Part of the Omron CP-Series Compact PLCs series — see the full model table, lifecycle status and replacement parts.

Omron CP1E-N30DT-D — front view of the CP1E-N CPU showing the Omron model label, the green PWR LED, the green RUN LED, the red ERR LED, the input-output LED row, the USB slave connector and the RS-232C DB9 port

Omron CP1E-N30DT-D — CP1E-N PLC, 30 I/O, 24 VDC, NPN

SKU: CP1E-N30DT-D

USD 132.00

CP1E-N compact PLC, 18 inputs / 12 NPN outputs, 24 VDC, RS-232C + USB, 8K + 8K. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CP1E-N30DT-D is the 30-I/O network-capable model of the CP1E-N compact PLC family It is manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

The CPU carries 18 DC inputs and 12 NPN (sinking) transistor outputs. Supply is 24 VDC, 20.4 to 26.4 V allowable, 20 W max.

For the relay-output version on the same body, use the CP1E-N30DR-A. Key specs: Built-in I/O 18 DC inputs, 12 NPN transistor outputs; Power Supply 24 VDC, 20.4 to 26.4 VDC allowable, 20 W max; Program Memory 8K steps; Data Memory 8K words, battery-free (optional CP1W-BAT01); Instruction Execution 1.19 us basic LD; High-Speed Counters 6 inputs at 100 kHz; Pulse Outputs 2 outputs at 100 kHz; Communication RS-232C + USB on body, option slot for RS-485 / Ethernet.

Key Features

  • CP1E-N compact PLC, 18 DC inputs / 12 NPN transistor outputs
  • 24 VDC supply, 8K steps program, 8K words data, battery-free
  • 6 high-speed counters at 100 kHz, 2 pulse outputs at 100 kHz, real-time clock
  • RS-232C + USB on the body, option slot for RS-485 or Ethernet, 150 max I/O
  • SKU: CP1E-N30DT-D
  • Series: Omron CP1E-N compact PLC
  • Voltage: 24 VDC
  • I/O: 18 I/O

Best-Fit Applications

  • Small conveyor cell where the 30-I/O count covers sensors and solenoids and the RS-232C talks to a barcode reader
  • Indexing machine where the 2-axis 100 kHz pulse output drives stepper drives through the built-in NPN outputs
  • Spare drop-in on a CP1E panel where the original PLC failed and the new CPU takes the same wiring and project

Buying Checklist

  • Pick the CP1E-N30DT-D for a CP1E-N compact PLC with 18 inputs / 12 NPN transistor outputs on a 24 VDC supply.
  • Pick the CP1E-N30DR-A instead when the panel needs relay outputs on the same 30-I/O CP1E-N body.
  • Pick the CP1E-NA20DR-A instead when the application adds 2 analog inputs and the rack needs only 20 I/O.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CP1E-N compact PLC
Model / SKU CP1E-N30DT-D
Built-in I/O 18 DC inputs, 12 NPN transistor outputs
Power Supply 24 VDC, 20.4 to 26.4 VDC allowable, 20 W max
Program Memory 8K steps
Data Memory 8K words, battery-free (optional CP1W-BAT01)
Instruction Execution 1.19 us basic LD
High-Speed Counters 6 inputs at 100 kHz
Pulse Outputs 2 outputs at 100 kHz
Communication RS-232C + USB on body, option slot for RS-485 / Ethernet
Operating Temperature 0 to 55 degC, DIN rail, 130 x 90 x 85 mm, 500 g

FAQ for CP1E-N30DT-D

What is the difference between CP1E-N and CP1E-E?
The CP1E-N is the network-capable model with a USB port, RS-232C port and an option-board slot for RS-485 or Ethernet. The CP1E-E is the basic model with USB only. The N model is the right pick when the application needs serial or Ethernet communication.
How many CP1W expansion units can I add?
Up to three CP1W Expansion I/O Units, taking the rack to 150 I/O points total. Compatible expansion units include CP1W-8ED / 16ED / 32ED inputs, CP1W-8ER / 16ER / 32ER outputs, the CP1W-AD analog inputs, CP1W-DA analog outputs and CP1W-TS temperature sensor units.
Does the CP1E-N30DT-D have Ethernet?
Not on the body. Add a CP1W-CIF41 Ethernet option board in the option slot for one RJ45 port, or step up to a CP2E-N CPU for built-in two-port Ethernet switching.
What software programs the CP1E-N30DT-D?
CX-Programmer under CX-One or CX-One Lite. The project file is forward-compatible across the CP1E-N family; switching to a 40-I/O or 60-I/O CPU on the same platform needs no project changes.
