Part of the Omron CP-Series Compact PLCs series — see the full model table, lifecycle status and replacement parts.

Omron CP1W-ME05M — top face of the CP1-series EEPROM memory cassette showing the green PCB, the EEPROM chip in the centre, the gold contact strip at the bottom that mates with the CP1L or CP1H option slot, the CP1W-ME05M part-number label and the orientation notch on the left edge

Omron CP1W-ME05M — CP1L/CP1H Memory Cassette, 512K

SKU: CP1W-ME05M

USD 29.00

Omron CP1W-ME05M EEPROM memory cassette for CP1L and CP1H PLCs, 512K words, non-volatile, auto-boot. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron CP1W-ME05M is the CP1-series EEPROM Memory Cassette, manufactured by Omron Corporation. Hengyixin Automation stocks this controller option board in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

It slots into the option-board bay on the front of a CP1L-EL, CP1L-EM, CP1H-X, or CP1H-Y CPU and holds 512 Kwords of non-volatile data - the user program, PLC Setup parameters, I/O comments, function block sources, and DM initial values. Retention is around 20 years at 25 C and the chip supports around 100,000 write cycles. Set DIP switch SW2 to ON at power-up and the CPU auto-boots the program from the cassette without a CX-Programmer connection.

Typical use is shipping a duplicate program into a sister machine or backing up a CP1L project before a firmware update. The cassette is NOT compatible with the CP1E family (CP1E has no option-board slot). For a CP1L with RS-485 on the same option slot, choose the CP1W-CIF11 instead.

Key Features

  • CP1-series EEPROM Memory Cassette, 512 Kwords (approximately 1 MB), for CP1L-EL/EM and CP1H-X/Y CPUs
  • Stores user program, PLC Setup, I/O comments, function block sources, and DM initial values
  • Auto-boot from the cassette when DIP switch SW2 is ON at power-up, no CX-Programmer required
  • Approximately 20-year data retention at 25 C and approximately 100,000 write cycles; not compatible with CP1E
  • SKU: CP1W-ME05M
  • Series: CP1-series option-board accessory, memory cassette

Best-Fit Applications

  • Duplicating the user program onto a sister CP1L-EM30DT-D before a swap-out so the new PLC boots the same logic without a laptop
  • Backing up a CP1H-X40DR-A project before a firmware upgrade so the cassette can restore the program if the flash erase fails
  • Storing a recipe on a CP1L-M40DR-A packaging line where the operator pulls a recipe cassette to change product SKU in seconds

Buying Checklist

  • Pick the CP1W-ME05M when the project needs up to 512 Kwords of user program plus comments and FB sources on a CP1L or CP1H CPU.
  • Pick the CP1W-CIF11 instead when the option slot needs RS-422A or RS-485 communication instead of program backup.
  • Pick a CP2E-N40DR-D instead when the project is a new build, since CP2E has no option slot and uses its own project memory.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series CP1-series option-board accessory, memory cassette
Model / SKU CP1W-ME05M
Memory Type Non-volatile EEPROM, 512 Kwords (approximately 1 MB)
Compatible CPUs CP1L-EL, CP1L-EM, CP1H-X, CP1H-Y
Data Stored User program, PLC Setup and CPU Bus Unit settings, I/O comments, rung comments, program comments, function block sources, DM initial values
Retention / Endurance Approximately 20 years at 25 C; approximately 100,000 write cycles
Read / Write Method CX-Programmer read/write, or auto-boot on power-up with DIP switch SW2 = ON
Mounting Slots into the option-board bay on the front of the CP1L or CP1H CPU
Incompatibility Not compatible with CP1E (CP1E has no option-board slot)
Weight / Dimensions 10 g, EEPROM in a 25 x 45 x 5 mm cartridge
Environment 0 to 55 C operating, 10 to 90 percent humidity (no condensation); storage -20 to 75 C

FAQ for CP1W-ME05M

What is the Omron CP1W-ME05M used for?
It is the CP1-series EEPROM Memory Cassette that slots into the option-board bay on a CP1L-EL / CP1L-EM or CP1H-X / CP1H-Y CPU. Typical uses are duplicating a user program onto a sister PLC, backing up a project before a firmware upgrade, and swapping recipes on a CP1L packaging line without a laptop.
Does the CP1W-ME05M work with CP1E CPUs?
No. The CP1E family has no option-board slot on the front of the CPU, so the CP1W-ME05M cannot fit. For CP1E program backup use the CX-Programmer project file on a USB stick or PC. The ME05M is for CP1L and CP1H only.
How do I auto-boot a program from the CP1W-ME05M?
Power down the CP1L or CP1H CPU, insert the ME05M cassette into the option-board bay, and set DIP switch SW2 on the front of the CPU to ON. On the next power-up the CPU copies the program from the cassette into internal RAM and runs it. Turn SW2 back OFF so later edits are not overwritten from the cassette.
How long does the CP1W-ME05M keep its data without power?
Around 20 years at 25 C. The EEPROM chip supports around 100,000 write cycles before the cells start to wear out, which is enough for daily recipe swaps for many years. CX-Programmer reads and writes the cassette through the USB or RS-232C port on the front of the CPU.
