Omron G2R-2-SND — front view of the plug-in relay showing the Omron model label, the 8 round pins on the bottom, the transparent case, the red LED indicator on the top and the mechanical operation flag

Omron G2R-2-SND — DPDT Relay, 24 VDC, 5 A, LED

SKU: G2R-2-SND

USD 1.80

DPDT 8-pin plug-in relay, 24 VDC coil, 5 A, LED + diode + mechanical flag. In stock.

1-Year Warranty Full manufacturer warranty
Global Shipping Worldwide delivery available
Genuine Omron 100% authentic product
Ready to Ship Usually ships within 24h
In Stock

This item is available for immediate shipment from our warehouse.

Request Quote

Contact for pricing, bulk discounts, and shipping

Product Overview

The Omron G2R-2-SND is a double-pole double-throw (DPDT, 2 Form C) plug-in relay from the G2R industrial family It is manufactured by Omron Corporation. Hengyixin Automation stocks this relay in Xiamen and ships within 3-5 business days to most Asian, European, and North American ports.

The coil runs on 24 VDC at 21.8 mA through 1.1 kohm (530 mW). The DPDT contacts switch up to 5 A at 250 VAC or 30 VDC resistive.

Mechanical life is 10 million operations; electrical life is 100,000 at full rated load. Key specs: Contact Configuration DPDT (2 Form C); 2 NO + 2 NC; Coil Voltage 24 VDC; Coil Resistance / Power 1.1 kohm; 21.8 mA; 530 mW; Contact Rating 5 A at 250 VAC or 30 VDC resistive; Max Switching 1250 VA AC / 150 W DC; Operate / Release Time 15 ms / 20 ms max; Mechanical Life 10 million operations min; Electrical Life 100,000 operations at rated load.

Key Features

  • G2R-series DPDT (2 Form C) 8-pin plug-in industrial relay, 24 VDC coil
  • 5 A contact rating at 250 VAC / 30 VDC resistive, AgSnIn contacts
  • LED coil indicator + mechanical operation flag + coil-suppression diode
  • 15 ms operate, 20 ms release, 10 million mechanical operations
  • SKU: G2R-2-SND
  • Series: Omron G2R-series slim 8-pin plug-in industrial relay
  • Voltage: 24 VDC

Best-Fit Applications

  • Interface between a CP1L transistor output and a 3-phase motor contactor where the diode absorbs the contactor back-EMF
  • Alarm and indicator relay bank where the LED confirms the PLC output is hot from the control-room HMI
  • Spare replacement on a packaging line where the LED + mechanical flag lets the operator verify the coil state at a glance

Buying Checklist

  • Pick the G2R-2-SND for a DPDT 24 VDC relay with LED, mechanical flag and coil diode on a 5 A 8-pin body.
  • Pick the G2R-2-SNI DC24(S) instead when the cabinet does not need the coil diode.
  • Pick the P2RFZ-08-E square socket instead of the P2RF-08 when the panel needs a finger-safe M3 screw terminal.

Technical Specifications

Manufacturer Omron Corporation (Japan)
Series Omron G2R-series slim 8-pin plug-in industrial relay
Model / SKU G2R-2-SND
Contact Configuration DPDT (2 Form C); 2 NO + 2 NC
Coil Voltage 24 VDC
Coil Resistance / Power 1.1 kohm; 21.8 mA; 530 mW
Contact Rating 5 A at 250 VAC or 30 VDC resistive
Max Switching 1250 VA AC / 150 W DC
Operate / Release Time 15 ms / 20 ms max
Mechanical Life 10 million operations min
Electrical Life 100,000 operations at rated load
Dimensions / Weight 29 (H) x 13 (W) x 35.5 (D) mm; 20 g; -40 to +70 degrees C

FAQ for G2R-2-SND

What does the SND suffix mean on the G2R-2?
S = slim housing, N = LED coil indicator + mechanical operation flag, D = coil-suppression diode (back-EMF clamp). Together the relay shows the coil state, can be probed by eye, and will not inject a flyback pulse back into the PLC transistor output.
Which socket fits the G2R-2-SND?
The P2RF-08-E round octal socket, the P2RFZ-08-E square finger-safe socket, or the PCB-mount P2R-08P. The P2RFZ-08-E is the recommended modern choice for finger-safe M3 screw terminals.
Can the G2R-2-SND switch 24 VDC at 5 A?
Yes on resistive loads (heaters, indicator lamps). On inductive DC loads (solenoids, contactor coils) the rating drops to 2 A. The built-in coil diode protects the driving transistor but does not protect the load-side contact; add a flyback diode across the load for inductive DC.
