Omron E3FB-DP22 photoelectric sensor — front face with red LED indicator and 18mm threaded brass body

Omron E3FB-DP22 — M18 Diffuse Sensor, 300mm, PNP

SKU: E3FB-DP22

USD 22.00

Omron E3FB-DP22 is an M18 brass-bodied diffuse-reflective photoelectric sensor with 300mm sensing distance, PNP output, M12 connector, and IP67 rating for harsh industrial environments.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The E3FB-DP22 is the 300mm diffuse-reflective variant in Omron's E3FB family of M18 threaded photoelectric sensors. The 'E3FB' code marks the family: F = full nickel-plated brass body (vs the E3FA plastic), B = standard cylindrical axial (vs E3RB side-view). The 'D' is diffuse-reflective, 'P' is PNP output, '2' is 300mm range, and '2' is the M12 connector. Diffuse-reflective means the sensor has both emitter and receiver in the same housing; it detects light reflected back from the target. This makes it ideal for short-range part detection on conveyors, in feeders, and at machine stations. The 300mm range is the most common spec for OEM machines — close enough for precise detection of small parts, far enough to mount the sensor away from the target zone. The brass housing matters more than it sounds. Plastic-bodied sensors (E3FA) are fine for clean panels and indoor equipment. The E3FB brass housing survives: - Coolant and cutting fluid splash in machining cells - Solvent and cleaning chemical exposure in food/pharma - Mechanical impact from dropped tools or parts - Thermal cycling from 0°C to 70°C without warping The IP67 rating means the sensor is dust-tight and survives temporary immersion. For washdown or outdoor installations, the E3FB is the right pick over the E3FA. On the wiring side, the M12 connector is the 4-pin industrial standard. PNP output sources current on the output line — connects to a PLC input configured for sinking (the standard for Omron CP1, CJ2, NX, NJ). The Light-ON/Dark-ON mode is set by the wiring of pin 2 (input): connecting pin 2 to 24V sets Light-ON (output active when target is present), connecting to 0V sets Dark-ON. The 0.5ms response is fine for most conveyor and feeder applications; for high-speed (>1 kHz) part counting, look at the E3FB-LP[] series with 0.1ms response. The M18 threaded body with two knurled nuts makes panel mounting simple: drill an 18mm hole, drop the sensor through, tighten the nuts. No bracket required for most installations. The 4-pin M12 pigtail cable (e.g., XS2F-D421-D80-F for 2m, or XS2F-D421-G80-F for 5m) plugs into the back. Common use: detecting part presence on a vibratory feeder bowl, confirming cap orientation on a bottle line, end-of-stroke detection on a pneumatic cylinder, counting parts in a small parts handling cell. The brass housing makes the E3FB the right pick for any cell with coolant, oil, or cleaning chemicals.

Key Features

  • Sensing Range: Up to 100mm
  • Output Type: PNP
  • Supply Voltage: DC12-24V
  • Response Time: 1ms
  • Light Source: Red LED
  • Protection: IP67/IP69K
  • SKU: E3FB-DP22
  • Series: E3FB
  • Voltage: 24V

Best-Fit Applications

  • Detecting part presence on a vibratory feeder bowl in electronics assembly cells
  • Confirming cap orientation on a bottle line in food and beverage packaging
  • End-of-stroke detection on pneumatic cylinders in pick-and-place machines
  • Counting parts in a small parts handling cell with 300mm stand-off distance

Buying Checklist

  • Nickel-plated brass housing survives coolant, solvent, and impact that destroys plastic sensors
  • M18 threaded body with knurled nuts — simple panel mounting without brackets
  • PNP output matches modern Omron PLCs with sinking inputs
  • IP67 rating handles washdown and outdoor installations
  • Light-ON/Dark-ON mode set by simple wire connection, no programming or teach button

Technical Specifications

Model E3FB-DP22
Series E3FB
Type Diffuse Photoelectric Sensor
Sensing Range Up to 100mm
Output Type PNP
Supply Voltage DC12-24V
Response Time 1ms
Light Source Red LED
Operating Temperature -25 to +55°C

FAQ for E3FB-DP22

What's the difference between E3FA and E3FB?
E3FA is plastic (ABS) housing; E3FB is nickel-plated brass housing. Same optics, same electronics, same M18 thread. The E3FB is the right pick for harsh environments (coolant splash, solvent exposure, food-grade washdown); E3FA is the value pick for clean panels and indoor OEM machinery. Price difference is small (~$10-15 per unit).
What's the difference between E3FB-DP22 and E3FB-DP12?
E3FB-DP22 is 300mm sensing distance with M12 connector; E3FB-DP12 is 100mm sensing distance with M12 connector. Choose the 100mm version when the target is small (screw head, small component) and you need precise detection close-up. Choose the 300mm version for general-purpose part detection at typical machine distances.
How do I set Light-ON vs Dark-ON on the E3FB-DP22?
Pin 2 of the M12 connector controls the mode. Connect pin 2 (blue wire on standard XS2F cable) to 24V for Light-ON (output active when target is present, beam unbroken). Connect pin 2 to 0V for Dark-ON (output active when target is absent, beam broken). For most applications, Light-ON is the intuitive choice — output ON when you can see the part.
Can I use E3FB-DP22 with a PNP-input PLC?
Yes — the E3FB-DP22 has PNP output, which sources current on the output line. It connects directly to any PLC input that accepts PNP/sourcing signals. Most modern PLCs (Omron CP1, CJ2, NX, NJ) accept PNP by default. For older PLCs that only accept NPN, use the E3FB-DN22 (NPN output, same 300mm range).

Similar Products

Explore related Omron models often viewed alongside this product.
