Omron C500-CE404 — 40-Pin Soldered Connector, Right-Angle
SKU: C500-CE404USD 10.00
40-pin soldered right-angle connector kit (Fujitsu FCN-361J040-AU housing + cover) supplied with the CJ1W-CT021 / C200H-CT021 high-speed counter.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron C500-CE404 is a 40-pin soldered right-angle connector kit (housing Fujitsu FCN-361J040-AU + cover FCN-360C040-J2 / OTAX N360C040J2) supplied with the CJ1W-CT021 / C200H-CT021 high-speed counter unit. The C500-CE404 lands the encoder and control wiring on the front face of the counter module -- the 40-pin male header on the CT021 mates to the FCN-365J040-B style socket, and the C500-CE404 carries the wiring from the cabinet to that socket. The right-angle soldered configuration is the standard pick for cabinet builds where the encoder cable enters the control panel from the side.
When to pick the soldered vs crimped vs pressure-welded
Pick the C500-CE404 (soldered, right-angle) for hand-soldered or low-volume builds where the wire gauge is fixed and the technician can solder each of the 40 pins to the housing. Pick the C500-CE405 (crimped, FCN-363J040 housing + FCN-363J-AU contacts) for field-replaceable builds where the encoder cable may need to be swapped without re-soldering. Pick the C500-CE403 (pressure-welded, FCN-367J040-AU/F) for flat-cable builds where the ribbon cable lays into the IDC insulation-displacement contacts in one press. Pick the bare C500-CE401 (40-pin soldered straight, no right-angle bend) for top-cable-entry builds where the cable drops straight down from the module.
How the C500-CE4xx sits on the CJ1W-CT021
The CJ1W-CT021 carries two 32-bit counter channels at 500 kHz line-driver / 50 kHz open-collector on the A, B, and Z phases. Each counter needs a 40-pin connector to land the encoder wires, the external control inputs, and the external outputs. The C500-CE404 is supplied with the CT021 as the standard accessory for one counter channel. For a two-channel build, order a second C500-CE404. For the XW2D-40G6 screw-terminal conversion unit on the back end of the wiring, use the XW2Z-050B / 100B / 150B / 200B / 300B / 500B cable in 0.5 m to 5 m lengths.
Before ordering
Confirm the encoder is a 5 V, 12 V, or 24 V open-collector device (50 kHz max) or a 5 V RS-422 line driver (500 kHz max). Order one C500-CE404 per counter channel on the CJ1W-CT021. The C500-CE404 is a spare / replacement part -- the CT021 already ships with one in the box.
Key Features
- 40-pin soldered right-angle connector kit for the CJ1W-CT021 / C200H-CT021 high-speed counter
- Housing: Fujitsu FCN-361J040-AU (1.27 mm pitch, 40 pins)
- Cover: Fujitsu FCN-360C040-J2 / OTAX N360C040J2
- Right-angle cable entry for cabinet side-cable builds
- Mates to the FCN-365J040-B style 40-pin header on the CT021 front face
- Suitable for hand-soldered custom wiring, no crimp tool required
- Supplied as standard accessory with the CJ1W-CT021 (one per counter channel)
- Compatible with the C500-CE4xx family for spare / replacement
- SKU: C500-CE404
- Series: C500 connector family (spare for CJ1W-CT021)
Best-Fit Applications
- Spare / replacement 40-pin connector for an existing CJ1W-CT021 high-speed counter build
- Cabinet side-cable entry where the encoder cable drops into the panel from the side
- Hand-soldered prototype build of a 2-axis encoder counter module on a CJ1 / C200H rack
- Custom wiring of phase-A, phase-B, phase-Z, and external control signals on a CT021
- Field-replacement of a damaged connector on an existing CT021 install
Buying Checklist
- Pick C500-CE404 for a 40-pin soldered right-angle connector kit for the CJ1W-CT021 / C200H-CT021 high-speed counter.
- Pick C500-CE401 instead for a 40-pin soldered straight connector (top-cable-entry build).
- Pick C500-CE403 instead for a 40-pin pressure-welded IDC connector (flat-cable ribbon build).
- Pick C500-CE405 instead for a 40-pin crimped connector (field-replaceable build with FCN-363J-AU contacts).
- Order one C500-CE404 per counter channel on the CT021 -- the CT021 ships with one in the box, so the spare is a like-for-like.
- Pair the C500-CE404 with an XW2D-40G6 screw-terminal conversion unit and an XW2Z cable (0.5 m to 5 m) for a clean cabinet wiring land.
Technical Specifications
| Series | C500 connector family (spare for CJ1W-CT021) |
|---|---|
| Connector Type | 40-pin soldered right-angle |
| Housing | Fujitsu FCN-361J040-AU (or equivalent) |
| Cover | Fujitsu FCN-360C040-J2 / OTAX N360C040J2 |
| Pin Pitch | 1.27 mm |
| Number of Pins | 40 pins |
| Use | CJ1W-CT021 / C200H-CT021 high-speed counter unit |
| Cable Entry | Right-angle, suited for side-of-cabinet cable runs |
| Mating Header (on CT021) | FCN-365J040-B style 40-pin male socket |
| Wiring Method | Hand-soldered to the housing contacts |
| Compatible With | C500-CE401 (straight) / CE403 (pressure-welded) / CE405 (crimped) |
| Includes | Housing + cover; sold in pairs (one per counter channel) |
Resources & Downloads
FAQ for C500-CE404
Is the C500-CE404 a network module?
No. The C500-CE404 is a 40-pin soldered right-angle connector kit (Fujitsu FCN-361J040-AU housing + FCN-360C040-J2 cover) supplied with the CJ1W-CT021 high-speed counter unit. It is not a Controller Link, EtherNet/IP, or any other communication module. Pick the C500-CE404 to wire the encoder / pulse / control signals into the front face of a CJ1W-CT021 counter; pick a communication unit (CJ1W-ETN21, CS1W-ETN21, or similar) for Ethernet.
What is the difference between C500-CE401, CE403, CE404, and CE405?
All four are 40-pin connector kits for the CJ1W-CT021 / C200H-CT021 high-speed counter. The CE401 is the bare 40-pin soldered straight connector (housing + cover). The CE403 is the 40-pin pressure-welded IDC connector (FCN-367J040-AU/F, no cover) for flat-cable ribbon builds. The CE404 is the 40-pin soldered right-angle connector (housing + cover) for cabinet side-cable builds. The CE405 is the 40-pin crimped connector (FCN-363J040 housing + FCN-363J-AU contacts, separate cover) for field-replaceable builds.
How many C500-CE404 connectors do I need per CJ1W-CT021?
The CJ1W-CT021 carries two 32-bit counter channels and ships with one C500-CE404 in the box. If both counter channels are wired to encoders, order a second C500-CE404 to land the wiring on the second channel. For a single-channel build, the in-box C500-CE404 is enough and no spare is required unless the connector is damaged and needs replacement.
Can the C500-CE404 be used on a 24-pin CJ1W-ID211 input unit?
No. The C500-CE404 is a 40-pin connector for the CJ1W-CT021 / C200H-CT021. The 24-pin connector for the CJ1W-ID211 / ID212 / ID231 input units is the C500-CE243 (24-pin soldered ribbon) or the C500-CE241 (24-pin soldered straight) / C500-CE242 (24-pin crimped). Pick the 24-pin variant for the CJ1W basic I/O units; pick the 40-pin C500-CE4xx for the high-speed counter.
