Omron E2B-M12KS04-WZ-B1 2M — three black M12 inductive sensors with the threaded brass housing, the yellow operation LED on the back cap and the 2 m PVC pre-wired cable coiled next to each sensor on a wood surface

Omron E2B-M12KS04-WZ-B1 2M — M12 Inductive, 4 mm, PNP

SKU: E2B-M12KS04-WZ-B1 2M

USD 7.55

Omron E2B-M12KS04-WZ-B1 2M M12 shielded inductive sensor, 4 mm, PNP NO, 12-24 VDC, 2 m cable. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron E2B-M12KS04-WZ-B1 2M is an M12 shielded inductive proximity sensor from the E2B family, manufactured by Omron Corporation. Hengyixin Automation ships this sensor from our Xiamen warehouse with a 30-day DOA return window and a datasheet PDF included in the box.

The sensor detects ferrous metal at 4 mm with a quasi-flush shielded mounting. It runs from 10 to 30 VDC (12 to 24 VDC nominal), draws 10 mA or less, and outputs PNP open-collector up to 200 mA. Response frequency is 800 Hz and the action is NO - the output turns ON when the target approaches. A yellow operation LED sits on the housing.

The housing is nickel-plated brass with a PBT sensing face and a 2 m PVC pre-wired cable. IP67 protection and -25 to 70 C operating range cover typical washdown and shop-floor conditions. Built-in protections cover output reverse polarity, supply reverse polarity, surge suppressor, and short circuit. The E2B-M12KS04-WZ-C1 2M is the NPN sibling.

Key Features

  • M12 shielded short-body inductive proximity sensor, 4 mm sensing distance, quasi-flush mounting
  • PNP open-collector NO output, 200 mA load, 800 Hz response, yellow operation LED
  • 10 to 30 VDC supply (12-24 VDC nominal), 10 mA max current consumption, surge / short-circuit / reverse-polarity protection
  • IP67 housing, nickel-plated brass + PBT sensing face, pre-wired 2 m PVC cable, -25 to +70 C operating
  • SKU: E2B-M12KS04-WZ-B1 2M
  • Series: Omron E2B M12 inductive proximity family
  • Voltage: 10 TO 30 VDC

Best-Fit Applications

  • End-of-stroke check on a packaging slide where the 4 mm shielded M12 fits a tight boss and the PNP output drives a CP1L DC input
  • Presence detection on a small parts feeder where the yellow LED confirms trigger state at commissioning and the 800 Hz catches each cycle
  • Cylinder-home check on a pneumatic pick-and-place where the 12-24 VDC sensor plugs into a standard input and the IP67 body tolerates oil mist

Buying Checklist

  • Pick the E2B-M12KS04-WZ-B1 2M for an M12 shielded 4 mm PNP NO inductive sensor with a 2 m pre-wired cable.
  • Pick the E2B-M12KS04-WZ-C1 2M instead when the cabinet needs NPN output instead of PNP.
  • Pick the E2B-M12KS04-M1-B1 2M instead when the sensor needs an M12 4-pin connector instead of a pre-wired pigtail.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron E2B M12 inductive proximity family
Model / SKU E2B-M12KS04-WZ-B1 2M
Size / Mounting M12 threaded, shielded short body, flush-mountable
Sensing Distance 4 mm +/- 10%, set distance 0 to 3.2 mm
Output Type PNP open collector, NO (B1 suffix)
Load Current 200 mA max at 30 VDC max, residual 2 V max
Response Frequency 800 Hz average
Supply Voltage 10 to 30 VDC (12-24 VDC nominal), ripple 10% max, 10 mA max current
Protection Output reverse polarity, supply reverse polarity, surge suppressor, short circuit
Connection Pre-wired 2 m PVC cable (diameter 4 mm)
Protection / Environment IP67, -25 to +70 C operating, 35 to 95% RH

FAQ for E2B-M12KS04-WZ-B1 2M

What is the E2B-M12KS04-WZ-B1 2M output type?
PNP open collector, normally open. The B in E2B-M12KS04-WZ-B1 2M is PNP; the C variant is NPN. The 1 in B1 is normally open; B2 is normally closed.
What is the sensing distance of the E2B-M12KS04-WZ-B1 2M?
4 mm on mild steel (12 x 12 x 1 mm reference target) with a +/- 10% tolerance. Set the operating distance to 0 to 3.2 mm for reliable operation across the production tolerance band.
Does the E2B-M12KS04-WZ-B1 2M work with a CP1L DC input?
Yes. The PNP output sources 24 VDC into a CP1L DC input card configured for sinking inputs. For NPN outputs driving the same card, pick the E2B-M12KS04-WZ-C1 2M.
What cable does the E2B-M12KS04-WZ-B1 2M ship with?
A 2 m PVC pre-wired standard cable with 4 mm outer diameter. The 5 m version has the suffix 5M; the M12 4-pin connector version has the suffix -M1.
Is the E2B-M12KS04-WZ-B1 2M IP67 rated?
Yes. The housing is rated IP67 per IEC 60529 and EMC EN 60947-5-2. Operating range is -25 to +70 C and humidity 35 to 95%.
