Omron G9SA-301 AC-DC24 — Safety Relay, 3NO/1NC, 24 V AC/DC
SKU: G9SA-301 AC-DC24USD 75.00
G9SA-series safety relay unit, 3 NO safety contacts + 1 NC aux, auto-reset, 24 V AC/DC supply, 45 mm DIN-rail housing, PLe/SIL 3.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron G9SA-301 AC/DC24 is a compact safety relay unit from the G9SA family — 3 NO safety contacts plus 1 NC auxiliary contact, 24 V AC/DC supply, automatic reset, and a 45 mm-wide DIN-rail housing. It monitors a dual-channel safety input from devices like E-stop buttons, guard-door switches, safety light curtains, or two-hand controls, and switches its safety outputs to a Category 4 / PL e / SIL 3 level when the safety circuit is intact.
The G9SA family is Omron's mid-size safety-relay line: narrower than the G9SA-TH301 two-hand module, and simpler than the G9SE programmable safety controllers. The 301 suffix means "3 safety contacts, no OFF-delay" — the most common configuration for E-stop and guard-door circuits that need a single stop category without time-delayed release.
Where the G9SA-301 fits on a safety circuit
Typical wiring pairs a dual-channel E-stop button or a D4NS / D4NL guard switch as the input device. When both channels close (button released, guard closed), the G9SA energises the 3 NO safety outputs to the contactors or drives downstream. Pressing the E-stop or opening the guard opens the safety loop, the G9SA drops the NO outputs within its 100 ms response window, and the downstream contactors drop the motor power. The 1 NC auxiliary contact is used for monitoring or for the reset-feedback loop.
Selecting this variant vs other G9SA units
In the same 45 mm body, the G9SA-321 adds two OFF-delay contacts for controlled-stop categories (1–15 s in 15 steps). The G9SA-501 has 5 NO safety contacts for circuits that need to drive more contactors. The G9SA-TH301 has the two-hand-control logic for press applications. For broader monitoring with diagnostics, the G9SE-201 or G9SP safety controllers offer configurable logic in a similarly compact body.
Before ordering
Wire the input as dual-channel (two NC contacts in series, cross-monitored) for any Cat 4 / PL e application — a single-channel wiring caps out at lower categories. Check that the panel supply is genuinely 24 V AC or 24 V DC; there are also 100–240 VAC supply variants of the G9SA family that look similar on the front label. The 3 NO contacts are rated 5 A at 250 VAC and 5 A at 30 VDC for resistive loads — derate to about 1.5 A for inductive AC-15 use. Always wire a fuse on the contactor side (10 A gG / gI).
Key Features
- G9SA family, compact 45 mm DIN-rail housing
- 3 NO safety outputs + 1 NC aux output (3PST-NO + SPST-NC)
- 24 V AC/DC supply (50/60 Hz)
- Auto-reset / manual-reset switchable on the front
- Cross-monitoring dual-channel safety input
- Up to Category 4 / PL e (ISO 13849-1), SIL 3 (IEC 61508) with proper wiring
- Compatible with E-stop, guard-door, safety-curtain, and two-hand devices
- Approvals: UL, CSA, TÜV (BG), CE
- SKU: G9SA-301 AC-DC24
- Series: G9SA compact safety relay (45 mm DIN-rail)
- Voltage: 24 V
Best-Fit Applications
- Single-stop E-stop and sliding-guard monitoring on a packaging, assembly, or transfer machine
- Dual-channel guard-door switch (D4NS, D4NL) interface for a mid-size machine cell
- Backup safety relay for a safety light curtain output (F3S, MS4800)
- Drives contactors or servo drive STO inputs in a Category 4 / PL e stop circuit
- Refit of an older G7SA / G9S-series safety relay on an existing machine
Buying Checklist
- Confirm the panel supply really is 24 V AC or 24 V DC — the G9SA-301 AC/DC24 is not interchangeable with the 100–240 VAC variants.
- Wire the input as dual-channel NC with cross-monitoring for any Cat 4 / PL e application; single-channel wiring caps out below the headline safety level.
- Use the front reset switch to choose auto or manual reset — manual is the safer default for E-stop circuits that must be deliberately reset.
- Derate the 5 A NO contact rating for inductive loads (AC-15): about 1.5 A at 250 VAC — pull from the load's contactor coil through the G9SA, not from a big motor directly.
- Add the front-mounted TÜV / UL marking sticker to the safety file — the G9SA is approved to EN 954-1 / ISO 13849-1 PL e and SIL 3 with the correct wiring.
Technical Specifications
| Model | G9SA-301 AC/DC24 |
|---|---|
| Series | G9SA compact safety relay (45 mm DIN-rail) |
| Contact Form | 3 NO safety contacts + 1 NC aux |
| Supply Voltage | 24 V AC/DC (50/60 Hz) |
| Reset Mode | Auto / Manual (front switch) |
| Response Time | ≤100 ms |
| Rated Load (NO) | 5 A at 250 VAC / 30 VDC resistive |
| Safety Category | Up to Cat 4 / PL e (ISO 13849-1), SIL 3 |
| Operating Temperature | -25 to +55 °C |
| Mounting | DIN rail (35 mm) or M4 screw |
| Dimensions | 45 × 90 × 76 mm (W × H × D) |
| Approvals | UL, CSA, TÜV (BG), CE |
Resources & Downloads
FAQ for G9SA-301 AC-DC24
What is the difference between G9SA-301, G9SA-321, and G9SA-501?
G9SA-301 has 3 NO safety contacts with no time delay. G9SA-321 replaces two of those with OFF-delay contacts (1–15 s in 15 steps) for controlled-stop circuits. G9SA-501 has 5 NO safety contacts for circuits that need to drop more contactors in one stop event. Pick the 301 for the common E-stop / guard-door wiring.
What safety level does the G9SA-301 reach?
Up to Category 4 / PL e under ISO 13849-1 and SIL 3 under IEC 61508, but only when wired with a dual-channel input from a monitored device such as an E-stop button or a D4NS / D4NL guard switch. A single-channel wiring tops out at a lower safety category — check the safety function in the machine's risk assessment.
Can I use the G9SA-301 with a safety light curtain?
Yes. Wire the light curtain's two OSSD outputs to the G9SA dual-channel input — most safety curtains with PNP OSSD outputs (Omron F3S, SICK, Keyence) are plug-compatible. The G9SA switches its 3 NO contacts when the curtain is clear; the curtain is detected as a "fault" if the OSSE/OSSD pair ever short to each other (cross-monitoring).
Does the G9SA-301 need a reset button?
It depends on the safety function. The front switch selects auto-reset (contacts close when the input recovers) or manual reset (an external NO button must pulse T31/T32 to close the outputs again). Manual reset is the standard for E-stop circuits to force a deliberate reset action before the machine restarts.
