Omron P7SA-10F-ND-PU DC24 — front face of the 4-pole DIN-rail socket showing the 10 Push-In Plus terminal slots and the orange release buttons

Omron P7SA-10F-ND-PU DC24 — Safety Relay Socket

SKU: P7SA-10F-ND-PU DC24

USD 13.50

P7SA 4-pole DIN socket for G7SA safety relays, Push-In Plus terminals, 24 VDC LED + diode, EN/IEC 61810-3.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron P7SA-10F-ND-PU DC24 is a 4-pole DIN-rail socket for the G7SA-series safety relays with forcibly guided contacts. It is manufactured by Omron Corporation. Hengyixin Automation stocks this relay in Xiamen and ships within 3-5 business days; safety-rated components ship with a batch-trace certificate.

The Push-In Plus terminals cut wiring time by about 60% versus screw terminals, and the integrated 24 VDC LED indicator plus reverse-polarity diode give at-a-glance status of the safety relay coil. The socket accepts the G7SA-2A2B (DPST-NO + DPST-NC) and G7SA-3A1B (3PST-NO + SPST-NC) safety relays.

Spare sockets should be ordered with the relay as a kit to avoid field-wiring mismatches when a socket is replaced under maintenance. Key specs: Model P7SA-10F-ND-PU DC24; Number of Poles 4 poles (10 terminals); Coil Voltage 24 VDC; LED / Diode Built-in 24 VDC LED indicator + reverse-polarity diode (ND); Terminal Style Push-In Plus (PU); Mounting 35 mm DIN rail, front-mounting (F); Dimensions 90 (H) x 22.5 (W) x 60.5 (D) mm; Compatible Relays G7SA-2A2B (DPST-NO + DPST-NC), G7SA-3A1B (3PST-NO + SPST-NC).

Key Features

  • P7SA 4-pole (10-terminal) DIN-rail socket for G7SA-series safety relays
  • Push-In Plus terminals, about 60% faster wiring versus screw terminals
  • 24 VDC LED indicator + reverse-polarity diode on the coil input
  • Accepts G7SA-2A2B and G7SA-3A1B relays with forcibly guided contacts
  • SKU: P7SA-10F-ND-PU DC24
  • Series: P7SA socket for G7SA safety relay series
  • Voltage: 24 VDC

Best-Fit Applications

  • Two-hand control panel where a PLe-rated circuit uses two G7SA sockets for redundancy.
  • Safety-gate monitoring on a guarded enclosure where two G7SA sockets drive the contactor drop-out.
  • Reach-over guard interlock on a press where the safety circuit drops the main contactor.

Buying Checklist

  • Confirm the matching G7SA relay is ordered separately - the socket alone is not a safety function.
  • Choose P7SA-10F-ND (screw terminals) when the cabinet already uses screw-terminalled components.
  • Choose P7SA-14F-ND-PU DC24 for the 14-terminal (6-pole) socket when the G7SA has more contacts.

Technical Specifications

Model P7SA-10F-ND-PU DC24
Series P7SA socket for G7SA safety relay series
Number of Poles 4 poles (10 terminals)
Coil Voltage 24 VDC
LED / Diode Built-in 24 VDC LED indicator + reverse-polarity diode (ND)
Terminal Style Push-In Plus (PU)
Mounting 35 mm DIN rail, front-mounting (F)
Dimensions 90 (H) x 22.5 (W) x 60.5 (D) mm
Compatible Relays G7SA-2A2B (DPST-NO + DPST-NC), G7SA-3A1B (3PST-NO + SPST-NC)
Contact Rating (relay) 6 A at 250 VAC / 6 A at 30 VDC (resistive)
Operating Temperature -25 to +55 degC
Certifications EN/IEC 61810-3, EN 50205 Class A, CE, UL

FAQ for P7SA-10F-ND-PU DC24

What does the -PU suffix on P7SA-10F-ND-PU DC24 mean?
PU = Push-In Plus terminals, which cut wiring time by about 60% versus screw. To release a wire, depress the orange push-button with a flat-blade screwdriver. The -ND version also adds an integrated 24 VDC LED indicator and reverse-polarity diode; the -PU alone (without -ND) lacks the LED.
Does the P7SA-10F-ND-PU include the safety relay?
No. The socket is the wiring interface only; the G7SA-2A2B or G7SA-3A1B relay plugs in on top. Order the relay separately, or buy a pre-assembled G7SA-2A2B + P7SA-10F-ND-PU DC24 kit from Hengyixin Automation. The MOV clamps the inductive kick to a level the silver-alloy contact can switch reliably for many more cycles.
What safety relays does the P7SA-10F-ND-PU DC24 accept?
G7SA-2A2B (DPST-NO + DPST-NC) and G7SA-3A1B (3PST-NO + SPST-NC) are the two standard 4-pole G7SA relays. Both have forcibly guided contacts per EN/IEC 61810-3 and EN 50205 Class A. The socket will not accept a 6-pole G7SA relay - for that, use the P7SA-14F-ND-PU DC24.
What does the -ND suffix mean?
ND = LED indicator + reverse-polarity diode on the coil input. The LED lights when the coil is energised, making fault-troubleshooting fast. The diode protects the upstream PLC output or safety controller from the back-EMF when the coil de-energises. The chassis-mount footprint is the same on both terminals, so the panel cutout does not change when you swap A5 for C5.
