Omron CJ1W-SCU21-V1 — CJ Serial Unit, 2 x RS-232C
SKU: CJ1W-SCU21-V1USD 105.00
CJ-series serial communication unit with two RS-232C ports, 5 VDC backplane powered, 38.4 kbps, host link / NT link / Modbus-RTU slave.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CJ1W-SCU21-V1 is the CJ-series CPU bus serial communication unit with two RS-232C ports. Each port connects to a single point-to-point RS-232C device at up to 15 m, and each port can run a different protocol independently. The unit pulls 0.28 A from the 5 VDC CJ backplane -- no separate power supply -- and slots into any CPU bus unit position on the CJ rack. Pick the SCU21-V1 when the cabinet needs two short-distance RS-232C devices on one CPU (for example, a barcode reader and a serial-label printer, or two inverters on Host Link).
SCU vs SCU@2 high-speed
The SCU2x-V1 is the standard-speed type at up to 38.4 kbps. The SCU@2 (SCU22 / SCU32 / SCU42) is the high-speed type that adds 115.2 kbps on RS-232C and 230.4 kbps on RS-422A / RS-485 plus the NT-AL001 RS-232C / RS-422A link adapter for 1:N communication. Pick the SCU@2 when a 38.4 kbps ceiling is too slow for the device. For a panel that needs both RS-232C and RS-422A / RS-485, pick the SCU41-V1 mixed-port sibling at 0.38 A. For a 2-port RS-422A / RS-485 install, pick the SCU31-V1.
Per-port protocols
Each of the two ports can be set independently to protocol macro (a sequence of predefined messages), Host Link (SYSWAY-compatible master / slave for CX-Programmer upload), NT Link 1:N (for an NS / NB HMI panel on the SCU port), serial gateway (auto FINS / Host Link / Modbus-RTU conversion), no-protocol (raw byte send / receive), or Modbus-RTU slave (the unit acts only as a slave, not as a master). The serial gateway mode is the typical pick when a third-party Modbus-RTU sensor needs to land on a CJ1 / NJ CPU as FINS.
Before ordering
Confirm the CJ rack has a free CPU bus unit slot (each SCU occupies one CPU-bus unit position). Up to 16 CPU-bus units sit on one CJ rack, so up to 16 SCUs and 32 serial ports per system. Each SCU draws 0.28 A from the 5 VDC backplane, so on a fully-loaded 16-SCU rack the backplane draw tops out around 5 A -- pick the CJ1W-PA205R (5.0 A at 5 VDC) or the CJ1W-PD025 (5.0 A at 5 VDC) PSU. For long-distance RS-422A 1:N, attach the NT-AL001 link adapter to a port and pick the SCU@2 high-speed type.
Key Features
- CJ-series CPU bus serial communication unit with TWO RS-232C ports on D-Sub 9-pin connectors
- Two independent RS-232C point-to-point links up to 15 m cable run
- Each port sets independently: protocol macro, host link, NT link (1:N), serial gateway, no-protocol, Modbus-RTU slave
- 5 VDC 0.28 A from the CJ backplane -- no separate power supply required
- Standard-speed communications at 1,200 to 38,400 bps (the SCU@2 high-speed type adds 115.2 / 230.4 kbps)
- RS-422A / RS-485 1:N multidrop via the NT-AL001 link adapter on each RS-232C port (the SCU21-V1 has no RS-422A port built in)
- Modbus-RTU acts as SLAVE only -- not as a master
- Up to 16 SCUs per CJ rack, up to 32 serial ports system-wide
- COMM1 / COMM2 + RUN / ERC front-panel LEDs
- Mounts in any CJ CPU-bus unit slot (CJ1M / CJ1H / CJ2H / CJ2M CPU racks)
- Pair with the NT-AL001 RS-232C to RS-422A / RS-485 link adapter for 1:N multidrop
- Not hot-swappable -- mount or replace with the CJ rack powered off (same as other CJ CPU-bus units)
- Distinguishing feature vs SCU31-V1: SCU21-V1 is two RS-232C, SCU31-V1 is two RS-422A/485, SCU41-V1 is mixed
- SKU: CJ1W-SCU21-V1
- Series: CJ-series CPU Bus Serial Communication Unit
Best-Fit Applications
- Two short-distance RS-232C devices on one CJ CPU -- barcode reader + serial-label printer, or two inverters on Host Link
- Modbus-RTU slave gateway from a third-party inverter / temperature controller / power meter to a CJ1 / NJ CPU via the SCU serial-gateway mode
- Two Host Link master ports for connecting to older C-series or C200H PLCs on a migration retrofit
- Pair with a CJ1W-CIF11 RS-232C to RS-422A adapter on each port for 1:N long-distance wiring (the CIF11 converts the RS-232C port to RS-422A / RS-485)
- Pick the SCU@2 high-speed sibling (SCU22 / SCU32 / SCU42) when 38.4 kbps is too slow for the device or 230.4 kbps RS-422A / RS-485 is needed
Buying Checklist
- Pick CJ1W-SCU21-V1 for a CJ CPU-bus serial unit with two RS-232C ports at 0.28 A from the 5 VDC backplane.
- Pick CJ1W-SCU31-V1 instead for two RS-422A / RS-485 ports when long-distance multidrop is needed.
- Pick CJ1W-SCU41-V1 instead when one RS-232C and one RS-422A / RS-485 port are both needed on a mixed-port panel.
- Pick CJ1W-SCU22 (SCU@2 high-speed) instead when 38.4 kbps is too slow or 115.2 kbps RS-232C is needed.
- Pick NT-AL001 instead to convert an RS-232C port on the SCU21-V1 to RS-422A for 1:N multidrop wiring.
- Confirm the CJ rack has a free CPU-bus unit slot (up to 16 CPU-bus units per CJ1 / CJ2 CPU rack).
Technical Specifications
| Series | CJ-series CPU Bus Serial Communication Unit |
|---|---|
| Model | CJ1W-SCU21-V1 (two RS-232C ports) |
| Port 1 / Port 2 | RS-232C, D-Sub 9-pin connector |
| Modes | Full duplex RS-232C, point-to-point |
| Communication Speed | 1,200 / 2,400 / 4,800 / 9,600 / 19,200 / 38,400 bps |
| Cable Distance | RS-232C 15 m; RS-422A / RS-485 500 m via NT-AL001 adapter on each port |
| Power | 0.28 A from 5 VDC CJ backplane (no external supply) |
| Protocols per Port (CJ mode) | Protocol macro, host link, NT link 1:N, serial gateway, no-protocol, Modbus-RTU slave |
| Modbus Role | SLAVE only (the SCU does not act as a Modbus-RTU master) |
| Mounting | One CJ CPU-bus unit slot, DIN-rail |
| System Capacity | Up to 16 SCUs per CJ rack, up to 32 serial ports per system |
| Approvals | UL / cULus (Class 1 Div 2) / CE / NK / Lloyd; MADE IN JAPAN |
Resources & Downloads
FAQ for CJ1W-SCU21-V1
What is the difference between CJ1W-SCU21-V1 and CJ1W-SCU31-V1?
The SCU21-V1 has two RS-232C ports (D-Sub 9-pin) for short-distance point-to-point devices (barcode readers, label printers, legacy inverters at up to 15 m). The SCU31-V1 has two RS-422A / RS-485 ports (5-pin terminal block) for long-distance multidrop wiring up to 500 m. Both pull power from the 5 VDC CJ backplane (the SCU21-V1 draws 0.28 A, the SCU31-V1 draws 0.38 A) and run the same per-port protocol set. Pick the SCU21-V1 when both field devices are short-distance RS-232C; pick the SCU31-V1 for an RS-422A / RS-485 multidrop chain.
What protocols does each SCU port support?
On a CJ system, each port can independently run protocol macro (a sequence of predefined send / receive messages), host link (SYSWAY-compatible, for CX-Programmer upload or a third-party SYSWAY master), NT link 1:N (for an NS / NB HMI panel on the same rack), serial gateway (automatic FINS / Host Link / Modbus-RTU conversion), no-protocol (raw byte send / receive), or Modbus-RTU slave (the SCU only acts as a slave, not as a master). On an NJ system the per-port list drops to protocol macro, serial gateway, no-protocol, and Modbus-RTU slave -- host link and NT link are not supported on the NJ via the SCU.
Can the SCU21-V1 talk to a Modbus-RTU master?
Yes -- as a slave. The SCU21-V1 Modbus-RTU mode is slave only; it does not act as a Modbus-RTU master to third-party slaves on the network. For a Modbus-RTU master port on the CJ CPU, use the CJ1W-SCU41-V1 mixed-port sibling (with the SCU running the master mode on the RS-422A / RS-485 port) or the CJ1W-CIF12-V1 isolated RS-485 option board fitted to the CPU option board slot. The Modbus-RTU slave is the typical pick when a third-party sensor (inverter, power meter, scale) needs to land on the CPU as FINS via the serial-gateway mode.
Can the SCU21-V1 run at 115.2 or 230.4 kbps?
No. The SCU21-V1 is the standard-speed type with a top speed of 38.4 kbps on each port. For 115.2 kbps (RS-232C) or 230.4 kbps (RS-422A / RS-485) pick the SCU@2 high-speed type: the SCU22 (2 x RS-232C, 0.28 A), the SCU32 (2 x RS-422A / RS-485, 0.40 A), or the SCU42 (1 x RS-232C + 1 x RS-422A / RS-485, 0.36 A). The SCU@2 also supports the NT-AL001 RS-232C to RS-422A adapter for 1:N link (the SCU21-V1 with the NT-AL001 adapter is limited to 38.4 kbps on the chain). Confirm the field device actually needs more than 38.4 kbps before paying the SCU@2 premium -- most Modbus-RTU slaves happily run at 19.2 kbps.
