Omron CJ1W-PD025 — 24VDC CJ1 Power Supply, 25W
SKU: CJ1W-PD025USD 70.00
Omron CJ1W-PD025 is a 24V DC input power supply unit for CJ-series PLCs — provides 5VDC/5A to the backplane and 24VDC/0.8A service power, 25W total output, for DC-only installations.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The CJ1W-PD025 is the DC-input version of the CJ1 power supply family. The 'PD' prefix identifies DC input (24V); the 'PA' prefix is AC input (100-240V). The 025 suffix is the 25W output class; the smaller PD022 is 14W. For DC-only installations (battery banks, solar systems, DC bus industrial environments, vehicle and marine applications), the PD025 is the standard pick. The PD025 sits in the leftmost slot of the CJ1 rack and provides: - 5V DC at 5.0A to the CPU Unit and the backplane for I/O and communication units - 24V DC at 0.8A as 'service power supply' for sinking-input I/O terminals - Total output: 25W The 5V rail powers everything in the rack. The 24V service power is a convenience supply for I/O that needs 24V at the terminals (sourcing outputs, sensor excitation, 24V input relay coils). For most CJ1 systems, the 0.8A is enough to power the I/O sourcing circuits; for heavy 24V loads, use an external 24V supply. On the input side, the PD025 accepts 24V DC at 21.6-26.4V operating range. Inrush current is 30A for 20ms at cold start — this is the most important number for selection. Most industrial 24V supplies can handle 30A inrush, but if you're running the PD025 from a small battery or current-limited DC source, you may need a soft-start precharge circuit. The 24V supply must be regulated — connecting to a 24V battery with no regulation can cause undervoltage faults during motor load transients. For new installations, check whether the AC version (PA205R) is acceptable — most industrial sites have 100-240V AC available, and the PA205R is the more popular and widely stocked part. The PD025 is specifically for DC-only systems. Compared to the smaller PD022 (14W), the PD025 supports a larger rack with more I/O and communication units. Most CJ1 systems with 1 CPU + 3-5 I/O units + 1 communication unit can run on PD025. For very large CJ1 racks (CPU + 8+ units), consider the PA205R (AC, 25W with same output but unlimited AC current) for headroom.
Key Features
- Universal AC input 100-240V
- Stable 5VDC output
- Compact CJ1 mount design
- Status LED indicators
- Overcurrent protection
- Thermal shutdown protection
- DIN rail mounting option
- Reliable screw terminals
- SKU: CJ1W-PD025
- Series: CJ1W
- Voltage: 240V
- I/O: 100 I/O
Best-Fit Applications
- Powering a CJ1 PLC system from a 24V battery bank in a telecom site or remote monitoring station
- DC bus industrial installations where 24V is the only power source available on the machine
- Marine and vehicle automation with 24V DC supply from onboard batteries or alternators
- Solar-powered outdoor control cabinets running off a 24V battery bank charged by PV panels
Buying Checklist
- DC 24V input matches modern industrial DC bus standards
- 25W output supports a typical CJ1 rack with 5-7 I/O units and 1-2 communication cards
- Compatible form-factor with AC version for direct swap when supply changes
- 30A inrush handled by most industrial 24V supplies; no special precharge needed
- Standard 24V output service power eliminates need for separate 24V supply for I/O terminals
Technical Specifications
| Model | CJ1W-PD025 |
|---|---|
| Series | CJ1W |
| Type | Power Supply Unit |
| Input Voltage | AC100-240V |
| Output Voltage | 5VDC (backplane) |
| Output Current | 5A |
| Output Power | 25W |
| Protection | Overcurrent, overvoltage |
| Operating Temperature | 0 to +55°C |
| Mounting | CJ series backplane |
Resources & Downloads
FAQ for CJ1W-PD025
What's the difference between CJ1W-PD025 and CJ1W-PA205R?
PD025 takes 24V DC input; PA205R takes 100-240V AC input. Both provide 5V/5A + 24V/0.8A output (25W total). The PD025 is for DC-only installations (battery, solar, DC bus); the PA205R is for AC mains. Most industrial sites use PA205R. Mechanically and functionally they are interchangeable in a CJ1 rack.
Can I use the CJ1W-PD025 with a 12V battery system?
No — the PD025 requires 21.6-26.4V DC, which is outside a 12V battery's range. You'd need a 12V-to-24V boost converter in front of the PD025. A simpler solution for low-voltage DC systems is to use a different PLC family (CP1L for small systems, or add a 24V industrial battery as a UPS on a normal AC installation).
How many CJ1 I/O units can the PD025 power?
5V at 5A is enough for 1 CPU + 5-7 typical I/O units + 1-2 communication units. Check the 5V current draw of each unit in the datasheet — a CJ1W-ID211 (16-point DC input) draws 80mA, a CJ1W-OC211 (16-point output) draws 110mA, and a CJ1W-IC101 (I/O control unit) draws 90mA. A typical mid-size CJ1 system of 1 CPU + 4 I/O + 1 communication draws under 1A — well within the 5A budget.
What size circuit breaker do I need for the inrush current?
The PD025 has 30A inrush for 20ms at cold start. Most industrial 24V supplies with 10-15A continuous rating handle this — the supply's current limit needs to be above 30A for 20ms. Use a 10A slow-blow fuse or 10A C-curve breaker on the input side. If the supply is rated exactly 10A continuous, the PD025 may trip it on startup.
