Omron E6B2-CWZ6C 300P-R — front view of the 40 mm rotary encoder showing the metal housing, the 6 mm solid shaft, the E6B2 label and the cable exit at the side

Omron E6B2-CWZ6C 300P-R — 40 mm Encoder, 300 PPR

SKU: E6B2-CWZ6C 300P-R

USD 32.00

Omron E6B2-CWZ6C 300P-R 40 mm incremental rotary encoder, 300 PPR, A/B/Z phases, NPN, 5-24 VDC. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron E6B2-CWZ6C 300P-R is a 40 mm incremental rotary encoder from the E6B2-C family, manufactured by Omron Corporation. Hengyixin Automation ships this sensor from our Xiamen warehouse with a 30-day DOA return window and a datasheet PDF included in the box.

The encoder ships in a 40 mm-diameter metal housing with a 6 mm solid shaft. It delivers 300 pulses per revolution on A, B, and Z phase outputs through an NPN open-collector driver rated 35 mA sink / 30 VDC applied max / 0.4 V residual max. A and B phases lead by 90 +/- 45 degrees.

Supply is 5 to 24 VDC at 70 mA max. Maximum response frequency is 100 kHz; maximum rotation 6000 RPM. Starting torque 0.98 mN.m max; shaft loads 30 N radial / 20 N thrust. Operating range -10 to +70 C. The 2 m pre-wired PVC cable carries the signal leads. IP50 IEC / IP64 JEM. The 2000 PPR variant in the same body is E6B2-CWZ6C 2000P-R.

Key Features

  • E6B2-C-series 40 mm-diameter incremental rotary encoder with 6 mm solid shaft and 300 P/R resolution
  • NPN open-collector output on A, B, and Z phases, 90 +/- 45 deg quadrature, 35 mA sink / 30 VDC max applied
  • 5 to 24 VDC supply at 70 mA max, 100 kHz max response, 6000 RPM max rotation, 0.98 mN.m starting torque
  • 30 N radial / 20 N thrust shaft load, IP50 IEC / IP64 JEM, pre-wired 2 m PVC cable, -10 to +70 C operating
  • SKU: E6B2-CWZ6C 300P-R
  • Series: Omron E6B2-C 40 mm incremental rotary encoder
  • Voltage: 5 TO 24 VDC

Best-Fit Applications

  • Conveyor speed feedback on a packaging line where 300 PPR with quadrature gives 1200 counts/rev for accurate length measurement
  • Motor shaft tachometer on a 1450 RPM induction drive where the 6000 RPM headroom and 100 kHz response cover the full ramp profile
  • Cut-to-length register on a textile web where the Z pulse from the encoder re-zeros the cut at every fabric splice

Buying Checklist

  • Pick the E6B2-CWZ6C 300P-R for a 40 mm NPN incremental encoder with 300 PPR on a 5-24 VDC supply.
  • Pick the E6B2-CWZ6C 2000P-R instead when the same body needs 2000 PPR for higher position resolution.
  • Pick the E6B2-CWZ1X instead when the line-driver output (RS-422A equivalent) is required for long cables.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron E6B2-C 40 mm incremental rotary encoder
Model / SKU E6B2-CWZ6C 300P-R
Resolution 300 pulses per revolution (P/R)
Output Phases / Form A, B, Z phases, NPN open collector (sink 35 mA max, applied 30 VDC max)
Phase Difference A and B lead 90 +/- 45 degrees (1/4 T +/- 1/8 T)
Supply Voltage 5 to 24 VDC, ripple 5% max, 70 mA max (9 A inrush at power-on for 0.3 ms)
Response Frequency 100 kHz max
Max Rotational Speed 6000 RPM
Starting Torque 0.98 mN.m max
Shaft Load 30 N radial, 20 N thrust
Protection / Connection IP50 IEC, IP64 JEM, pre-wired 2 m PVC cable, 5 cores, 0.93 g

FAQ for E6B2-CWZ6C 300P-R

What is the resolution of E6B2-CWZ6C 300P-R?
300 pulses per revolution (PPR). With quadrature decoding on A and B, a counter module reads 1200 counts per revolution. The 2 m cable length is the standard pre-wired variant.
Does E6B2-CWZ6C 300P-R need pull-up resistors?
Yes. The NPN open-collector output pulls the line low; an external pull-up to the PLC input voltage is required. Many Omron CP1L and CJ2 counter inputs have internal pull-ups so wiring is just the encoder leads.
Can E6B2-CWZ6C 300P-R run on a 5 V supply?
Yes. The supply range is 5 to 24 VDC with a -5% to +15% tolerance. At 5 V the residual voltage rises so confirm the counter-input threshold on the receiving PLC.
What is the difference between E6B2-CWZ6C and E6B2-CWZ1X?
CWZ6C is NPN open-collector, 5-24 VDC. CWZ1X is RS-422A line-driver, 5 VDC, for long cables and high noise. Both share the same 40 mm body and 6 mm shaft.
