Omron H7EC-N — Self-Powered 8-Digit Totalizer
SKU: H7EC-NUSD 18.00
Omron H7EC-N self-powered LCD totalizer, 8-digit, no-voltage input, 48 x 24 mm panel. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron H7EC-N is a self-powered LCD totalizer from the H7E family, manufactured by Omron Corporation. Hengyixin Automation stocks this timer / counter at our Xiamen warehouse; orders placed before 14:00 CST ship same business day.
The unit ships in a 1/32 DIN (48 x 24 mm) flush panel housing with screw terminals. The 8-digit LCD has 8.6 mm character height and reads 0 to 99,999,999 without overflow. The H7EC-N is fully self-powered from an internal replaceable lithium battery - no external supply is needed for the counter itself.
Count input is no-voltage (dry contact or NPN open-collector pull-down). Maximum counting speed is 30 Hz or 1 kHz, selected by a DIP switch on the front. Reset is via the front-panel key. Front face is IP66; light-grey case. Operating range -10 to +55 C. For a PNP/NPN DC-voltage-input version of the same body, pick the H7ET-N; for a 48 x 48 mm AC counter-timer, the H5CC-A.
Key Features
- 1/32 DIN (48 x 24 mm) flush-mount LCD totalizer, 8 digits, 8.6 mm character height, 0 to 99,999,999 range
- Self-powered from internal replaceable lithium battery - no external supply needed for the counter
- No-voltage input (dry contact or NPN open-collector pull-down), 30 Hz / 1 kHz switchable max count speed
- Front-panel reset key, screw terminals, IP66 front face, light-grey case, -10 to +55 C operating
- SKU: H7EC-N
- Series: Omron H7E self-powered totalizer family
Best-Fit Applications
- Production-piece counter on a manual assembly station where the no-voltage contact input wires directly to a foot-switch
- Odometer-style length totalizer on a measuring wheel where the encoder pulses accumulate over a shift without external power
- Spare replacement on an existing H7E panel where the original battery has reached end of life and the install must match exactly
Buying Checklist
- Pick the H7EC-N for a self-powered 8-digit totalizer with no-voltage contact input and an IP66 front face.
- Pick the H7EC-NV instead when the input must be a PNP/NPN DC-voltage signal rather than a dry contact.
- Pick the H7CC-A instead when the panel needs a 48 x 48 mm timer/counter with outputs and an external supply.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron H7E self-powered totalizer family |
| Model / SKU | H7EC-N |
| Counting Function | Totalising (count up) |
| Digits / Range | 8 digits, 0 to 99,999,999 |
| Display | 7-segment LCD, 8.6 mm character height, no backlight |
| Count Input | No-voltage (dry contact or NPN open-collector), short-circuit 10 kOhm max, open 750 kOhm min |
| Max Counting Speed | 30 Hz or 1 kHz, selectable by DIP switch |
| Reset | Front-panel key (external reset not available on H7EC-N) |
| Power Supply | Self-powered by internal replaceable lithium battery (Y92S-36 spare) |
| Protection / Mounting | Front face IP66, NEMA 4 indoor, UL Type 4X indoor, screw terminals, flush panel mount |
| Dimensions / Weight | 48 (W) x 24 (H) x 48.5 (D) mm, 60 g, light-grey case |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for H7EC-N
Does the H7EC-N need external power?
No. The H7EC-N is fully self-powered from an internal replaceable lithium battery. Applying external voltage to the count input terminals will damage the unit - the H7EC-N accepts only a no-voltage contact or NPN pull-down.
H7EC-N vs H7EC-NV - what is the difference?
The H7EC-N is a no-voltage-input, self-powered totalizer for a simple dry-contact or NPN pull-down. The H7EC-NV accepts a PNP/NPN DC-voltage input (4.5 to 30 VDC) at higher noise immunity and is the right choice when the source is a transistor output rather than a contact.
How do I replace the H7EC-N battery?
Open the case and swap the Y92S-36 lithium cell. Omron's spec sheet notes UL / CSA compliance for the replacement cell. The counter retains the running total during the swap if the change is fast.
