Omron P2RFZ-05-E — Relay Socket, 5-Pin, 10 A, Screw
SKU: P2RFZ-05-EUSD 4.00
5-pin DIN-rail socket for G2R-1-S relays, 250 VAC, 10 A, screw terminal. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron P2RFZ-05-E is a 5-pin DIN-rail and surface-mount socket for the G2R-1-S plug-in relay family It is manufactured by Omron Corporation. Hengyixin Automation stocks this relay in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
The socket has five M3 screw terminals and accepts forked or round crimp terminals. The -E suffix marks the finger-safe construction with protective covers over the coil and contact screws.
For an 8-pin socket for the 2-pole G2R-2-S relay family, pick the P2RFZ-08-E. Key specs: Pin Count 5; Rated Voltage / Current 250 VAC, 10 A; Compatible Relays G2R-1-S 12VDC (S), 24VDC (S), 24VAC (S), 120VAC (S), 230VAC (S); Terminal Type M3 screw (finger-safe -E construction); Applicable Ferrules Forked terminals, round terminals; Mounting 35 mm DIN rail or surface mount with M4 screws; Hold-Down / Release Hold-down clip and release lever included; Approvals IEC / VDE EN 61810-1, CSA C22.2, UL 508, CE.
Key Features
- 5-pin DIN-rail and surface-mount socket for the G2R-1-S relay family
- 250 VAC at 10 A, M3 screw terminals with finger-safe -E construction
- Built-in hold-down clip and release lever for tool-free relay swap
- 15.5 x 79 x 61 mm, accepts forked or round crimp terminals
- SKU: P2RFZ-05-E
- Series: Omron P2RFZ-series 5-pin screw-terminal relay socket
- Voltage: 250 VAC
Best-Fit Applications
- Control relay socket on a packaging line panel where the G2R-1-S 24VDC relay drives a solenoid and the finger-safe terminals pass the safety audit
- DIN-rail marshalling block where five P2RFZ-05-E sockets sit side by side with P2DN-15.7-100S shorting bars for commoning the coil negative
- Spare drop-in for an existing Omron panel where the previous P2RFZ-05-E socket failed and the wiring is forked or round crimp on M3 screws
Buying Checklist
- Pick the P2RFZ-05-E for a 5-pin screw-terminal socket for the G2R-1-S relay family with finger-safe -E construction.
- Pick the P2RF-05-PU instead when the cabinet needs tool-free push-in wiring for high-volume panel builds.
- Pick the P2RFZ-08-E instead when the panel needs an 8-pin socket for the G2R-2-S 2-pole relay family.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron P2RFZ-series 5-pin screw-terminal relay socket |
| Model / SKU | P2RFZ-05-E |
| Pin Count | 5 |
| Rated Voltage / Current | 250 VAC, 10 A |
| Compatible Relays | G2R-1-S 12VDC (S), 24VDC (S), 24VAC (S), 120VAC (S), 230VAC (S) |
| Terminal Type | M3 screw (finger-safe -E construction) |
| Applicable Ferrules | Forked terminals, round terminals |
| Mounting | 35 mm DIN rail or surface mount with M4 screws |
| Hold-Down / Release | Hold-down clip and release lever included |
| Approvals | IEC / VDE EN 61810-1, CSA C22.2, UL 508, CE |
| Dimensions / Color | 79 (H) x 15.5 (W) x 61 (D) mm; black |
