Omron H5CC-L8D 48x48 mm digital counter in shipping carton with the type label visible

Omron H5CC-L8D — 1-Stage Preset Counter, 8-Pin

SKU: H5CC-L8D

USD 75.00

H5CC 48x48 mm 1-stage preset digital counter on AC 24 V / DC 12-48 V supply, 8-pin round socket, 30 Hz / 10 kHz count, SPDT + transistor output.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron H5CC-L8D is a 1-stage preset digital counter in the 48x48 mm H5CC lineup. It counts pulse inputs from a sensor or switch and trips a relay when the count reaches the preset value. The display is a 4-digit LCD readable from across a panel, and the supply is AC 24 V or DC 12 to 48 V -- useful on retrofit cabinets that already have 24 VAC control transformers or 24 VDC sensor rails but not the 100-240 VAC mains.

Why the L8 in the model code matters

The H5CC family splits on connection and supply. The first letter tells the supply: H5CC-A = AC 100-240 V, H5CC-AD = AC 24 V / DC 12-48 V (this SKU's supply). The trailing letter-pair tells the connection: bare (screw terminal), A11 (11-pin socket), AS / L8 (8-pin socket). The 8-pin socket version -- this SKU -- plugs into a P2CF-08-E round base, so the counter can be lifted out of the panel with the wiring left on the socket. Useful for spares that swap with the rest of the cabinet.

H5CC vs H7CC

The H5CC is the earlier generation. The current H7CC series replaces it for new builds, adding multifunction counters, tachometer mode, and color-change LCDs. Pick the H5CC-L8D only when you are swapping an existing H5CC counter on an unchanged wiring base, or when the cabinet still uses 8-pin sockets and P2CF-08-E bases that the H7CC's 11-pin or screw layout does not fit.

Before ordering

Confirm the cabinet supply is AC 24 V or DC 12 to 48 V -- if it is 100-240 VAC, pick the H5CC-A or H5CC-AS instead. The panel cutout is 45 x 45 mm; seat the unit with the Y92S-P6 gasket for IP66 on the panel face. Set the count speed DIP to 30 Hz for mechanical switches or 10 kHz for proximity sensors.

Key Features

  • H5CC-series 48x48 mm 1-stage preset digital counter
  • 8-pin round socket connection (matches P2CF-08-E base)
  • AC 24 V / DC 12 to 48 V supply (H5CC-AD family)
  • 30 Hz or 10 kHz count speed (DIP switchable)
  • 4-digit -999 to +9999 LCD, with status row
  • NPN / PNP input switchable on rear DIP switch
  • SPDT contact output (AC 250 V 3 A) plus transistor output (DC 30 V 100 mA)
  • Prescale 0.001 to 99.999 in setup menu
  • 45 x 45 mm panel cutout, IP66 panel face with Y92S-P6 gasket
  • Predecessor to H7CC -- use H5CC for like-for-like spare replacement
  • SKU: H5CC-L8D
  • Series: H5CC-L8D
  • Voltage: 24 V
  • I/O: 250 I/O

Best-Fit Applications

  • Counting parts on a packaging line with a single setpoint batch quantity
  • Spare-counter swap on a panel that already has an H5CC on a P2CF-08-E socket
  • Cycle-counter on a press or stamping machine with relay output to a stacklight
  • Foot-count or piece-count on a small feeder or extrusion line where a relay trips the next step
  • Replacement counter on a retrofit cabinet wired for AC 24 V control or 24 VDC sensor rail

Buying Checklist

  • Pick H5CC-L8D when swapping an existing H5CC on AC 24 V / DC 12-48 V with an 8-pin socket base.
  • Pick H7CC-A8D instead for new builds -- the H7CC adds the same single-stage counter on the same socket plus modern display functions.
  • Pick H5CC-AD when the cabinet has screw-terminal wiring rather than the 8-pin P2CF socket.
  • Pick H5CC-AS when the cabinet supply is AC 100-240 V instead of the AC 24 V / DC 12-48 V rail.
  • Pick H7CC-AU when multifunction counter / tachometer mode is needed in addition to plain count.
  • Confirm supply voltage and panel cutout -- H5CC-L8D takes 45 x 45 mm and AC 24 V or DC 12-48 V only.

Technical Specifications

Function 1-stage preset digital counter
Supply Voltage AC 24 V or DC 12 to 48 V
Count Range -999 to +9999 (4-digit)
Count Speed 30 Hz or 10 kHz (DIP switchable)
Inputs Count + reset, NPN / PNP via rear DIP
Outputs SPDT contact (AC 250 V 3 A) + transistor (DC 30 V 100 mA)
External Connection 8-pin round socket (P2CF-08-E base)
Panel Cutout 45 x 45 mm; IP66 panel face with Y92S-P6 gasket
Operating Temperature -10 to +55 deg C
Family Siblings H5CC-A / H5CC-A11D / H5CC-AS / H7CC-A8D (current generation)

FAQ for H5CC-L8D

Is the H5CC-L8D a timer or a counter?
Counter. The H5CC family is a 1-stage preset counter -- it counts incoming pulses and trips the relay when the count reaches the preset. For a timer in the same 48x48 form factor, pick the H5CX-L8D or the current H5CX-AD timer series. The H5CC and H5CX look similar on the shelf but count pulse inputs vs time intervals.
What is the difference between H5CC-L8D and H7CC-A8D?
Both are 48x48 mm 1-stage preset counters on an 8-pin socket, AC 24 V / DC 12-48 V supply, IP66 panel face. The H5CC-L8D is the earlier generation -- smaller LCD, simpler setup, lower cost. The H7CC-A8D is the current generation -- larger white LCD with color-change row, easier key setup, and the same matching socket, so it is a drop-in replacement on the same P2CF-08-E base. Pick the H7CC-A8D for new builds; pick the H5CC-L8D when a like-for-like spare is required.
What socket does the H5CC-L8D plug into?
The Omron P2CF-08-E 8-pin round base, mounted to the cabinet back with screws and wired with fork or ring lugs under each socket screw. The counter itself lifts off the socket for replacement without disturbing the field wiring -- useful on cabinets where the counter is treated as a serviceable spare. The matching hold-down clip is the P2CF-08-E / Y92F-30 series.
Can the H5CC-L8D count fast pulses?
Up to 10 kHz with the count-speed DIP set to the high-speed position. That covers most encoder / proximity applications. For higher pulse rates (10 to 500 kHz) step up to the CS1W-CT021 or CJ1W-CT021 high-speed counter unit on a CJ-series rack, or to the H7CX preset counter which shares the H5CC footprint but adds a 5 kHz / 10 kHz / higher range.
