Omron H5CC-AD — 48 mm Digital Timer / Counter, 12-48 VDC
SKU: H5CC-ADUSD 73.00
Omron H5CC-AD 48 x 48 mm digital timer / counter, screw terminals, 12-48 VDC / 24 VAC supply, SPDT, switchable NPN/PNP.
1-Year Warranty
Full manufacturer warranty
Global Shipping
Worldwide delivery available
Genuine Omron
100% authentic product
Ready to Ship
Usually ships within 24h
In Stock
This item is available for immediate shipment from our warehouse.
Contact for pricing, bulk discounts, and shipping
Product Overview
The Omron H5CC-AD is a 48 x 48 mm digital timer and counter from the H5CC family, manufactured by Omron Corporation. Hengyixin Automation stocks this timer / counter at our Xiamen warehouse; orders placed before 14:00 CST ship same business day.
The front face carries a 6-digit LCD with red and green backlight and push-button setup for time ranges from 0.001 s to 999,999 h and for count modes up and down. Nineteen operating modes include ON-delay, Signal ON/OFF delay, Interval, One-shot, Twin Timer, Stopwatch and Cumulative. Inputs accept no-voltage (NPN) or voltage (PNP) signals, switchable from the front panel.
Supply is 12 to 48 VDC or 24 VAC. Output is one SPDT contact. The unit clips to DIN rail or mounts in a 45.6 x 45.6 mm panel cutout; front face is IP66. For the AC supply sibling, pick the H5CC-A. For a transistor-output version, pick the H5CC-L8D. For the next-generation upgrade path, consider the H7CC-AU.
Key Features
- 48 x 48 mm digital timer / counter, 6-digit LCD with red / green backlight and push-button setup
- 19 operating modes including ON-delay, Signal ON/OFF delay, Interval, One-shot, Twin Timer, Stopwatch and Cumulative
- Switchable no-voltage (NPN) / voltage (PNP) inputs, SPDT contact output, 12-48 VDC or 24 VAC supply
- DIN rail or panel mount, 45.6 x 45.6 mm cutout, IP66 front face, -10 to +55 degC
- SKU: H5CC-AD
- Series: Omron H5CC 48 mm digital timer / counter
- Voltage: 12 TO 48 VDC
Best-Fit Applications
- Dwell timing on a small stamping press where the ON-delay mode holds the solenoid for a fixed interval after the foot switch is released
- Counting shift production on a packaging line by wiring a proximity sensor to the Signal input and reading the cumulative total at end of shift
- Twin-timer alternation on a dual-pump duty panel where the H5CC-AD swaps the run signal every set interval
Buying Checklist
- Pick the H5CC-AD for a 48 x 48 mm digital timer / counter with screw terminals, 12-48 VDC / 24 VAC supply, and switchable NPN / PNP inputs.
- Pick the H5CC-A instead when the cabinet is fed with 100-240 VAC and the supply must match the rest of the panel.
- Pick the H5CC-L8D instead when the output is a transistor rather than an SPDT contact.
Technical Specifications
| Manufacturer | Omron Corporation (Japan) |
|---|---|
| Series | Omron H5CC 48 mm digital timer / counter |
| Model / SKU | H5CC-AD |
| Function | Digital timer and counter, multi-mode |
| Installation | DIN rail, on-panel, or socket mount, screw terminals |
| Size / Panel Cutout | 48 x 48 x 59 mm (1/16 DIN); 45.6 x 45.6 mm cutout |
| Supply Voltage | 12 to 48 VDC, or 24 VAC |
| Operating Modes | 19 modes including ON-delay, Signal ON/OFF delay, Interval, One-shot, Twin Timer, Stopwatch, Cumulative |
| Time Ranges | 0.001 s to 999,999 h (multiple ranges) |
| Inputs | Signal, Reset, Gate (NPN / PNP, switchable) |
| Output | SPDT contact (time-limit), relay |
| Display / IP | 6-digit LCD with red / green backlight; IP66 front face |
Manufacturer documentation
Omron's own product page, where the manufacturer's current specification and lifecycle information are published. We are an independent distributor and cannot mirror those documents; the link goes to Omron's site.
FAQ for H5CC-AD
What is the Omron H5CC-AD used for?
It is a panel-mount digital timer or counter for stand-alone timing and counting tasks. Typical fits are dwell timing, interval delay, cycle counting and shift-total monitoring on machines that do not need a full PLC.
Can the H5CC-AD run on 24 VDC?
Yes. The H5CC-AD accepts 12 to 48 VDC or 24 VAC on the supply terminals. The H5CC-A is the AC-only sibling for 100-240 VAC supply.
Does the H5CC-AD work with both NPN and PNP sensors?
Yes. The Signal, Reset and Gate inputs accept either no-voltage (NPN) or voltage (PNP) signals, and the input type is selected from the front panel during setup.
What replaces the H5CC-AD?
Omron's current-generation equivalent in the same 48 mm form factor is the H7CC-AU. The H5CC-AD is still in production and widely available from authorised distributors as a spare for legacy panels.
