Omron E3S-DBN21 — Industrial Sensor
SKU: E3S-DBN21USD 93.00
Compact retro-reflective photoelectric sensor with mirror-surface rejection (MSR) function and P-opaquing algorithm for transparent object detection (PET bottles, glass, clear film). 0–3.5 m sensing with E39-R8 reflector, NPN output via M12 connector, 1 ms response, IP67/IP69K Ecolab-certified for washdown.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The E3S-DBN21 is a member of the E3S-DB 'Transparent Object Detection' photoelectric sensor family — a compact retro-reflective sensor with MSR (mirror-surface rejection) function and Omron's proprietary P-opaquing algorithm, engineered specifically to detect PET bottles, glass bottles, clear plastic trays, and transparent films on conveyors without false triggering on shiny non-target objects (e.g., aluminum cans, glossy packaging).
Decoding the E3S-DBN21 model number
E3S = compact square photoelectric sensor family (alternative to E3Z cylinder family); D = 'detect' family / transparent-object + MSR + Smart Teaching; B = generation II of the DB series (replaces the older E3S-DB[][]1 / E3S-DB[][]2 nomenclature); N = NPN output (vs P = PNP); 2 = standard transparent-object detection variant (vs 1 = wide-angle long-range, 3 = narrow-beam 0.5 m range); 1 = M12 4-pin connector (vs '0' = pre-wired 2 m or 'M' = pre-wired 0.3 m SmartClick). The '21' suffix thus says: standard variant with M12 connector. Siblings: E3S-DBN11 2M (pre-wired 2 m), E3S-DBN31 0.3M (SmartClick prewired), E3S-DBP21 (PNP), E3S-DBN22 (narrow-beam 0.5 m).
Why retro-reflective with MSR for transparent targets
Standard diffuse-reflective sensors rely on light scattering off the target — but transparent targets like PET bottles scatter very little light back to the sensor, so a diffuse-reflective mode misses them entirely. Standard retro-reflective sensors fire the beam at a corner-cube reflector (which folds the beam back to the sensor); the sensor detects the beam-block by absence of return light. Transparent targets partially block the return light (some still comes back via refraction), causing a standard retro to either partially trigger or chatter.
Application context — PET bottle detection
The E3S-DBN21's primary application is on PET bottle filling / capping lines in the beverage industry. The sensor detects the bottle body between rinser and filler (E3S-DBN21 + E39-R8 reflector mounted on either side of the conveyor at 200-300 mm range) to count bottles and confirm the bottle is in position for filling. The MSR function rejects glare from the bottle's smooth PET wall, which would otherwise false-trigger the sensor. The IP69K + Ecolab certification matters here: the sensor is mounted in close proximity to caustic washdown nozzles (typically 100-200 mm away), which spray hot (60-80 °C) caustic at the bottle between rinses.
Key Features
- E3S-DB Transparent-Object Detection Photoelectric Sensor family
- Retro-reflective with mirror-surface rejection function
- Omron P-opaquing algorithm for PET bottles, glass, clear film detection
- Sensing distance 0 to 3.5 m with E39-R8 reflector
- Light source: visible Red LED 624 nm
- Spot diameter: 6 mm at 250 mm sensing distance
- Power supply voltage 10 to 30 VDC
- Output: NPN open collector, NO operation
- SKU: E3S-DBN21
- Series: E3S-DB Transparent Object Detection Photoelectric Sensor
- Voltage: 10 TO 30 VDC
- I/O: 100 I/O
Best-Fit Applications
- PET bottle counting on a beverage filling line — E3S-DBN21 + E39-R8 reflector mounted at opposite sides of a conveyor.
- Glass bottle presence detection on a wine bottling line — retro reflective with E39-R8 detects the bottle body even with.
- Clear plastic tray detection on a vacuum-former output conveyor — the E3S-DBN21 detects trays as they exit the sealer, even.
- Transparent film splice detection on a packaging-line film roll — the retro reflective detects the splice tape which would otherwise.
Buying Checklist
- Pick E3S-DBN21 for retro-reflective TRANSPARENT-object detection with NPN output and M12 connector
- Pick E3S-DBN11 2M for retro-reflective transparent-object detection with NPN output and pre-wired 2 m cable
- Pick E3S-DBP21 for the PNP output equivalent
- Pick E3S-DB[]22T with narrow-beam 0.5 m range when detecting small targets where the 6 mm standard spot is too wide
- Pick E3Z-D82 for diffuse-reflective at 1 m range — cheaper than E3S-DBN21 for non-transparent detection
- Pick E3FA-DP21 for diffuse-reflective opaque detection in M18 barrel form factor
Technical Specifications
| Model | E3S-DBN21 |
|---|---|
| Series | E3S-DB Transparent Object Detection Photoelectric Sensor |
| Type | Retro-reflective with MSR function + P-opaquing algorithm |
| Sensing Method | Retro-reflective (RETROREFLECTIVE, NOT diffuse-reflective — this is a correction vs old DB) |
| Sensing Distance | 0 to 3.5 m with E39-R8 reflector (sold separately) |
| Standard Reflector | E39-R8 (40 × 60 mm, included in some kits, sold separately) |
| Narrow Beam Range (with E39-R21) | 0 to 0.5 m (small spot 2.5 mm dia. at 200 mm) |
| Spot Diameter | 6 mm dia. at 250 mm sensing distance (with E39-R8) |
| Power Supply Voltage | 10 to 30 VDC |
| Current Consumption | 30 mA max (typical 25 mA at 24 VDC) |
| Control Output | NPN open collector, 100 mA max at 30 VDC, residual voltage 1 V max |
| Output Configuration | Light-ON / Dark-ON switchable (SLD selector switch on sensor) |
| Material (Connector) | Brass, nickel-plated |
| Operating Temperature | -25 to +55 °C |
| Storage Temperature | -40 to +70 °C |
Resources & Downloads
FAQ for E3S-DBN21
What is the difference between E3S-DBN21 and E3S-DBN11 2M?
Both are E3S-DB-series retro-reflective sensors with MSR function and transparent-target detection capability, both with NPN output. The differences are in connection method: E3S-DBN21 (this SKU) uses an M12 4-pin metal connector on the sensor body for quick-disconnect installation with cordset XS3F-M421-402-A. E3S-DBN11 2M has a 2 m pre-wired PVC cable instead.
Why does the E3S-DBN21 detect PET bottles when other sensors cannot?
PET bottles (clear plastic, ~0.5 mm wall thickness) are difficult targets for standard photoelectric sensors because they don't reflect enough light back to diffuse-reflective sensors and they don't block enough light from standard retro-reflective sensors.
What is the Smart Teaching routine for the E3S-DBN21?
Smart Teaching is a 3-step procedure: (1) With the sensor and reflector installed and aligned, press and hold the teach button on the sensor body for 3 seconds with no target in the beam — the LED blinks slowly, indicating 'baseline learning mode' is recording the empty-beam return level. (2) Release the button, then pass 3 sample targets (typical PET bottles) through the beam in sequence — the LED blinks once per detection, confirming each signal.
Is the E3S-DBN21 IP69K-rated for high-pressure washdown?
Yes — the E3S-DBN21 carries both IP67 (IEC 60529, submersion protection) and IP69K (DIN 40050-9, high-pressure high-temperature water-jet protection) ratings. IP69K specifically tests protection against 80 °C water sprayed at 80-100 bar pressure from 100-150 mm distance — equivalent to the caustic washdown nozzles in beverage / dairy / pharmaceutical plants. In addition, the body carries Ecolab detergent-resistance certification (tested against the standard Ecolab P3-topax 66 + P3-topactive OK ranges used in food/beverage CIP).
