Omron E2B-M12KS02-WP-C1 2M — M12 Inductive, 2 mm, NPN
SKU: E2B-M12KS02-WP-C1 2MUSD 11.00
Omron E2B-M12KS02-WP-C1 2M M12 shielded inductive sensor, 2 mm, NPN NO, 2 m PVC cable, IP67. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron E2B-M12KS02-WP-C1 2M is an M12 shielded inductive proximity sensor from the E2B family, manufactured by Omron Corporation. Hengyixin Automation ships this sensor from our Xiamen warehouse with a 30-day DOA return window and a datasheet PDF included in the box.
The sensor detects ferrous metal at 2 mm with a flush mount. The nickel-plated brass body is 47 mm long with a 30 mm thread, and the 2 m PVC prewired cable exits the back. Output is NPN normally open, 3-wire, 10 to 30 VDC supply at 200 mA max load. Response frequency is 1,500 Hz.
A yellow LED on the back of the body shows the output state. The unit is IP67 sealed and operates from -25 to +70 degC, with reverse-polarity, surge and short-circuit protection on the output. For an M12 4 mm NPN NO variant, pick the E2B-M12KS04-WZ-B1 2M. For an M8 2 mm PNP NO, pick the E2B-S08KS02-MC-B1. For the legacy E2E-series with an M12 connector on the same 2 mm shielded spec, pick the E2E-X2D1-M1.
Key Features
- E2B M12 shielded inductive proximity sensor, 2 mm sensing distance, flush mount
- NPN normally open 3-wire output, 10-30 VDC supply, 200 mA max load
- 47 mm nickel-plated brass body, 30 mm thread, 2 m PVC prewired cable
- 1,500 Hz response, IP67, -25 to +70 degC, yellow operation LED
- SKU: E2B-M12KS02-WP-C1 2M
- Series: Omron E2B-series M12 cylindrical inductive proximity sensor
- Voltage: 10 TO 30 VDC
Best-Fit Applications
- Tool-presence check on a CNC chuck where the 2 mm shielded detect picks the M12 tool shank through the steel chip guard
- Conveyor pallet-position feedback on a packaging line where the NPN NO output ties into a CP1W transistor input without an interposing relay
- Spare replacement on a vibratory feeder bowl where the original 2-wire sensor failed and the flush-mount 2 mm detect fits the same bracket
Buying Checklist
- Pick the E2B-M12KS02-WP-C1 2M for an M12 shielded 2 mm NPN NO inductive sensor with a 2 m PVC prewired cable.
- Pick the E2B-M12KS04-WZ-B1 2M instead when the application needs 4 mm range on the same M12 shielded body.
- Pick the E2E-X2D1-M1 instead when the panel needs the legacy E2E-series with an M12 connector on the same 2 mm shielded spec.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron E2B-series M12 cylindrical inductive proximity sensor |
| Model / SKU | E2B-M12KS02-WP-C1 2M |
| Sensing Method | Inductive, shielded (flush mount) |
| Sensing Distance | 2 mm |
| Standard Target | 12 x 12 x 1 mm mild steel |
| Output | NPN normally open, 3-wire |
| Supply Voltage | 10 to 30 VDC |
| Load Current | 200 mA max |
| Response Frequency | 1,500 Hz |
| Connection | 2 m PVC prewired cable |
| Protection / Material | IP67; nickel-plated brass body, PBT sensing face; -25 to +70 degC |
FAQ for E2B-M12KS02-WP-C1 2M
What metal can the E2B-M12KS02-WP-C1 2M detect?
Ferrous metal at the full 2 mm rated distance. The sensing distance drops on non-ferrous metals (stainless steel, aluminium, brass) and on thinner targets. Use a 12 x 12 x 1 mm mild-steel target for the published 2 mm spec.
Can this sensor mount in a steel bracket?
Yes. The shielded body lets it sit flush against ferrous metal without reducing the sensing range. For non-shielded bodies, the surrounding metal must stay at least one body diameter away from the sensing face.
Is the cable oil-resistant?
Standard PVC cable. For cutting-fluid or oil-rich environments, order the E2B-M12KS02-WP-C1 5M with the oil-resistant PUR cable option or switch to the E2EQ series.
What does the C1 in the SKU mean?
C1 = cable exit on the rear axial face of the sensor. The C2 suffix is cable exit on the right side and the C3 suffix is cable exit on the left side. The body and sensing spec are identical.
