Omron CJ1W-MAD42 — PLC Controller
SKU: CJ1W-MAD42USD 215.00
CJ-series mixed analog I/O unit with 4 differential inputs and 2 outputs, per-channel configurable ranges (-10 to +10 V, 0-5/10 V, 1-5 V, 4-20 mA). Resolution 1/4,000 default settable to 1/8,000; conversion 1 ms or 250 µs/point; input disconnection detection on 1-5 V / 4-20 mA ranges.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The CJ1W-MAD42 is Omron's CJ-series mixed analog I/O unit, combining 4 differential analog inputs and 2 analog outputs in a single 31 mm wide slot. It is the workhorse unit for process-control loops on packaging machines, HVAC skids, water-treatment skids, and any application where the PLC reads a 4-20 mA signal from a transmitter (pressure, flow, temperature, level) and writes a 4-20 mA or 0-10 V output to a valve positioner, VFD speed reference, or damper actuator.
Resolution and conversion speed trade-off
The CJ1W-MAD42 has two resolution settings: 1/4,000 default (1 ms/point conversion speed) and 1/8,000 high-resolution (250 µs/point conversion speed). The 1/4,000 default provides 12-bit resolution (4,096 discrete values) over the full input range, sufficient for most process-control applications where the transmitter's intrinsic accuracy is ±0.1 to ±0.5% of full scale. The 1/8,000 high-resolution mode provides 13-bit resolution (8,192 discrete values) for applications requiring finer discrimination — typically strain-gauge load cells, precision pressure transducers, or pH / conductivity analyzers.
Input disconnection detection on 1-5 V / 4-20 mA ranges
The CJ1W-MAD42 supports per-input disconnection detection on the 1-5 V and 4-20 mA ranges — a critical safety feature for current-loop transmitter inputs. If the input voltage drops below 0.3 V (or the current drops below 1.2 mA), the unit interprets the loss as a wire break or sensor failure and sets a per-input disconnection flag in the allocated I/O memory. The PLC program reads this flag and raises an alarm (instead of treating the near-zero reading as a valid low process value, which could cause a control valve to slam shut on a stuck-low sensor).
Scaling engineering units
The CJ1W-MAD42's per-channel scaling lets the engineer define the engineering-unit range that maps to the analog input range. For example, for a 4-20 mA pressure transmitter with 0-100 PSI range: the engineer scales 4 mA = 0 (raw value 0) to 20 mA = 10000 (raw value 4,000), so the digital value in the PLC's DM area reads 0-10000 for 0-100 PSI. The scaling is independent per channel, so different inputs can have different unit ranges (temperature in °C, pressure in kPa, flow in L/min) without scaling gymnastics in the PLC program. The PLC program reads the scaled engineering-unit value directly.
Key Features
- CJ-series mixed analog I/O unit
- 4 differential analog inputs
- 2 analog outputs
- Input signal ranges: -10 to +10 V, 0 to 5 V, 0 to 10 V, 1 to 5.
- Output signal ranges: -10 to +10 V, 0 to 5 V, 0 to 10 V, 1 to 5.
- Resolution: 1/4,000 default, settable to 1/8,000
- Conversion speed: 1 ms/point default, settable to 250 µs/point
- Accuracy: ±0.2% of F.S., ±0.4% of F.S.
- SKU: CJ1W-MAD42
- Series: CJ1W Special I/O Units (CJ-series analog I/O)
- I/O: 4 I/O
Best-Fit Applications
- Pressure control loop on a boiler — 4-20 mA pressure transmitter on input 0, PID loop in CJ2M CPU, 4-20.
- Flow control loop on a water-treatment skid — 4-20 mA magnetic flow meter on input 1, PID loop with the.
- Tank level control on a chemical batching system — 4-20 mA hydrostatic level transmitter on input 2, 4-20 mA output.
- HVAC damper actuator control on a cleanroom — 0-10 V input from a room-pressure sensor on input 3, 0-10 V.
Buying Checklist
- Pick CJ1W-MAD42 for 4AI + 2AO mixed analog I/O — standard PID control loops, valves, VFD speed references, multi-variable process control
- Pick CJ1W-AD042 — for input-only applications, slightly lower cost
- Pick CJ1W-DA041 — for output-only applications, slightly lower cost
- Pick CJ1W-AD081-V1 — for higher-density input, higher resolution
- Pick CJ1W-PH@@@ for high-density analog — when you need 8+ channels in a single slot
- Pick CJ1W-TS@@@ / CJ1W-PT@@@ for thermocouple / RTD inputs — for direct temperature sensor inputs
Technical Specifications
| Model | CJ1W-MAD42 |
|---|---|
| Series | CJ1W Special I/O Units (CJ-series analog I/O) |
| Type | Mixed analog I/O unit (4 inputs + 2 outputs) |
| Analog Inputs | 4 differential inputs |
| Analog Outputs | 2 outputs |
| Input Signal Ranges | -10 to +10 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 4 to 20 mA (per-channel configurable) |
| Output Signal Ranges | -10 to +10 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 4 to 20 mA (per-channel configurable) |
| Resolution (default) | 1/4,000 (12-bit equivalent) |
| Resolution (high-resolution mode) | 1/8,000 (13-bit equivalent) |
| Accuracy (Voltage) | ±0.2% of F.S. (at 23 ± 2 °C, 55 ± 10 % RH) |
| Accuracy (Current) | ±0.4% of F.S. (at 23 ± 2 °C, 55 ± 10 % RH) |
| Input Impedance (Voltage) | 1 MΩ min |
| Input Impedance (Current) | 250 Ω |
| Voltage Output Max Current | 5 mA (max load 2 kΩ) |
| Current Output Max Load | 600 Ω (at 24 VDC supply, sourced through output transistor) |
Resources & Downloads
FAQ for CJ1W-MAD42
What's the difference between CJ1W-MAD42 and CJ1W-AD042 or CJ1W-DA041?
The CJ1W-MAD42 is a mixed analog I/O unit that combines 4 analog inputs and 2 analog outputs in one slot. The CJ1W-AD042 is an input-only unit with 4 analog inputs (no outputs, no output channel). The CJ1W-DA041 is an output-only unit with 2 analog outputs (no inputs). For applications with both inputs and outputs, the MAD42 saves DIN-rail space and cost compared to having both an AD042 and a DA041. For input-only applications, the AD042 is slightly cheaper.
How does the input disconnection detection work on the CJ1W-MAD42?
The CJ1W-MAD42 monitors each input on the 1-5 V and 4-20 mA ranges and detects when the input signal drops below the live-zero threshold (0.3 V for 1-5 V, 1.2 mA for 4-20 mA). When this happens, the unit sets a per-input disconnection flag in the allocated I/O memory (the PLC program reads this flag and raises an alarm).
Can I configure different input ranges on different channels of the CJ1W-MAD42?
Yes — each of the 4 inputs is independently configurable for any of the 5 supported ranges (-10 to +10 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 4 to 20 mA). Likewise, each of the 2 outputs is independently configurable. The configuration is done in the CJ CPU's I/O memory using the allocated I/O words for the unit.
What's the difference between 1/4,000 and 1/8,000 resolution modes?
The 1/4,000 default mode provides 4,000 discrete values across the full input range (e.g., 0-4000 for 0-10 V, or 0-4000 for 4-20 mA). This is equivalent to 12-bit resolution (4096 = 2^12). The 1/8,000 high-resolution mode provides 8,000 discrete values across the full input range, equivalent to 13-bit resolution (8192 = 2^13). The 1/8,000 mode discriminates finer signals (e.g., 0-10000 PSI would resolve to 1.25 PSI steps vs 2.5 PSI steps at 1/4,000).
