Omron E5AC-CX3ASM-804 — front view of the 96×96 mm black housing showing the large white 25 mm PV display, the secondary SV/status row, and the model label

Omron E5AC-CX3ASM-804 — 96×96 PID Temp Controller, RS-485

SKU: E5AC-CX3ASM-804

USD 68.00

E5AC-series 96×96 mm PID temperature controller, universal input, linear 4-20 mA output, RS-485, 3-point aux output, AC100-240 V.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron E5AC-CX3ASM-804 is a digital PID temperature controller in the 96×96 mm E5AC family, sized for panel cutouts where a larger, easy-to-read display matters. The E5AC-800 generation uses a 25 mm-tall white PV display so process values stay readable from across the cabinet. It accepts a universal input — thermocouple, Pt100, ES1B infrared, or analog (4-20 mA, 0-20 mA, 1-5 V, 0-5 V, 0-10 V). Control output 1 is linear 4-20 mA for a thyristor or analog-driven actuator. Three relay auxiliary outputs handle alarms, two event inputs accept external switches (RUN / STOP, manual / auto, remote SP), and RS-485 communication is fitted. It is the standard pick for panel temperature control on plastic or heat-treat lines where analog control and a PLC link are both needed.

Where it fits in the E5_C family

The E5_C family splits by size. The E5CC is the 48×48 mm version, the E5EC is the 48×96 mm version, and the E5AC is the 96×96 mm version. Within the E5AC-800 series, E5AC-CX3ASM-804 is the linear-output 3-point RS-485 AC100-240 V variant with 2 event inputs. E5AC-CX3ASM-808 adds heater-burnout detection. E5AC-CX3ASM-810 adds 4 event inputs and 4 auxiliary outputs. E5AC-CX3DSM-804 is the same controller on AC/DC 24 V supply. Pick the E5AC-CX3ASM-804 when linear current output, RS-485 to a PLC, and an AC-supply panel are the goal.

Why linear output rather than relay

Relay outputs switch ON/OFF, which causes process oscillation on fast heaters. A linear 4-20 mA output drives a thyristor (e.g., the G3PX series) in proportion to PID demand, so a 200 W and a 20 kW heater both run with the same control stability. Three relay auxiliary outputs handle alarms; use the event inputs for a panel-mounted RUN/STOP key and an auto/manual selector.

Before ordering

Confirm the input matches the field sensor — TC polarity, 2-wire / 3-wire RTD, or analog loop. Wire event inputs with dry contacts or PNP drivers per the manual. Set RS-485 to 9600 or 19200 bps half-duplex with a unique unit number before connecting to a CP1L / CP2E / NJ PLC. Use CX-Thermo (free tool) via the front port for setup and auto-tuning.

Key Features

  • E5AC family 96×96 mm PID temperature controller
  • Universal input: TC (K/J/T/E/L/U/N/R/S/B/W), Pt100, ES1B, 4-20 mA, 0-10 V
  • Linear 4-20 mA control output for thyristor or analog actuator
  • Three relay auxiliary outputs, two event inputs
  • RS-485 serial communication, CompoWay/F protocol
  • 50 ms sampling period for fast-loop response
  • 25 mm-tall white LCD PV display
  • AC100-240 V supply, 9.0 VA
  • SKU: E5AC-CX3ASM-804
  • Series: E5AC 96×96 mm PID temperature controller
  • Voltage: 240 V
  • I/O: 100 I/O

Best-Fit Applications

  • Extruder barrel and die temperature control on plastics lines
  • Furnace and oven zone control on a heat-treat line
  • Tank and reactor temperature control in process plants
  • Thyristor-driven electric heater control via 4-20 mA demand
  • PLC linkup for status and parameter change via RS-485

Buying Checklist

  • Choose E5AC-CX3ASM-804 for linear 4-20 mA output and RS-485 on AC100-240 V.
  • Choose E5AC-CX3ASM-808 when heater-burnout detection is required.
  • Choose E5AC-CX3ASM-810 for 4 event inputs and 4 auxiliary outputs.
  • Choose E5AC-CX3DSM-804 for the same controller on AC/DC 24 V supply.
  • Choose E5CC-QX2ASM-800 for a 48×48 mm panel when the larger cutout is not needed.
  • Confirm the sensor type (TC, RTD, analog) matches the field wiring.

Technical Specifications

Series E5AC 96×96 mm PID temperature controller
Size 96 × 96 × 60 mm (1/4 DIN), panel cutout 92 × 92 mm
Supply Voltage AC100-240 V, 50/60 Hz
Power Consumption 9.0 VA max. at AC100-240 V
Sensor Input Thermocouple (K/J/T/E/L/U/N/R/S/B/W), Pt100/JPt100, ES1B, 4-20 mA / 0-20 mA / 1-5 V / 0-5 V / 0-10 V
Sampling Period 50 ms
Control Output Linear current 4-20 mA / 0-20 mA, load ≤500 Ω
Auxiliary Outputs 3 × SPST-NO, AC250 V 3 A resistive
Event Inputs 2 external contact / transistor inputs
Communication RS-485, CompoWay/F, terminal block
Control Modes ON/OFF or 2-DOF PID with auto-tuning, standard or heat/cool
Operating Temperature -10 to +55 °C

FAQ for E5AC-CX3ASM-804

What is the difference between E5AC-CX3ASM-804 and E5AC-CX3ASM-800?
Both are 96×96 mm E5AC controllers with linear current control output and AC100-240 V supply. E5AC-CX3ASM-800 has no communication and no event inputs. E5AC-CX3ASM-804 adds RS-485 communication and 2 event inputs. Pick -804 when a PLC link or remote auto/manual switch is part of the job; pick -800 when the controller stands alone.
What sensor inputs does E5AC-CX3ASM-804 accept?
It accepts any thermocouple type in the E5_C list (K, J, T, E, L, U, N, R, S, B, W), Pt100 or JPt100 RTD in 2- or 3-wire, the ES1B non-contact infrared sensor, or a 4-20 mA / 0-20 mA / 1-5 V / 0-5 V / 0-10 V analog signal. Switch between them in the parameter menu, so one controller can run different zones on the same machine.
How does the linear 4-20 mA output wire up?
The linear output terminal drives a thyristor (G3PX series, E5CK-T / G3PW, etc.) with a 4-20 mA loop, with the load resistance held below 500 Ω. It is the right pick for proportional control of electric heaters, where ON/OFF relays cause process cycling. Use the auxiliary relay outputs for alarm signalling, not for proportional load switching.
