Omron E3ZM-R81 — Retro-Reflective Sensor, 4 m, PNP
SKU: E3ZM-R81USD 130.00
Omron E3ZM-R81 stainless steel retro-reflective sensor with MSR, 4 m range, polarized red LED, PNP, IP67/IP69K. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron E3ZM-R81 is a compact stainless steel retro-reflective photoelectric sensor with MSR function, manufactured by Omron Corporation. Hengyixin Automation ships this sensor from our Xiamen warehouse with a 30-day DOA return window and a datasheet PDF included in the box.
Sensing distance is 4 m with the E39-R1S reflector and 100 mm minimum between sensor and reflector. The light source is a polarized red LED at 660 nm so the sensor ignores light reflected off shiny surfaces. Output is PNP open-collector, Light-ON or Dark-ON selectable by switch, 100 mA max load. Response time is 1 ms.
Supply is 10 to 30 VDC at 25 mA max. The housing is SUS316L stainless steel with IP67 and DIN 40050-9 IP69K protection, suited to wash-down food lines. Body is 10.8 x 32.2 x 21 mm, 90 g pre-wired. For the same 4 m range in the E3Z plastic housing, pick the E3Z-R81.
Key Features
- Compact retro-reflective sensor with MSR function, polarized red LED 660 nm, 4 m range
- PNP open-collector output, Light-ON / Dark-ON selectable, 100 mA max load, 1 ms response
- SUS316L stainless steel housing, IP67 and DIN 40050-9 IP69K rated for wash-down lines
- 10-30 VDC supply, 25 mA max current, 10.8 x 32.2 x 21 mm, 90 g pre-wired
- SKU: E3ZM-R81
- Series: Omron E3ZM compact stainless steel photoelectric
- Voltage: 10 TO 30 VDC
Best-Fit Applications
- Bottle detection on a beverage conveyor where shiny PET bottles would confuse a non-polarized sensor
- Carton presence check at the out-feed of a case packer with an E39-R1S reflector mounted on the far rail
- Trigger for a fill-and-cap machine on a wash-down dairy line where the IP69K rating matters
Buying Checklist
- Pick the E3ZM-R81 for a PNP, 4 m, polarized red LED retro-reflective sensor in a stainless body.
- Pick the E3ZM-R61 instead when the cabinet is wired NPN and the same 4 m range and IP69K rating are needed.
- Pick the E3Z-R81 instead when the line is dry and a plastic-body E3Z sensor at lower cost is acceptable.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron E3ZM compact stainless steel photoelectric |
| Model / SKU | E3ZM-R81 |
| Sensing Method | Retro-reflective with MSR (mirror surface rejection) |
| Light Source | Polarized red LED, 660 nm |
| Sensing Distance | 4 m (with E39-R1S reflector); 100 mm minimum distance |
| Standard Object | Opaque, 75 mm diameter minimum |
| Output Type | PNP open-collector, Light-ON / Dark-ON switch selectable |
| Load Current | 100 mA max, residual voltage 2 V max |
| Response Time | 1 ms operate or reset |
| Supply Voltage | 10 to 30 VDC including 10% ripple |
| Protection / Material | IP67, IP69K; SUS316L housing; -25 to 55 degC operating |
FAQ for E3ZM-R81
Does the E3ZM-R81 need a reflector?
Yes. Retro-reflective sensors read light bounced back from a reflector, not from the target. The matching reflector for 4 m range is the E39-R1S (40 x 60 x 7.5 mm); the smaller E39-R3 fits tighter mounts.
Can the E3ZM-R81 ignore reflections from shiny surfaces?
Yes. The MSR function uses a polarized red LED and a matched polarizer in the receiver, so light bouncing off a shiny PET bottle or a stainless panel is rejected. The target still needs to break the beam to the reflector.
What is the minimum object size for the E3ZM-R81?
75 mm diameter opaque object. Smaller targets may not break the beam cleanly, especially at the far end of the 4 m range. Test on the actual line before committing.
