Omron E6CP-AG5C 256P-R — 50 mm Absolute Encoder

SKU: E6CP-AG5C 256P-R

USD 63.00

Omron E6CP-AG5C 256P-R absolute rotary encoder, 50 mm, 256 divisions, 12-24 VDC. In stock, China shipping.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron E6CP-AG5C 256P-R is a general-purpose absolute rotary encoder from the E6CP-A family, manufactured by Omron Corporation. Hengyixin Automation ships this sensor from our Xiamen warehouse with a 30-day DOA return window and a datasheet PDF included in the box.

The encoder delivers 256 divisions per revolution (8-bit) in gray code on an open-collector NPN output. Supply is 12-24 VDC (12 VDC -10% to 24 VDC +15%, ripple p-p 5% max) at 70 mA max. Maximum response frequency is 5 kHz and accuracy is +/-1 degree. Rotation is CW from the shaft, with negative logic (H = 0, L = 1).

The 50 mm plastic body carries a 6 mm solid shaft and a 2 m pre-wired cable. Shaft load is radial 10 N / axial 5 N and max rotation 5,000 r/min. For an incremental sibling in the same 50 mm body, use the E6C2-CWZ5B 500PR 2M. For 5-12 VDC supply use the E6CP-AG3C sibling.

Key Features

  • E6CP-series absolute rotary encoder, 50 mm body, 6 mm solid shaft, 2 m pre-wired cable
  • 256 divisions per revolution, 8-bit gray code output, open-collector NPN, 12-24 VDC supply
  • 5 kHz max response frequency, +/-1 degree accuracy, negative logic, CW rotation = code up
  • Starting torque 1 mN-m max, IP50, 5,000 r/min max speed, plastic body for low weight
  • SKU: E6CP-AG5C 256P-R
  • Series: Omron E6CP-A series general-purpose absolute rotary encoder
  • Voltage: 12 VDC

Best-Fit Applications

  • Turntable position feedback on a labeling machine where the gray code absolute position lets the host PLC resume indexing after a power cycle without re-homing
  • Damper / valve position indicator on an HVAC fan coil where 256 divisions over 360 degrees is enough resolution for the actuator's set-point profile
  • Spare replacement on a long-running packaging line where the old E6CP-AG5C 256P/R has been superseded and a like-for-like encoder is needed in the same mounting

Buying Checklist

  • Pick the E6CP-AG5C 256P-R for an absolute gray-code encoder at 12-24 VDC supply with 256 divisions on a 50 mm body.
  • Pick the E6CP-AG3C instead when the host controller or sensor supply is 5-12 VDC only.
  • Pick the E6C2-CWZ6C instead when an incremental A/B/Z pulse train is enough and the panel can re-home on power-up.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron E6CP-A series general-purpose absolute rotary encoder
Model / SKU E6CP-AG5C 256P-R
Body Diameter 50 mm
Resolution 256 divisions per revolution (8-bit)
Output Code Gray code, open-collector NPN, 28 VDC max load, 16 mA max sink
Power Supply 12 VDC -10% to 24 VDC +15%, ripple p-p 5% max, 70 mA max current consumption
Accuracy +/-1 degree
Response Frequency 5 kHz max
Logic / Direction Negative logic (H = 0, L = 1), CW rotation viewed from shaft increases code
Rise / Fall Time 1 us max (at 16 V, 1 kOhm, 2 m cable)
Mechanical / Environment Starting torque 1 mN-m max, moment of inertia 1 x 10^-7 kg-m^2, shaft load radial 10 N / axial 5 N, 5,000 r/min max speed, IP50, -10 to +55 C operating, 2 m pre-wired PVC cable

FAQ for E6CP-AG5C 256P-R

What is the Omron E6CP-AG5C 256P-R used for?
It is a 50 mm absolute rotary encoder for turntable, valve, and door position feedback. The 8-bit gray code output lets the host PLC know the shaft position the moment power returns, with no re-homing.
E6CP-AG5C vs E6CP-AG3C - what is the difference?
The E6CP-AG5C accepts 12-24 VDC supply. The E6CP-AG3C accepts 5-12 VDC supply. Resolution (256 divisions), output code (gray code), and mechanical body are identical between the two.
Does the E6CP-AG5C 256P-R output incremental pulses?
No. The E6CP-AG5C outputs absolute gray code, 8 bits of position per revolution. For incremental A/B/Z pulses pick the E6C2-CWZ6C sibling in the same 50 mm body.
How is the E6CP-AG5C 256P-R wired?
Six wires in the 2 m PVC pigtail cable: red +V supply, black 0 V common, brown output bit 20 (MSB), and three more output wires for the remaining bits, plus an orange enable / shield line. See the datasheet for the exact color map and the E69-C06B coupling accessory.
What is the starting torque of the E6CP-AG5C 256P-R?
1 mN-m max, with moment of inertia 1 x 10^-7 kg-m^2. Shaft load is radial 10 N / axial 5 N. These are the same mechanical limits on the E6CP-AG5C-C sibling and the older E6CP-AG3C.
