Omron CP1L-M30DR-A — CP1L CPU, 30 I/O, AC, USB
SKU: CP1L-M30DR-AUSD 160.00
Omron CP1L-M30DR-A CP1L M30 CPU, 18 DC in / 12 relay out, 100-240 VAC, 10K steps, USB. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CP1L-M30DR-A is a 30-point M-type CPU unit from the CP1L compact PLC family, manufactured by Omron Corporation. Hengyixin Automation stocks this controller in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports. CP1L-M40DT-D has a published 2027-06-30 production end; this variant needs confirmation from Omron.
The unit ships with 18 digital inputs (24 VDC, PNP or NPN) and 12 relay outputs (2 A) on removable terminal blocks. Program capacity is 10K steps and data memory is 32K words. Logic execution is 0.55 microseconds per LD instruction. Four inputs double as 100 kHz high-speed counters.
Built-in ports are USB only (no built-in RS-232C, no built-in Ethernet). Three CP1W expansion units add up to 150 I/O and up to 25 analog channels with option boards. The body is 130 x 90 x 85 mm, 610 g, DIN-rail mounted. For 14 or 20 I/O on the same M-type, pick the CP1L-L20DR-A. For a CP1H upgrade with the same 30 I/O, pick the CP1H-X40DR-A.
Key Features
- CP1L M-type 30-point CPU with 18 DC inputs and 12 relay outputs (2 A)
- 10K steps program, 32K words data, 0.55 us LD execution
- Built-in USB (no built-in RS-232C), 4 high-speed counter inputs at 100 kHz
- 100-240 VAC supply, 300 mA aux 24 VDC, up to 3 CP1W expansion units, 610 g
- SKU: CP1L-M30DR-A
- Series: Omron CP1L-series M-type compact PLC
- Voltage: 100 TO 240 VAC
Best-Fit Applications
- Small machine retrofit where the CX-Programmer project loads over USB and the HMI talks through a CP1W-CIF01 RS-232C option board
- Compact conveyor cell where the 32K words data holds the recipe table and the 100 kHz counters track the encoder
- Spare CPU drop-in for an existing CP1L-M30DR-A cell where the project backup is already on a CP1W-ME05M memory cassette
Buying Checklist
- Pick the CP1L-M30DR-A for a 30-I/O CP1L M-type CPU with 100-240 VAC supply, USB and 10K steps.
- Pick the CP1L-L20DR-A instead when the cabinet needs 20 I/O on the same L-type platform.
- Pick the CP1L-EM30DT-D instead when the cell needs built-in Ethernet and transistor outputs on the same 30-I/O body.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron CP1L-series M-type compact PLC |
| Model / SKU | CP1L-M30DR-A |
| Supply Voltage | 100 to 240 VAC, 50/60 Hz (operating range 85 to 264 VAC) |
| Digital Inputs | 18 x 24 VDC (PNP or NPN); 4 are 100 kHz high-speed counters |
| Digital Outputs | 12 x relay, 250 VAC 2 A resistive |
| Program Capacity | 10K steps |
| Data Memory | 32K words |
| LD Execution Time | 0.55 us per basic instruction |
| Communication Ports | USB 2.0 programming (no built-in RS-232C) |
| Expansion | Up to 3 CP1W expansion units; max 150 I/O; max 25 analog channels |
| Dimensions / Weight | 130 (W) x 90 (H) x 85 (D) mm; 610 g |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for CP1L-M30DR-A
Does the CP1L-M30DR-A have a built-in RS-232C port?
No. The M-type has USB only. For RS-232C, fit the CP1W-CIF01 option board in one of the two option-board slots. For RS-422A or RS-485, fit the CP1W-CIF11 (non-isolated) or CP1W-CIF12-V1 (isolated).
When does the CP1L-M30DR-A reach end of production?
CP1L-M40DT-D has a published 2027-06-30 production end; this variant needs confirmation from Omron. For a longer-life replacement on the same form factor, use the CP2E-N60DR-D (60 I/O, 2 Ethernet, battery-free) or the CP1L-EM30DT-D (CP1L with built-in Ethernet).
What is the difference between the CP1E and CP1L?
The CP1L adds more program and data memory (10K steps and 32K words vs. 8K and 8K), faster LD execution (0.55 us vs. 1.19 us), four 100 kHz counters instead of six 10 kHz, and function-block programming. The CP1E keeps the RS-232C port the CP1L drops.
