Omron CP1L-EM30DT-D — 30 I/O PLC, Ethernet, NPN
SKU: CP1L-EM30DT-DUSD 215.00
CP1L-EM compact PLC, 18 DC inputs / 12 NPN-sinking outputs, built-in Ethernet, 10K-step program, 24 VDC supply, 100 kHz HSC + pulse.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron CP1L-EM30DT-D is the 30-I/O Ethernet-equipped compact PLC in the CP1L line. It has 18 DC inputs and 12 NPN-sinking transistor outputs on the base unit, a built-in 10/100 base-T Ethernet port for FINS/UDP, FINS/TCP, and socket service, a 10K-step program, and 24 VDC supply on the same removable terminal block. The DT suffix means NPN (sinking) -- the output pulls to common when active, which is the standard polarity for Omron's CP1W / CP2E expansion output cards and most Japanese PLC wiring.
Where the 4-axis HSC and 2-axis pulse output fit
The 4 high-speed counter inputs at 100 kHz single-phase (50 kHz differential) are enough for one or two incremental encoders on a conveyor or a feeder, plus a third / fourth position sensor on a cutoff or indexing station. The 2 pulse outputs at 100 kHz can drive two stepper-motor indexers, two variable-frequency drives in pulse-following mode, or one pulse + direction axis and one PWM output. The HSC and pulse-output counts are on the EM30DT-D, not on the smaller L14 or EL20 heads.
Ethernet vs USB-only siblings
Pick the CP1L-EM30DT-D (this SKU) when the PLC needs Ethernet for SCADA polling, remote HMI access, or NB-series HMI / NJ controller peer-to-peer. Pick the CP1L-M30DT-D instead when the cabinet has no Ethernet and the program is uploaded via the USB programming port. Pick the CP1L-EL20DT-D when the application only needs 20 I/O but still wants Ethernet -- the EL line saves cabinet space and budget.
Before ordering
Confirm the supply is 24 VDC -- for 100-240 VAC supply, order the matching CP1L-EM30DR-A (relay output) or CP1L-EM30DT-A (NPN sink). Confirm the load is NPN (sinking) -- for a PNP (sourcing) load, order CP1L-EM30DT1-D instead. Add up to 3 CP1W expansion units on the right side of the head for up to 160 total I/O; add a CP1W-CIF11 / CIF12-V1 option board for serial RS-232C / RS-485 if the field device speaks Modbus RTU or Host Link.
Key Features
- CP1L-EM-series compact PLC with built-in 10/100 base-T Ethernet port
- 30 built-in I/O: 18 DC inputs (24 VDC) + 12 NPN-sinking transistor outputs
- 10K-step program memory, 32K-word data memory, 0.1 us basic instruction
- 4-axis 100 kHz high-speed counter (single-phase) / 2-axis 100 kHz pulse output
- DT = NPN (sinking) open-collector, 0.3 A per point, 1.2 A per common
- D = 24 VDC supply (the -A suffix is 100-240 VAC)
- Up to 3 CP1W expansion units / 160 I/O total, 1 option-board serial slot
- CX-Programmer / CX-One programming, FB / ST language compatible
- DIN-rail 90 mm wide body, 0 to +55 C operating
- UL 508 / cULus / CE / C-Tick / KC approved
- SKU: CP1L-EM30DT-D
- Series: CP1L-EM30DT-D
- Voltage: 24 VDC
- I/O: 18 I/O
Best-Fit Applications
- Packaging line control with encoder feedback on a 30-I/O footprint
- Small conveyor system with two inverter pulse-following axes and a remote HMI
- Test fixture with 4-axis HSC for position verification and 2-axis pulse for feeder index
- OEM machine builder standardising on Ethernet for remote support and SCADA polling
- Material-handling cell with Modbus RTU on the option-board port plus Ethernet for HMI
Buying Checklist
- Pick CP1L-EM30DT-D for 30 I/O with built-in Ethernet, 4-axis 100 kHz HSC, and 2-axis 100 kHz pulse on 24 VDC supply.
- Pick CP1L-EM30DT1-D instead when the load is PNP (sourcing) instead of NPN (sinking).
- Pick CP1L-EM30DR-D instead when the load is a contactor coil, indicator lamp, or 250 VAC relay and you need dry contacts.
- Pick CP1L-M30DT-D instead when the PLC has no Ethernet and uploads over USB only (saves money).
- Pick CP1L-EL20DT-D when the application only needs 20 I/O and you want Ethernet in the smaller head.
- Add a CP1W-CIF11 (RS-232C) or CP1W-CIF12-V1 (RS-422/485) option board for Modbus RTU / Host Link serial port.
Technical Specifications
| I/O Count | 18 DC inputs / 12 NPN-sinking outputs (30 total) |
|---|---|
| Output Type | NPN open-collector, 0.3 A per point, 1.2 A per common |
| Supply Voltage | 24 VDC (D suffix; A suffix is 100-240 VAC) |
| Program Memory | 10K steps, 32K-word data |
| Basic Instruction | 0.1 us / LD, 0.3 us / MOV |
| High-Speed Counter | 4-axis at 100 kHz single-phase, 50 kHz differential |
| Pulse Output | 2-axis at 100 kHz transistor |
| Communication | 10/100 base-T Ethernet (FINS/TCP/UDP + socket) |
| Serial Option | 1 option-board slot, RS-232C or RS-422/485 |
| Expansion | Up to 3 CP1W units, 160 I/O total |
| Dimensions | DIN-rail 90 mm wide body |
| Operating Temperature | 0 to +55 C |
Resources & Downloads
FAQ for CP1L-EM30DT-D
What is the difference between CP1L-EM30DT-D and CP1L-EM30DT1-D?
Output polarity. The DT suffix is NPN (sinking) -- the output pulls to common when active, suitable for an Omron-style PLC input or a load that expects a switched-low signal. The DT1 suffix is PNP (sourcing) -- the output sources +24 V when active, suitable for a European-style PLC input or a load that expects a switched-high signal. Both have the same 30 I/O count, Ethernet port, HSC count, and program memory. The only difference is the output transistor polarity.
How many high-speed counter inputs does this PLC have?
4 axes at 100 kHz single-phase (50 kHz differential or 2-phase). The 4 counters are on the same input terminals as the regular DC inputs, so each HSC input replaces one general-purpose input. For more HSC axes, the CP1H-X or CP1H-Y is the upgrade path; for a 4-axis HSC on a small PLC, the EM30DT-D is the right size.
Can the CP1L-EM30DT-D accept 100-240 VAC supply?
No. The D suffix is 24 VDC supply only. For a 100-240 VAC cabinet, the matching SKU is the CP1L-EM30DR-A (relay output) or the CP1L-EM30DT-A (NPN transistor output) -- the A suffix swaps the DC supply for a wide-range AC supply. The I/O count, Ethernet port, and HSC count are identical.
What is the program memory size?
10K steps of program memory and 32K words of data memory. The 10K figure is the EM/EL head capacity; the M40/60 head is 5K steps, the L10/14/20 head is 5K steps. For programs above 10K, step up to the CP1H-X (20K) or the CJ2M-CPU3x (30-60K). The EM30DT-D also supports structured text (ST) and function block (FB) programming via CX-Programmer / CX-One.
