Omron FJ-S2MG — front face of the 2 MP monochrome CCD camera showing the C-mount lens flange, the global shutter window, the Gigabit Ethernet PoE port and the 6-pin power / I/O connector

Omron FJ-S2MG — 2 MP Monochrome CCD GigE Camera

SKU: FJ-S2MG

USD 248.00

2 MP monochrome CCD GigE vision camera, 1624 x 1234, 20 fps, C-mount, PoE. In stock, China.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron FJ-S2MG is an FJ-series 2 MP monochrome CCD camera for PC vision systems It is manufactured by Omron Corporation. Hengyixin Automation ships this sensor from our Xiamen warehouse with a 30-day DOA return window and a datasheet PDF included in the box.

Effective pixels are 1626 (H) x 1236 (V) on a 1/1.8-inch progressive-scan CCD. Frame rate is 20 fps at full resolution.

Pair with the FZ-LES3 lens and an NJ501-1300 controller. Key specs: Image Element 1/1.8-inch progressive-scan CCD, monochrome; Effective Pixels 1626 (H) x 1236 (V) (approx 2 MP); pixel size 4.4 (um) x 4.4 (um); Frame Rate 20 fps at full frame; 2 to 1236 lines selectable; Shutter Speed 25 us to 1 s; gain 0 dB to +18 dB; Trigger External or software trigger (Ethernet); strobe or trigger READY output (software-configurable); Interface Gigabit Ethernet (1 Gbit/s); 8-bit digital video output; C-mount lens (sold separately); Power Supply PoE (IEEE 802.3af) or 11.3 to 13.2 VDC via FJ-VSP cable; 3.8 W PoE / 3.2 W external; Cable Length LAN up to 40 m (FJ-VSG); power / I/O up to 10 m (FJ-VSP).

Key Features

  • FJ-series 2 MP monochrome CCD camera, 1626 x 1236 effective pixels, 1/1.8-inch progressive scan
  • 20 fps full frame, 2 to 1236 lines selectable, shutter 25 us to 1 s, C-mount lens (sold separately)
  • Gigabit Ethernet (1 Gbit/s) with PoE or 11.3 to 13.2 VDC, external or software trigger, strobe / trigger ready output
  • 90 g, IP30 housing, operating 0 to 40 degC, pair with FZ-LES3 lens and NJ501-1300 controller
  • SKU: FJ-S2MG
  • Series: FJ-series PC Vision System
  • Voltage: 11.3 TO 13.2 VDC

Best-Fit Applications

  • Pick-and-place verification where the monochrome CCD reads fiducial marks on a PCB and the NJ501-1300 PLC rejects misaligned boards
  • Spare replacement for an FJ-SC2MG color camera where the application only needs monochrome and the same FJ-VSG LAN cable reuses the cutout
  • Barcode and 2D code reading where the global shutter freezes motion at 25 us and the FJ-VSP cable delivers power and strobe trigger

Buying Checklist

  • Choose the FJ-SC2MG instead when color imaging is required for the same 2 MP resolution and 20 fps.
  • Confirm the lens is ordered separately (FZ-LES3 for typical 8 mm focal length) and the FJ-VSG LAN cable is included or ordered with the camera.
  • Choose the FJ-S2MG when the inspection only needs monochrome imaging and 20 fps is enough on a PC vision system.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series FJ-series PC Vision System
Model / SKU FJ-S2MG
Image Element 1/1.8-inch progressive-scan CCD, monochrome
Effective Pixels 1626 (H) x 1236 (V) (approx 2 MP); pixel size 4.4 (um) x 4.4 (um)
Frame Rate 20 fps at full frame; 2 to 1236 lines selectable
Shutter Speed 25 us to 1 s; gain 0 dB to +18 dB
Trigger External or software trigger (Ethernet); strobe or trigger READY output (software-configurable)
Interface Gigabit Ethernet (1 Gbit/s); 8-bit digital video output; C-mount lens (sold separately)
Power Supply PoE (IEEE 802.3af) or 11.3 to 13.2 VDC via FJ-VSP cable; 3.8 W PoE / 3.2 W external
Cable Length LAN up to 40 m (FJ-VSG); power / I/O up to 10 m (FJ-VSP)
Operating / Housing 0 to 40 degC (case surface 55 degC max); IP30 aluminum cover, zinc die-cast case; 90 g

FAQ for FJ-S2MG

Does the FJ-S2MG include a lens?
No. The FJ-S2MG has a C-mount lens flange and the lens is sold separately. The FZ-LES3 is a common 8 mm focal length lens for typical short-distance inspection. For longer working distances, choose an FZ-LES series lens with the right focal length for the field of view.
What is the difference between FJ-S2MG and FJ-SC2MG?
Both are 2 MP, 1/1.8-inch CCD cameras at 20 fps with Gigabit Ethernet. The FJ-S2MG is monochrome and suited to inspection, alignment, and code reading. The FJ-SC2MG is color and adds color-based sorting and verification. Both use the same FJ-VSG LAN cable and FJ-VSP power / I/O cable.
How is the FJ-S2MG powered?
Two ways. PoE (Power over Ethernet, IEEE 802.3af) from a PoE switch delivers both Ethernet data and power over the FJ-VSG cable at 3.8 W. Or use a separate 11.3 to 13.2 VDC supply on the FJ-VSP cable at 3.2 W. Mixing the two supplies is not supported.
How fast is the FJ-S2MG shutter?
The shutter runs from 25 us to 1 s. For high-speed lines, set a short shutter (under 100 us) and pair with a strobe trigger output to freeze motion. The trigger input accepts external or software trigger over Ethernet, and the external output can be set to strobe or trigger ready.
