Omron E2B-S08KS02-WP-C1 2M — M8 Inductive Sensor, 2 mm
SKU: E2B-S08KS02-WP-C1 2MUSD 7.50
Omron E2B-S08KS02-WP-C1 2M M8 inductive sensor, stainless, 2 mm, NPN NO, 2 m. In stock, China shipping.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron E2B-S08KS02-WP-C1 2M is a short-body M8 inductive proximity sensor from the E2B series, manufactured by Omron Corporation. Hengyixin Automation ships this sensor from our Xiamen warehouse with a 30-day DOA return window and a datasheet PDF included in the box.
The sensor detects ferrous metal up to 2 mm from the front face, with the shielded (flush) body allowing direct mounting in metal brackets. Output is NPN normally open on a 3-wire DC circuit. Supply is 10 to 30 VDC; maximum load current is 200 mA at 32 VDC max with a 2 V residual voltage. Response frequency is 1.5 kHz.
The 42 mm stainless steel housing carries a 2 m PVC pre-wired cable; threaded length is 27 mm. The 360-degree yellow LED confirms the switch from any direction. Protection covers output reverse polarity, supply reverse polarity, surge, and short-circuit. IP67 / IP67G / IP69K rated, -25 to +70 C. The E2B-M12KN05-WZ-B1 is the long-body M12 NPN NO sibling at 5 mm.
Key Features
- E2B-series M8 stainless steel inductive proximity sensor, short body, shielded flush mount, 2 mm sensing distance
- DC 3-wire NPN normally open, 10-30 VDC supply, 200 mA max load, 2 V max residual voltage, 1.5 kHz response
- 42 mm overall length, 27 mm threaded length, 2 m PVC pre-wired cable, 360-degree yellow operation LED
- IP67 / IP67G / IP69K rated, built-in surge + reverse-polarity + short-circuit protection, -25 to +70 C operating
- SKU: E2B-S08KS02-WP-C1 2M
- Series: Omron E2B-series M8 cylindrical inductive proximity sensor
- Voltage: 10 TO 30 VDC
Best-Fit Applications
- Small-tool position confirmation on a desktop CNC tool changer where the 2 mm shielded M8 body fits between the collet and the spindle nose
- Parts-present detection on a vibratory bowl feeder output where a 2 mm M8 sensor through a bracket flags the part on the track
- Spare replacement on a pharmaceutical blister line where the previous M8 prox has failed and an IP67 stainless body is needed for weekly washdown cycles
Buying Checklist
- Pick the E2B-S08KS02-WP-C1 2M for a shielded M8 NPN normally open proximity sensor at 2 mm on a stainless short body with IP67 / IP69K rating.
- Pick the E2B-M12KN05-WZ-B1 instead when the bracket needs an M12 long-body NPN NO at 5 mm sensing.
- Pick the E2B-S08KN04-MC-B1 2M instead when the wiring is PNP sourcing for the same M8 body at 4 mm.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron E2B-series M8 cylindrical inductive proximity sensor |
| Model / SKU | E2B-S08KS02-WP-C1 2M |
| Size | M8 stainless steel short body |
| Sensing Distance | 2 mm nominal, 0 to 1.6 mm setting distance |
| Mounting | Shielded (flush mountable) |
| Output Type | NPN normally open, DC 3-wire |
| Supply Voltage | 10 to 30 VDC |
| Load Current | 200 mA max at 32 VDC max, 2 V max residual voltage |
| Response Frequency | 1.5 kHz |
| Connection | 2 m PVC pre-wired cable |
| Environment / Mounting | 42 mm overall length, 27 mm threaded length, IP67 / IP67G / IP69K, -25 to +70 C operating, 35 to 95% RH non-condensing, EMC IEC 60947-5-2 compliant |
FAQ for E2B-S08KS02-WP-C1 2M
What is the Omron E2B-S08KS02-WP-C1 2M used for?
It is a small M8 shielded inductive proximity sensor for position confirmation and parts-present detection. The 2 mm sensing distance and short 42 mm body fit on tight-mounting fixtures where M12 or M18 sensors do not.
E2B-S08KS02-WP-C1 2M vs E2B-S08KS02-MC-B1 - what is the difference?
The WP-C1 is NPN normally open on a pre-wired 2 m PVC cable. The MC-B1 is the same M8 body and 2 mm sensing distance but with a PNP normally open output on the same pre-wired cable. Pick the WP-C1 for sinking inputs and the MC-B1 for sourcing inputs.
Is the E2B-S08KS02-WP-C1 2M shielded?
Yes. The sensor is shielded (flush-mountable), so it can be installed in a metal bracket without derating the sensing distance. The 2 mm nominal range applies at the rated 24 VDC supply.
What is the IP rating of the E2B-S08KS02-WP-C1 2M?
IP67, IP67G, and IP69K. The sensor withstands temporary immersion, oil exposure, and high-pressure hot water washdown. Operating temperature is -25 to +70 C in 35 to 95% RH non-condensing ambient.
