambient 0 to +55 degC, 10 to 95 percent RH. Vibration IEC 60068-2-6 9.8 m/s2; shock IEC 60068-2-27 147 m/s2. Approvals: cULus, EU EN 61326, RCM, KC. Pair with the CK3W-PD048 24 VDC power supply on the first rack.
Key Features
- Expansion master unit for CK3M-series multi-axis controller
- Connects over CK3W-CAX003A 0.3 m cable to one CK3W-EXS02 slave on rack 2
- 5 V 0.4 W bus-powered, no separate supply
- 90 x 80 x 31.6 mm DIN-rail block, 100 g, 0 to +55 degC
- SKU: CK3W-EXM01
- Series: Omron CK3M-series programmable multi-axis controller (CK3W expansion)
Best-Fit Applications
- Second rack on a 12-axis machine where the EXM01 sits on rack 1 and the EXS02 takes the second row of axis-interface modules
- Modular cabinet retrofit where the original 8-axis machine grows to 16 axes and the EXM01 adds the second row of axes
- Spare replacement on a CK3M retrofit where the original EXM01 failed and the new unit drops onto the same DIN rail and CK3W-CAX003A cable
Buying Checklist
- Pick the CK3W-EXM01 for the expansion master unit on the CK3M first rack when a second row of axes is needed.
- Pick the CK3W-EXS02 as the matching slave on the second rack when the EXM01 is already installed.
- Pick the CK3M-CPU101 instead when no second rack is needed and the CPU sits alone on the backplane.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron CK3M-series programmable multi-axis controller (CK3W expansion) |
| Model / SKU | CK3W-EXM01 |
| Function | Expansion master unit for the second rack |
| Compatible CPUs | CK3M-CPU101, CK3M-CPU111, CK3M-CPU121 |
| Connection to Slave | CK3W-CAX003A 0.3 m expansion cable |
| Power Consumption | 5 V 0.4 W max (bus-powered) |
| Required Power Supply | CK3W-PD048 on the first rack |
| Mounting | DIN rail, 35 mm track, behind the CPU on rack 1 |
| Vibration / Shock | IEC 60068-2-6 9.8 m/s2 / IEC 60068-2-27 147 m/s2 |
| Approvals | cULus, EU EN 61326, RCM, KC |
| Dimensions / Weight | 90 (H) x 80 (D) x 31.6 (W) mm; 100 g |
FAQ for CK3W-EXM01
Does the CK3W-EXM01 need its own power supply?
No. The unit is bus-powered from the CK3W-PD048 supply on the first rack through the backplane connector. 5 V 0.4 W max is the only power it draws.
How many slaves can the CK3W-EXM01 drive?
One. The CK3W-EXM01 supports exactly one CK3W-EXS02 expansion slave unit. For more than two racks, step up to the NX-series PLC + NX-EIC202 coupler topology.
What cable connects the EXM01 to the EXS02?
The CK3W-CAX003A 0.3 m expansion cable, included separately. The cable carries the backplane expansion signals; it is not a network cable.
