Omron CJ1W-SCU42 — CJ SCU@2 Mixed-Port, 1 RS-232 + 1 RS-485
SKU: CJ1W-SCU42USD 158.00
CJ-series SCU@2 high-speed mixed-port serial unit: 1 x RS-232C and 1 x RS-422A/485. 230.4 kbps, 0.36 A.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CJ1W-SCU42 is the mixed-port member of the CJ SCU@2 high-speed serial communication family. Pick it when one cabinet needs one RS-232C point-to-point line and one RS-422A / RS-485 multi-drop line in a single module.
The front face carries COMM1 (RS-232C on a D-Sub 9-pin connector) and COMM2 (RS-422A / RS-485 on a removable 5-pin terminal block). Each port sets independently to protocol macro, Host Link, NT Link 1:N, serial gateway, no-protocol, or Modbus-RTU slave, and runs up to 230.4 kbps in SCU@2 high-speed mode (the standard SCU-V1 family tops out at 38.4 kbps).
Power comes from the CJ backplane at 0.36 A on 5 VDC. The RS-232C port reaches 15 m on a standard cable; the RS-422A / RS-485 port reaches 1,200 m, which is the SCU@2 high-speed advantage over the SCU-V1 standard-speed 500 m ceiling. Add an NT-AL001 RS-232C-to-RS-422A link adapter to convert a port to 1:N long-distance RS-422A comms.
The unit takes one CJ CPU-bus slot (the CJ CPU-bus spec permits up to 16 CPU-bus high-function units per rack / 32 serial ports per system when SCUs are stacked). It is NOT hot-swappable, and Modbus-RTU acts only as a slave. CX-Protocol (CX-Programmer add-on) and CX-Programmer over Ethernet (when a CJ1W-ETN21 or CJ1W-EIP21 sits elsewhere on the rack) cover setup.
Approvals: UC1, N, L, CE. Made in Japan.
Key Features
- CJ-series SCU@2 high-speed CPU-bus serial communication unit
- One RS-232C port on D-Sub 9-pin connector (COMM1) + one RS-422A / RS-485 port on 5-pin terminal block (COMM2)
- Per-port protocol: protocol macro, Host Link, NT Link 1:N, serial gateway, no-protocol, Modbus-RTU SLAVE
- Up to 230.4 kbps per port in SCU@2 high-speed mode (standard SCU-V1 family tops at 38.4 kbps)
- RS-232C cable 15 m; RS-422A / RS-485 cable 1,200 m (SCU@2 advantage over standard 500 m)
- Attach NT-AL001 RS-232C-to-RS-422A link adapter for 1:N long-distance RS-422A chains
- 0.36 A from 5 VDC CJ backplane
- Up to 16 CPU-bus units / 32 serial ports per CJ rack
- NOT hot-swappable; Modbus-RTU acts only as slave
- On an NJ-series CPU, per-port protocol drops to protocol macro / serial gateway / no-protocol / Modbus-RTU slave
- Approvals: UC1, N, L, CE
- Made in Japan
- SKU: CJ1W-SCU42
- Series: CJ-series CPU-bus high-function unit, SCU@2 high-speed family
Best-Fit Applications
- One RS-232C point-to-point link to a barcode scanner + one RS-422A / RS-485 multi-drop to VFDs
- Mixing Host Link on the RS-232C port with Modbus-RTU slave on the RS-485 port in the same CJ rack
- Long-distance (up to 1,200 m) RS-422A / RS-485 chains where the SCU-V1 500 m would not reach
- Adding serial gateway routing from a CJ PLC to a Modbus-RTU slave field device
- Skid-mount controller where COMM2 needs a screw-terminal RS-485 and COMM1 needs a D-Sub RS-232C
- Protocol-macro custom message exchange on the RS-232C port while RS-485 runs a standard protocol
Buying Checklist
- Pick the CJ1W-SCU42 when one cabinet needs one RS-232C and one RS-422A / RS-485 port in a single high-speed (230.4 kbps) module.
- Pick the CJ1W-SCU22 instead when both ports should be RS-232C.
- Pick the CJ1W-SCU32 when both ports should be RS-422A / RS-485.
- Pick the CJ1W-SCU41-V1 for a mixed-port module on the standard-speed (38.4 kbps / 500 m RS-422A) family.
- Pick the CJ1W-SCU21-V1 when the cabinet only needs RS-232C on the standard-speed family.
- Confirm spare CJ CPU-bus slots — the SCU42 takes one slot and counts toward the 16-units-per-rack limit.
Technical Specifications
| Series | CJ-series CPU-bus high-function unit, SCU@2 high-speed family |
|---|---|
| Model | CJ1W-SCU42 |
| Ports | 1 x RS-232C (D-Sub 9-pin) + 1 x RS-422A / RS-485 (5-pin removable terminal block) |
| Max Baud Rate | 230.4 kbps per port (SCU@2 high-speed) |
| Cable Run | RS-232C 15 m; RS-422A / RS-485 1,200 m |
| Protocols (CJ1 system) | Protocol macro, Host Link, NT Link 1:N, serial gateway, no-protocol, Modbus-RTU slave |
| Protocols (NJ system) | Protocol macro, serial gateway, no-protocol, Modbus-RTU slave (Host Link and NT Link not supported) |
| Current Draw | 0.36 A at 5 VDC from CJ backplane |
| Per-rack Limit | Up to 16 SCU / high-function CPU-bus units / 32 serial ports per CJ rack |
| Hot-Swap | Not supported |
| Dimensions | 31 x 90 x 65 mm (slim CJ CPU-bus form factor) |
| Approvals | UC1, N, L, CE |
Resources & Downloads
FAQ for CJ1W-SCU42
What is the difference between CJ1W-SCU42 and CJ1W-SCU41-V1?
SCU42 is on the SCU@2 high-speed family (up to 230.4 kbps, RS-422A / RS-485 cable runs to 1,200 m). SCU41-V1 is on the SCU-V1 standard-speed family (up to 38.4 kbps at standard mode / 115.2 kbps at high-speed mode, RS-422A / RS-485 cable runs to 500 m). Both carry one RS-232C and one RS-422A / RS-485 port. Pick SCU42 for new high-speed builds; pick SCU41-V1 as a like-for-like spare on an existing standard-speed rack.
Is the CJ1W-SCU42 hot-swappable?
No. CJ-series SCUs are not hot-swappable — power the rack down before inserting or removing an SCU42. (The SRT2-series SmartSlice I/O blocks and a few CS1D duplex modules support hot-swap; the CJ1W-SCU42 does not.)
Can the CJ1W-SCU42 act as a Modbus-RTU master?
No. The SCU42 lists Modbus-RTU SLAVE in its per-port protocol menu, not master. Use the SCU as a slave and let the CJ CPU scan it via the serial gateway, or use a dedicated master module if the field device is a slave that the PLC needs to poll.
How many CJ1W-SCU42 units can sit on one CJ rack?
Up to 16 CPU-bus high-function units per CJ / CJ2 rack (CPU plus expansion racks), which gives up to 32 serial ports in the system when SCUs are the limiting factor. Confirm spare slots when planning a multi-SCU build.
