Omron CK3W-MD7110 — 16-In / 16-Out Digital I/O
SKU: CK3W-MD7110USD 441.00
16-in / 16-out NPN digital I/O for CK3M / CK5M, 24 VDC, push-in terminal. In stock, China.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CK3W-MD7110 is a CK3W-series Digital I/O Unit with 16 inputs and 16 NPN outputs for the CK3M and CK5M Programmable Multi-Axis Controllers It is manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.
Inputs and outputs both run at 24 VDC, and the outputs switch up to the CK3M / CK5M servo cycle of 25 us per 5 axes for deterministic actuation. The push-in terminal block accepts solid, stranded, and ferrule wires without tools.
Body size is 31.6 x 90 x 80 mm at 143 g. Key specs: Inputs 16 digital inputs, 24 VDC; Outputs 16 NPN digital outputs, 24 VDC; Rated Input Voltage 24 VDC; Output Type NPN open collector; Cycle Synchronization 25 us / 5 axes with CK3M / CK5M; External Connection Push-in terminal block (screwless); Power Consumption 1.0 W max at 5 VDC; Dielectric Strength 510 VAC for 1 minute between isolated circuits.
Key Features
- CK3W-series Digital I/O Unit for CK3M / CK5M motion controllers
- 16 DC inputs + 16 NPN outputs, 24 VDC rated, push-in terminal block
- Synchronized to the CK3M / CK5M 25 us servo cycle for high-speed actuation
- 31.6 x 90 x 80 mm, 143 g, IP20, cULus / EN 61326 / RCM / KC / EAC
- SKU: CK3W-MD7110
- Series: CK3W-series Digital I/O Unit
- Voltage: 24 VDC
Best-Fit Applications
- CNC router where the CK3W-MD7110 handles the auxiliary I/O for tool-change, coolant pump, and limit-switch feedback alongside the G-code motion path.
- Semiconductor wafer-handling robot where 16 inputs capture vacuum and proximity feedback and 16 outputs actuate end-effector solenoid valves.
- Multi-station assembly press where the 16 outputs synchronize light-stack indicators and ejector pins with the press motion profile.
Buying Checklist
- Choose the CK3W-MD7120 instead when PNP sourcing outputs are required for the same load class.
- Choose the CK3W-MD7110 when the cabinet needs 16 NPN outputs synchronized to the CK3M / CK5M 25 us servo cycle.
- Verify the push-in terminal block accepts 0.5 mm² stranded wire for clean tool-free replacement during commissioning.
Technical Specifications
| Series | CK3W-series Digital I/O Unit |
|---|---|
| Inputs | 16 digital inputs, 24 VDC |
| Outputs | 16 NPN digital outputs, 24 VDC |
| Rated Input Voltage | 24 VDC |
| Output Type | NPN open collector |
| Cycle Synchronization | 25 us / 5 axes with CK3M / CK5M |
| External Connection | Push-in terminal block (screwless) |
| Power Consumption | 1.0 W max at 5 VDC |
| Dielectric Strength | 510 VAC for 1 minute between isolated circuits |
| Insulation Resistance | 20 MOhm min at 100 VDC |
| Operating Temperature | 0 to 55 degC, 10 to 95 percent (no condensation) |
| Dimensions | 31.6 x 90 x 80 mm, 143 g, IP20 |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for CK3W-MD7110
Does the CK3W-MD7110 need a CK3M or CK5M controller?
Yes - the CK3W-MD7110 mounts only on a CK3M or CK5M Programmable Multi-Axis Controller, not on a CJ, NJ or NX CPU. The MD7110 uses the CK-bus expansion bus and the 25 us servo cycle. For standard PLC cabinets, use NX-MD6121-5 or NX-OD4256 instead.
What is the difference between CK3W-MD7110 and CK3W-MD7120?
The MD7110 is the NPN output version. The MD7120 is the PNP output version with the same 16 inputs / 16 outputs layout. Pick by the input / output common the machine uses. The mechanical size and wiring block are identical between the two.
Can the CK3W-MD7110 be synchronized with motion events?
Yes - the 16 outputs can be triggered by motion-event logic in the CK3M / CK5M controller, including cam switches, position triggers, and error-stop events. Synchronization to the 25 us servo cycle keeps output jitter under one cycle for high-speed packaging and semiconductor applications.
Is the CK3W-MD7110 safety-rated?
No - the CK3W-MD7110 is a standard (non-safety) I/O module. For safety I/O on the CK platform, use the NX-SL3300 Safety CPU on a separate NX-ECC203 EtherCAT sub-node. Safety devices like E-stops and interlocks must run on the FSoE subnet, not on the CK3W bus.
