Omron E3JK-TR11-C — 40 m Through-Beam, Relay, AC/DC

SKU: E3JK-TR11-C

USD 21.00

E3JK-series M18 through-beam photoelectric pair, 40 m red LED range, SPDT relay output, AC/DC 24-240 V supply, E39-L40 bracket included.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron E3JK-TR11-C is the 40 m red-LED through-beam pair in the E3JK compact family. It is two separate heads -- an emitter and a receiver -- that mount on opposite sides of a conveyor, lane, or guard opening, and it closes a SPDT relay contact when the beam is intact (or when it is broken, depending on the rear switch position). The 40 m range covers the long spans where a diffuse-reflective or retro-reflective sensor would not reach: wide carton lanes, pallet-transfer points, large door interlock spans, and boundary detection on long production cells.

Why the relay output matters here

Pick the E3JK-TR11-C (relay output) instead of the E3JK-TP11-C / E3JK-TN11-C (transistor output) siblings when the load is a contactor coil, a small motor starter, an indicator lamp, or a PLC input that the same sensor must drive directly. The SPDT relay contact switches up to 250 VAC 3 A resistive or 30 VDC 3 A resistive without an interposing relay. Pick the TP11 / TN11 transistor siblings instead when the sensor feeds only a fast PLC high-speed input -- the relay's 20 ms response is too slow for a 1 kHz+ count input.

Free-voltage supply for any cabinet

The AC/DC 24-240 V free-voltage supply accepts the same wiring on a 24 VDC cabinet, a 120 VAC control panel, and a 240 VAC European-style cabinet. The trade-off is the AC/DC spike sensitivity -- route the sensor cable away from VFD output cables and from the inverter's braking-resistor leads, since the optical receiver is rated at 3,000 lx incandescent / 11,000 lx sunlight ambient tolerance and a heavy switching transient on the supply line can false-trigger the relay.

Before ordering

The E39-L40 right-angle bracket is already in the box (the -C suffix is the bundle). For the retro-reflective E3JK family, add the E39-R1 reflector or the E39-R2 long-range reflector. The TR11-C ships as a pair (E3JK-TR11-L emitter + E3JK-TR11-D receiver); the bare E3JK-TR11 without the -C ships as the pair only, no bracket.

Key Features

  • E3JK-series M18 cylindrical through-beam photoelectric sensor pair
  • 40 m sensing range with visible red 624 nm LED source (5 m short-range is the TR12-C)
  • SPDT relay output, 250 VAC 3 A / 30 VDC 3 A resistive, Light-ON / Dark-ON rear switch
  • AC/DC 24-240 V +/- 10% free-voltage supply at 2 W / 30 mA
  • 20 ms or less response time, single-turn sensitivity pot on the receiver
  • Orange operation + green stability LED on the receiver, anti-mutual-interference optics
  • Ambient light immunity 3,000 lx incandescent / 11,000 lx sunlight
  • Pre-wired 2 m oil-resistant PVC cable, ABS plastic IP64 M18 housing
  • E39-L40 right-angle mounting bracket INCLUDED (the -C bundle suffix)
  • 50 million mechanical / 100,000 electrical operations, UL / cULus / CE / EN 60947-5-2
  • SKU: E3JK-TR11-C
  • Series: E3JK-TR11-C
  • Voltage: 24-240 V
  • I/O: 250 I/O

Best-Fit Applications

  • Long-span carton detection on wide conveyors and pallet lanes
  • Boundary detection on a 30+ m production cell perimeter
  • Door-interlock confirmation on a large guard span where a diffuse sensor would not reach
  • Stack-height control at the end of an oven or curing tunnel
  • Truck-dock bay detection with the emitter on one wall and the receiver on the opposite wall
  • Triggering a conveyor turn-off when a pallet breaks the beam at the end of the lane

Buying Checklist

  • Pick E3JK-TR11-C for the 40 m RED-LED through-beam range with relay output and the E39-L40 bracket in the box.
  • Pick E3JK-TP11-C / E3JK-TN11-C instead when the load is a fast PLC high-speed input or IO-Link master (the relay's 20 ms is too slow).
  • Pick E3JK-TR12-C for the 5 m short-range red-LED through-beam with the same relay output (saves money on short spans).
  • Pick E3JK-RR11-C for 7 m retro-reflective detection on a single-side mount with the E39-R1 reflector.
  • Pick E3JK-DR11-C for 2.5 m diffuse-reflective detection with no reflector needed at all.
  • Order the matching E39-R1 or E39-R2 reflector with the retro-reflective E3JK-RR11-C / E3JK-RR12-C SKUs.
  • Keep the sensor cable away from VFD output cables and braking-resistor leads to avoid AC-line transient false-triggers.

Technical Specifications

Sensing Method Through-beam pair (separate emitter + receiver)
Sensing Range 40 m (red 624 nm LED)
Standard Target 75 mm dia. or larger opaque object
Output Type SPDT relay, 250 VAC 3 A / 30 VDC 3 A resistive
Output Logic Light-ON / Dark-ON selectable on the rear switch
Supply Voltage AC/DC 24-240 V +/- 10%, 50/60 Hz, 2 W / 30 mA
Response Time 20 ms or less
Indicators Orange operation LED + green stability LED
Connection Pre-wired 2 m oil-resistant PVC cable
Housing ABS plastic, M18 cylindrical, IP64
Operating Temperature -25 to +55 C (storage -40 to +70 C)
Mounting E39-L40 right-angle bracket included (-C bundle)

FAQ for E3JK-TR11-C

What is the actual sensing range of the E3JK-TR11-C?
40 m on a red 624 nm LED. The 15 m figure sometimes seen on older datasheets is not correct for this SKU -- the 5 m short-range red-LED model is the E3JK-TR12-C, and the 40 m IR model is the E3JK-TR13. Pick the TR11-C for the long span, the TR12-C for the short span.
What is the difference between E3JK-TR11 and E3JK-TR11-C?
The C suffix is the bundle code: the E3JK-TR11-C ships with one E39-L40 right-angle mounting bracket in the box. The bare E3JK-TR11 ships as the sensor pair only. Both have the same 40 m red-LED, SPDT relay, AC/DC 24-240 V specifications -- the bracket is the only difference. Order the -C if you do not already have the E39-L40 in stock; order the bare SKU if your cabinet already has the bracket on the shelf.
Can the E3JK-TR11-C feed a PLC high-speed counter?
Not directly -- the SPDT relay has a 20 ms response time, which caps the count speed at about 25 counts per second. For high-speed count inputs pick the E3JK-TP11-C (PNP) or E3JK-TN11-C (NPN) transistor-output siblings, which respond in 1 ms or less. The relay output is for switching contactor coils, motor starters, indicator lamps, and PLC discrete inputs that do not need high speed.
Does the E3JK-TR11-C work on a 24 VDC cabinet?
Yes. The AC/DC 24-240 V free-voltage supply accepts the same 24 VDC, 120 VAC, and 240 VAC inputs on the same two terminals. The only cabinet concern is the AC-line transient -- route the sensor cable away from VFD output cables and from the inverter's braking-resistor leads, since the optical receiver's 3,000 lx incandescent / 11,000 lx sunlight ambient tolerance does not protect against conducted EMI on the supply line.
