Omron XW2Z-200K — both ends of the 2-meter shielded I/O connection cable showing the straight 40-pin MIL sockets on each end

Omron XW2Z-200K — 2 m I/O Cable, MIL40 to MIL40

SKU: XW2Z-200K

USD 42.00

Omron XW2Z-200K I/O connection cable, MIL40 to MIL40, 2 m, shielded, for 32-pt PLC I/O. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron XW2Z-200K is the 2-meter I/O connection cable with a 40-pin MIL socket on each end, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

It pairs the Omron NX-series 32-point / 64-point DC input and transistor output units (NX-ID6142-5, NX-ID6142-6, NX-OD6256-5, NX-OD6121-5, NX-OD6121-6) and the CJ1W / CS1W 32-point and 64-point I/O units (CJ1W-ID262, CJ1W-OD262, CS1W-ID231, CS1W-OD231) with the XW2D-40G6, XW2K-40G-O32C, or G70A-ZOC16-3 connector-terminal block conversion unit.

Cable is 28 AWG shielded cores in a polyester resin connector housing, rated 1 A and 125 VAC with 20 mOhm contact resistance max. Operating temperature 0 to 55 C ambient. Pre-assembled plug-and-play replacement for hand-wired 40-point harnesses. The 1-meter sibling is XW2Z-100K. The 5-meter sibling is XW2Z-500K. The MIL40-to-2xMIL20 cross-wired sibling is XW2Z-200N. For 16-point MIL20 panels use the XW2Z-100X / 200X / 0500X cable series.

Key Features

  • XW2Z-series I/O connection cable, 40-pin MIL socket (FCN-365P040-AU compatible) on each end, 2 m long
  • Pairs NX-series 32-pt / 64-pt I/O units (NX-ID6142-5, NX-OD6256-5) and CJ1W / CS1W 32-pt / 64-pt I/O units with the XW2D-40G6 or G70A-ZOC16-3 terminal block
  • 28 AWG shielded cores, polyester resin connector housing, 1 A and 125 VAC rated, 20 mOhm contact resistance max
  • Pre-assembled plug-and-play replacement for hand-wired 40-point harnesses, 0 to 55 C ambient
  • SKU: XW2Z-200K
  • Series: XW2Z-series I/O connection cables
  • Voltage: 125 VAC

Best-Fit Applications

  • Automotive welding cell where the NX-OD6256-5 32-point PNP output unit lands on an XW2D-40G6 terminal block via a 2-meter XW2Z-200K for tool-free field replacement
  • Conveyor panel retrofit where the original hand-wired 40-point harness is replaced with a pre-assembled XW2Z-200K to cut commissioning time on a CS1W-ID231
  • Spare replacement on a packaging line where the original 2-meter MIL40 cable was lost and the cabinet drawing lists the XW2Z-200K as the standard harness

Buying Checklist

  • Pick the XW2Z-200K when the cabinet needs a 2-meter pre-assembled MIL40-to-MIL40 cable between a 32-pt / 64-pt PLC I/O unit and an XW2D-40G6 or G70A-ZOC16-3 terminal block.
  • Pick the XW2Z-100K instead when the panel is shallow and only 1 meter of cable is needed.
  • Pick the XW2Z-200N instead when the terminal block uses two 20-pin MIL20 sockets and the cable must be cross-wired to split the 40 points into two commons.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series XW2Z-series I/O connection cables
Model / SKU XW2Z-200K
Function Pre-assembled I/O connection cable, MIL40 socket to MIL40 socket, 2 m
Connectors 1 x 40-pin MIL socket (FCN-365P040-AU compatible) on each end; polyester resin housing
Cable 28 AWG shielded cores; outer diameter approx. 10.4 mm; bend radius 84 mm
Rated Current / Voltage 1 A; 125 VAC
Contact Resistance 20 mOhm max
Compatible I/O Units NX-ID6142-5, NX-ID6142-6, NX-OD6256-5, NX-OD6121-5, NX-OD6121-6, CJ1W-ID262, CJ1W-OD262, CS1W-ID231, CS1W-OD231 and other 32-pt / 64-pt I/O units with MIL40 connector
Compatible Terminals XW2D-40G6, XW2K-40G-O32C, G70A-ZOC16-3
Operating Temperature 0 to 55 C ambient
Approvals / Weight CE; 300 g approx

FAQ for XW2Z-200K

What is the Omron XW2Z-200K used for?
It is the 2-meter pre-assembled I/O connection cable with a 40-pin MIL socket on each end. Typical uses are automotive welding cells with an NX-OD6256-5 32-point PNP output and an XW2D-40G6 terminal block, conveyor panel retrofits replacing a hand-wired 40-point harness on a CS1W-ID231, and spare replacement where the cabinet drawing lists the XW2Z-200K.
Which I/O units does the XW2Z-200K connect?
Any Omron PLC I/O unit with a 40-pin MIL connector on the slice: the NX-series NX-ID6142-5, NX-ID6142-6, NX-OD6256-5, NX-OD6121-5, and NX-OD6121-6; the CJ1W-ID262, CJ1W-OD262; the CS1W-ID231, CS1W-OD231. The other end lands on an XW2D-40G6 general-purpose terminal block, an XW2K-40G-O32C wiring system, or a G70A-ZOC16-3 relay output terminal.
What is the difference between XW2Z-200K and XW2Z-200N?
Both are 2-meter pre-assembled cables for NX / CJ1W / CS1W 32-point and 64-point I/O units. The XW2Z-200K has a MIL40 socket on each end (1-to-1 straight wiring). The XW2Z-200N has a MIL40 socket on one end and two MIL20 sockets on the other (1-to-2, cross-wired) so a 40-point signal breaks out to two 20-pin terminal blocks. Pick the 200K for a single 40-pin terminal; pick the 200N for two 20-pin terminals.
How long is the XW2Z-200K?
2 meters (6.56 feet). The 1-meter sibling is XW2Z-100K. The 1.5-meter sibling is XW2Z-150K. The 3-meter sibling is XW2Z-300K. The 5-meter sibling is XW2Z-500K. Pick the shortest cable that reaches between the slice and the terminal block; longer cables add cost and signal noise pickup.
