Omron CJ1W-BAT01 — the small white Omron retail carton standing upright on a wood counter, label reading TYPE CJ1W-BAT01 / LOT No. 230502YK / QTY 1 with the RoHS mark, the OMRON Corporation / MADE IN JAPAN line and the blue OMRON band across the base, reflected on the polished counter

Omron CJ1W-BAT01 — PLC Memory Backup Battery

SKU: CJ1W-BAT01

USD 18.50

Omron CJ1W-BAT01 3 V lithium battery backs up program memory and clock on CJ1M, CJ2H, CJ2M, NJ501 and NSJ-series CPUs.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CJ1W-BAT01 is a 3 V lithium backup battery for the CJ-series and NJ/NSJ-series CPUs, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

Inside the cartridge is a single CR14250SE-CJ lithium manganese dioxide cell, 3.0 V, 850 mAh. It keeps the RAM and the real-time clock alive on power loss, so the program, retained data and clock do not clear. Omron rates battery life at about 5 years at 25 °C. A short wired lead plugs into a white connector on the CPU; you can swap it hot without losing the program if the CPU stays powered.

It fits the CJ1M, CJ2H (including the CJ2H-CPU64-EIP), CJ2M, NJ501, and NSJ-series CPUs. It does not fit the CS1, CPM2A or CJ1G/H families, and it is not the right battery for a CP-series PLC. Replace it as soon as the CPU shows a battery-low alarm.

Key Features

  • 3 V, 850 mAh CR14250SE-CJ lithium manganese dioxide cell
  • Backs up program, retained data and the real-time clock on power loss
  • Fits CJ1M, CJ2H, CJ2M, NJ501 and NSJ-series CPUs
  • About 5 years of life at 25 °C; hot-swap with the CPU powered
  • SKU: CJ1W-BAT01
  • Series: Omron CJ-series battery set
  • Voltage: 3.0 V

Best-Fit Applications

  • Scheduled spare on a CJ2M-CPU33 line every four years so the program never rides the end of the cell
  • Restoring a CJ2H-CPU64-EIP after a long panel shutdown where the original cell finally dropped out
  • Fleet refresh on a group of NJ501 controllers at a water utility, one battery per CPU as a kit

Buying Checklist

  • Pick the CJ1W-BAT01 for any CJ1M, CJ2H, CJ2M, NJ501 or NSJ CPU.
  • Pick the same battery (and check the holder) for a CJ2H-CPU64-EIP retrofit where the original is dead.
  • Pick the CS1W-BAT01 instead for a CS1-series CPU -- the cartridge is not the same.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron CJ-series battery set
Model / SKU CJ1W-BAT01
Cell Type CR14250SE-CJ, lithium manganese dioxide
Nominal Voltage 3.0 V
Capacity 850 mAh
Compatible CPUs CJ1M, CJ2H, CJ2M, NJ501, NSJ5 / NSJ8 / NSJ10 / NSJ12
Not For CS1, CPM2A, CJ1G/CJ1H, or CP-series (use CP1W-BAT01)
Battery Life About 5 years at 25 °C (per Omron datasheet)
Operating Temperature 0 to 55 °C
Storage Temperature -20 to 65 °C (excluding battery)
Cell Dimensions Approx. Ø14.5 x 26 mm

FAQ for CJ1W-BAT01

What does the Omron CJ1W-BAT01 do?
It keeps the CPU's RAM and the real-time clock alive when the panel power is off. Without it, a power-off longer than the capacitor hold-up would clear the program, the retained data and the clock on a CJ1M, CJ2H, CJ2M, NJ501 or NSJ CPU.
How long does the CJ1W-BAT01 last?
Omron rates it at about 5 years at 25 °C. Higher ambient temperatures, frequent power cycles or longer outages shorten that. Replace it when the CPU raises a battery-low alarm, not on a fixed calendar.
Can the CJ1W-BAT01 be hot-swapped?
Yes, as long as the CPU stays powered while you swap the battery. The program and the clock stay in RAM. Omron recommends finishing the swap within a few minutes.
Will the CJ1W-BAT01 fit a CP1L or CP1E?
No. CP-series PLCs take a different battery with a different holder and connector. Buying a CJ1W-BAT01 for a CP1L is a common mix-up.
What is the difference between CJ1W-BAT01 and CS1W-BAT01?
The CS1W-BAT01 is a different cartridge for CS1-series CPUs. The CJ1W-BAT01 does not fit a CS1 rack, and the CS1W-BAT01 will not seat in a CJ-series holder.
