Omron G6D-F4B DC24V — 4× SPST-NO 3 A Screw-Terminal Relay

SKU: G6D-F4B DC24V

USD 16.50

Compact 4-point terminal relay with 4× SPST-NO mechanical G6D relays, 24 VDC coils, screw terminals, LED indicators. Rated 3 A at 250 VAC / 30 VDC, 5 A carry. Same form factor as PYF-08 socket. Includes short-bar jumper accessory for COM-bus commoning.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The G6D-F4B DC24V is Omron's 4-point terminal relay in the G6D family — four SPST-NO mechanical relays in a single 31 × 35 × 68 mm package with screw terminals, LED indicators, and built-in coil-surge diodes. The right pick when you need four independent relay outputs on a DIN rail panel with field-side wiring that should be quick (screw terminals) and PLC-friendly (24 VDC coil, low 200 mW power per relay). It is a true terminal relay — the relays are mounted on a captive PCB inside the housing, and the screw terminals are at the field side for easy wire landings.

Decoding the G6D-F4B model number

G6D = G6D mini-relay family (SPST-NO, 5 A max contact, 6.5 mm wide × 15 mm high coil); F4 = 'Four-point' terminal relay form factor (4 relays in one housing); B = screw terminals (vs PU = Push-In Plus terminals). The 'B' vs 'PU' choice is the user-facing wiring method: 'B' for Phillips-head screw terminals that accept ferrule-ended wires and 0.25-2.5 mm² / AWG 24-14 wires; 'PU' for Push-In Plus terminals that accept ferrules directly without screws for faster installation.

Why SPST-NO × 4 vs alternatives

Each of the 4 relays in the G6D-F4B is a single-pole single-throw normally-open contact (Form A / SPST-NO) — when the coil is energized, the contact closes between COM and NO; when de-energized, the contact returns to NO. This is the most common contact arrangement for digital-output-to-isolated-load applications (e.g., 24 VDC PLC output to 230 VAC relay coil via field interposing relay). The 4 SPST-NO configuration gives 4 isolated control paths in one housing — each output has its own load-side wiring, no internal common-bus sharing like the G6B-4BND's DPDT contacts.

Built-in surge protection per channel

Each of the 4 relay coils has a built-in flyback diode across the coil (1N4007 or equivalent), absorbing the back-EMF when the coil is de-energized. This protects the PLC driving the coil from voltage spikes — no external MOV/diode required. The 24 VDC coil draws ~10 mA at 24 V (200 mW coil power); a single CJ1W-OD211 (16-pt NPN sinking) or CJ1W-OD212 (16-pt PNP sourcing) output at 0.5 A/point can drive 40 G6D-F4B relays (40 × 10 mA = 400 mA, well under 500 mA point rating). For higher-current DC coils (>50 mA), consider the G6B-4BND DC24V which has higher 70 mA coil current for larger mechanical relays.

Key Features

  • G6D series 4-point terminal relay
  • 4× SPST-NO mechanical contact sets
  • 24 VDC coil
  • Screw terminals for field-side wiring
  • Compact form factor 31 × 35 × 68 mm
  • Approximate size match to PYF-08 legacy socket
  • Screw terminal torque 0.5 N·m max
  • LED operation indicator per channel
  • SKU: G6D-F4B DC24V
  • Series: G6D Terminal Relays (4-point SPST-NO 5 mm × 20 mm × 12.5 mm mini-relay)
  • Voltage: 24 VDC

Best-Fit Applications

  • 24 VDC PLC output expansion to 230 VAC loads — the G6D-F4B relays accept 24 VDC from CJ1W-OD211 / OD212.
  • Indicator lamp driver on a control panel — 4 relays each switching a 24 VDC / 120 / 230 VAC.
  • Isolated interface between PLC and external equipment — the G6D-F4B provides galvanic isolation between the PLC's 24 VDC logic and.
  • Building-automation light-switching relay panel — 4 SPST-NO relays each controlling a separate lighting circuit; PLC time-clock program cycles lighting via.

Buying Checklist

  • Pick G6D-F4B DC24V for 4× SPST-NO 3 A 24 VDC coil relay terminal — compact terminal-relay block
  • Pick G6D-F4B DC12 for 12 VDC coil version — if PLC output is 12 VDC instead of 24 VDC
  • Pick G6D-F4PU DC24 for Push-In Plus terminals — if you want tool-free wiring instead of screw
  • Pick G6B-4BND DC24V for 4× DPDT 5 A 24 VDC coil — if you need DPDT contacts or higher current rating
  • Pick G3DZ-F4B DC24V for 4× SPST-NO 0.1 A MOSFET output — for silent high-cycle low-current switching
  • Pick G3DZ-F4PU DC24V for Push-In Plus MOSFET version — combine fast wiring + silent switching

Technical Specifications

Model G6D-F4B DC24V
Series G6D Terminal Relays (4-point SPST-NO 5 mm × 20 mm × 12.5 mm mini-relay)
Type 4-point terminal relay with SPST-NO contacts, screw terminals
Number of Relays 4 SPST-NO relays per housing
Contact Configuration SPST-NO × 4 (NOT 4PDT — correction vs old DB)
Coil Voltage 24 VDC
Coil Resistance Approx 2,880 Ω
Coil Power Consumption Approx 200 mW per relay (10 mA at 24 VDC)
Pickup Voltage 70% max of rated voltage (16.8 VDC at 24 VDC coil)
Dropout Voltage 10% min of rated voltage (2.4 VDC at 24 VDC coil)
Rated Carry Current 5 A (continuous, when 1-2 outputs energised)
Max Switching Voltage 250 VAC, 30 VDC
Max Switching Current 5 A (above 3 A rating reduces life expectancy)
Max Switching Capacity (reference) 1,250 VA / 150 W per output
Min Switching Capacity 100 mA at 5 VDC (micropower dry-circuit)

FAQ for G6D-F4B DC24V

Can the G6D-F4B DC24V be driven from a NPN sinking PLC output?
Yes — the G6D-F4B DC24V 24 VDC coil is polarity-sensitive (because of the internal flyback diode). For NPN sinking PLC output (e.g., CJ1W-OD211): connect the PLC output to the coil '+' terminal of the G6D; connect the coil '-' terminal to the 24 VDC supply positive rail. The NPN output sinks current from the coil + to ground when ON, completing the 24 VDC → coil+ → NPN → GND circuit.
How do I tell the difference between G6D-F4B, G6D-F4PU, and G3DZ-F4B?
All three are 4-point terminal relays in similar form factor with 24 VDC coils, but differ in contact type and wiring method. G6D-F4B (this SKU) uses mechanical SPST-NO relays with screw terminals, 3 A / 250 VAC per contact. G6D-F4PU uses mechanical SPST-NO relays with Push-In Plus terminals (tool-free ferrule-direct wiring), same 3 A contact rating as F4B but faster wiring.
What is the G6D-4-SB Short Bar and when do I need it?
The G6D-4-SB Short Bar (sold separately, pack of 5) is an accessory that bridges adjacent same-polarity terminals of a G6D-F4B / G6D-F4PU / G3DZ-F4B housing.
Can the G6D-F4B drive 230 VAC inductive loads like solenoid valves?
Yes — the G6D-F4B's SPST-NO contacts are rated 3 A at 250 VAC, suitable for switching 230 VAC solenoid valves, contactor coils, and small motor windings. Add surge suppression across the AC load (typically a 275 V MOV or an RC snubber across the AC coil terminals) — the G6D-F4B's contacts have no internal surge protection, unlike the coil side which has a flyback diode.
