Omron E3T-ST12 2M — 1 m Through-Beam Sensor, Side View, NPN
SKU: E3T-ST12 2MUSD 25.00
Omron E3T-ST12 2M ultra-compact side-view through-beam sensor, 1 m range, NPN Dark-ON, red LED, 2 m cable, IP67 PBT body.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron E3T-ST12 2M is an ultra-compact side-view through-beam photoelectric sensor with a 1 m sensing range, manufactured by Omron Corporation. Hengyixin Automation ships this sensor from our Xiamen warehouse with a 30-day DOA return window and a datasheet PDF included in the box.
The set is one emitter head and one receiver head, each 18.5 x 7 x 9.5 mm in a black PBT case. The visible red 650 nm LED makes alignment easy. Output is NPN open collector, Dark-ON; it switches ON when the beam is broken. Power is 12 to 24 VDC; the load can pull up to 50 mA. Response time is 1 ms max. The cable is 2 m pre-wired.
Use the E39-L117 bracket for rear mounting or the E39-L118 bracket for side mounting. Minimum sensing object is a 2 mm opaque part. For the Light-ON twin, pick the E3T-ST11. For a diffuse-reflective 30 mm sensor in the same body, pick the E3T-FD11.
Key Features
- Ultra-compact side-view through-beam photoelectric sensor, 1 m sensing range
- NPN open collector, Dark-ON, 12 to 24 VDC supply, 1 ms response
- Visible red 650 nm LED for easy alignment, 2 mm opaque min object
- PBT body, IP67, 2 m pre-wired cable, M2 screws with E39-L117 / L118 brackets
- SKU: E3T-ST12 2M
- Series: Omron E3T miniature photoelectric sensor
- Voltage: 12 TO 24 VDC
Best-Fit Applications
- Detecting ICs dropping off a tape feeder on a pick-and-place head where the 7 mm width fits between the guide rails
- Sensing a thin packaging web between two rollers on a vertical form-fill-seal machine, with the side-view body flat against the frame
- Position check on a syringe dial table where the visible red beam makes it easy to confirm the head is aimed at the target
Buying Checklist
- Pick the E3T-ST12 2M for an ultra-compact side-view through-beam sensor with NPN Dark-ON output and 2 m cable.
- Pick the E3T-ST11 2M instead when the PLC input expects the Light-ON logic of the same sensor.
- Pick the E3T-FD11 instead when you need diffuse-reflective 30 mm sensing in the same miniature body.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron E3T miniature photoelectric sensor |
| Model / SKU | E3T-ST12 2M |
| Sensing Method | Through-beam, side view |
| Sensing Distance | 1000 mm (1 m) |
| Min Sensing Object | 2 mm opaque |
| Light Source | Visible red LED, 650 nm |
| Output Type | NPN open collector, Dark-ON |
| Supply Voltage | 12 to 24 VDC ±10%, ripple 10% p-p max |
| Load Current | 50 mA max |
| Response Time | 1 ms max operate or reset |
| Housing / IP / Cable | PBT; IP67; 2 m pre-wired |
FAQ for E3T-ST12 2M
What does the Omron E3T-ST12 2M detect?
Anything opaque that breaks the 1 m beam between the emitter and receiver heads. The minimum sensing object is 2 mm. Output is Dark-ON, so it switches ON when the beam is interrupted.
E3T-ST12 2M vs E3T-ST11 2M — what is the difference?
Output logic. Both are 1 m side-view through-beam sensors in the E3T series. The ST12 is Dark-ON (output ON when the beam is broken); the ST11 is Light-ON (output ON when the beam is received).
What brackets fit the E3T-ST12 2M?
The E39-L117 rear-mount bracket and the E39-L118 side-mount bracket. Both are sold separately and hold the head with M2 screws.
