Omron G7TC-ID16 DC24V — 16-pt Input Relay Terminal
SKU: G7TC-ID16 DC24VUSD 150.00
Omron G7TC-ID16 DC24V G7TC 16-point input relay terminal, 24 VDC coil, NPN common, DIN-rail. In stock.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron G7TC-ID16 DC24V is a 16-point input relay terminal for SYSMAC PLCs, manufactured by Omron Corporation. Hengyixin Automation stocks this relay in Xiamen and ships within 3-5 business days in original Omron packaging with the lot code visible.
The unit mounts 16 SPST-NO (1a) G7T relays on a single P7TF-IS16 terminal socket. A single XW2Z-R cable links the terminal to a SYSMAC input card, replacing 16 individual panel-wire runs. Coil voltage is 24 VDC and the internal common is NPN (minus common). Each point has a green LED that lights when the relay is closed.
Contact rating is 1 A at 24 VDC on the input side. The terminal is 182 x 85 x 68 mm, DIN-rail mounted, and approved to UL 508 and CSA C22.2 No. 14. To back the terminal with a slim-line 24 VDC relay, pair it with the G2R-2-SND DC24(S) or the G2R-2-SND DC24V on a matching P2RFZ-08-E socket.
Key Features
- G7TC 16-point input relay terminal with a single SYSMAC connector cable
- 24 VDC coil, NPN (- common), 1a x 16 SPST-NO contacts via G7T-1122S relays
- Green LED per point, built-in diode surge suppressor, 1 A at 24 VDC contact rating
- 182 x 85 x 68 mm DIN-rail housing, UL 508 and CSA C22.2 No. 14 approved
- SKU: G7TC-ID16 DC24V
- Series: Omron G7TC-series I/O Relay Terminal
- Voltage: 24 VDC
- I/O: 16 points
Best-Fit Applications
- Input consolidation for a CJ2M-CPU13 where 16 field sensors land on one terminal and a single cable drops to the CJ1W-ID211 input card
- Spare I/O terminal for a SYSMAC CJ1 panel where the previous G7TC-ID16 failed and the wiring is NPN minus common
- Retrofit of an existing C200H panel where the field wiring is 24 VDC and the SYSMAC side uses a single connector cable
Buying Checklist
- Pick the G7TC-ID16 DC24V for a 16-point 24 VDC input relay terminal on a SYSMAC rack.
- Pick the G7TC-IA16 instead when the field inputs are 100/110 VAC or 200/220 VAC.
- Pick the G7TC-OC16 DC24V instead when the same form factor is needed for 16 outputs instead of inputs.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron G7TC-series I/O Relay Terminal |
| Model / SKU | G7TC-ID16 DC24V |
| I/O Classification | Input, 16 points |
| Internal Common | NPN (- common) |
| Coil Voltage | 24 VDC |
| Contact Configuration | 1a x 16 (SPST-NO via G7T-1122S relays) |
| Contact Rating | 1 A at 24 VDC (resistive) on the input side |
| Operating / Release Time | 15 ms max each |
| Indicators | Green LED per point; built-in diode surge suppressor |
| Mounting | DIN rail (35 mm); 182 x 85 x 68 mm |
| Approvals / Cable | UL 508, CSA C22.2 No. 14; XW2Z-R cable to SYSMAC, up to 5 m |
FAQ for G7TC-ID16 DC24V
What cable links the G7TC-ID16 to a PLC?
An XW2Z-R cable with a Fujitsu/Otax or MIL connector on the PLC side and a matching connector on the G7TC side. Standard lengths run from 0.5 m to 5 m; longer cables are available on request.
Can the relays be replaced individually?
Yes. Each of the 16 relays is a G7T-1122S SPST-NO relay that pulls straight out of the P7TF-IS16 socket. Swap a failed relay without unwiring the field terminal.
What is the maximum cable length to the field device?
Up to 50 m to the I/O device when using a 2 mm squared CVV cable. To the controller the cable should not exceed 5 m, which is the longest standard XW2Z-R length.
What replaces a failed G7TC-ID16 on the same wiring?
A second G7TC-ID16 with the same coil voltage clips straight onto the DIN rail and uses the same XW2Z-R cable. No rewiring of the SYSMAC side is needed if the cable and node address are unchanged.
